This product is out of stock
We can email you when it's back in stock, confirm expected lead times, or recommend in-stock alternatives that meet the same requirements.
Allied Telesis AT X950-28XSQ - Switch - L3 - Managed - 24 x 1 Gigabit / 10 Gigabit SFP / SFP+ + 4 x 40/100 Gigabit QSFP+ / QSFP28 - rack-mountable
- 24 x 1/10G SFP+ ports, 4 x 40G/100G uplink ports, and 1 x expansion bay
- Large switching and routing tables support multiple services and connected devices
- VCStack up to 8 units locally or over distance for a resilient network core
- Autonomous Management Framework (AMF) for network automation
- SDN for network intelligence with OpenFlow v 1.3
Overview
Allied Telesis AT-x950-28XSQ-B01, Managed, L3, Rack mounting
Specifications
Management features
- Switch type
- Managed
- Switch layer
- L3
- Quality of Service (QoS) support
- Yes
- Web-based management
- Yes
- Configuring Location Settings (CLI)
- Yes
- System event log
- Yes
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity
- 0
- Basic switching RJ-45 Ethernet ports type
- No
- Installed SFP modules quantity
- 0
- Installed SFP+ modules quantity
- 0
- SFP+ module slots quantity
- 24
- QSFP+ module slots quantity
- 4
- USB 2.0 ports quantity
- 1
Network
- Networking standards
- IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ad, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.3ac, IEEE 802.3ad
- 10G support
- Yes
- Port mirroring
- Yes
- IP routing
- Yes
- Policy-based routing
- Yes
- Routing entries
- 64
- Link aggregation
- Yes
- Spanning tree protocol
- Yes
- VLAN support
- Yes
- Virtual LAN features
- Private VLAN, Stacked VLAN, Tagged VLAN, Voice VLAN
- Number of VLANs
- 4000
Data transmission
- MAC address table
- 96000 entries entries
- Switching capacity
- 1920 Gbit/s Gbit/s
- Forwarding rate
- 1190 Mpps Mpps
- Latency (10 Gbps)
- 0.8 µs µs
- Jumbo frames support
- Yes
- Jumbo frames
- 10000
- Packet buffer memory
- 16 MB MB
Security
- DHCP features
- DHCP client, DHCP relay, DHCP server, DHCPv6 client, DHCPv6 relay, DHCPv6 server
- Access Control List (ACL)
- Yes
- IGMP snooping
- Yes
- Security algorithms
- EAP, HTTPS, MD5, PEAP, SSH, SSH-2, SSL/TLS, TTLS
- MAC address filtering
- Yes
- Loop protection
- Yes
- BPDU filtering/protection
- Yes
- Authentication
- MAC-based authentication, Web-based authentication
Multicast features
- Multicast support
- Yes
- Multicast MAC address table
- 8000 entries entries
Protocols
- Routing protocols
- BGP, OSPF, RIP, RIP-2
Design
- Rack mounting
- Yes
- Stackable
- Yes
- Product colour
- Grey
- LED indicators
- Yes
- Electromagnetic compatibility
- EN55032 A, FCC A, VCCI A
Performance
- Memory type
- DDR-SDRAM
- Internal memory
- 4096 MB MB
- Flash memory
- 4000 MB MB
- Noise level
- 63.4 dB dB
Power
- AC input voltage
- 100 - 240 V V
- AC input frequency
- 47/63 Hz Hz
- Power consumption (max)
- 231.2 W W
Power over Ethernet (PoE)
- Power over Ethernet (PoE)
- No
Operational conditions
- Operating temperature (T-T)
- 0 - 50 °C °C
- Storage temperature (T-T)
- -25 - 70 °C °C
- Operating relative humidity (H-H)
- 5 - 90% %
- Storage relative humidity (H-H)
- 5 - 95% %
- Operating altitude
- 0 - 3050 m m
- Heat dissipation
- 789 BTU/h BTU/h
Weight & dimensions
- Width
- 440 mm mm
- Depth
- 482 mm mm
- Height
- 44 mm mm
- Weight
- 7.2 kg kg
Packaging data
- Package weight
- 9.2 kg kg
Certificates
- Certification
- EN55024, EN61000-3-2 UL60950-1, CAN/CSA-C22.2 No. 60950-1-03, EN60950-1, EN60825-1, AS/NZS 60950 UL, cUL, TUV RoHS
Logistics data
- Harmonized System (HS) code
- 85176990
