This product is out of stock
We can email you when it's back in stock, confirm expected lead times, or recommend in-stock alternatives that meet the same requirements.
ATEN VPK312K1 - Button panel - 29 buttons - cable - for ATEN VP2730 7
- Fully customizable for the functions and layout of the keys
- Power redundancy supported when both DC power and Power over Ethernet (PoE) are supplied
- Convenient reset of system and network settings using the built-in reset button
- Firmware upgradable
- 12-key Network Remote Pad for ATEN Presentation Switches
- Effortless configuration via the intuitive web GUI
- Dual-color button LEDs for clear indication and visibility
- Engraved buttons for intuitive port indication and operation
- Easy pairing with a Presentation Switch via the host Presentation Switch's web console
Overview
ATEN 12-Key Network Remote Pad (EU, 2 Gang), Remote control, White, 10,100 Mbit/s, Aten VP2730, Plastic, Wired
Specifications
Operational conditions
- Operating relative humidity (H-H)
- 0 - 80% %
- Storage temperature (T-T)
- -20 - 60 °C °C
- Storage relative humidity (H-H)
- 0 - 80% %
- Operating temperature (T-T)
- 0 - 40 °C °C
Logistics data
- Master (outer) case width
- 300 mm mm
- Master (outer) case height
- 194 mm mm
- Products per master (outer) case
- 5 pc(s) pc(s)
- Master (outer) case gross weight
- 2.86 kg kg
- Master (outer) case length
- 336 mm mm
- Master (outer) case net weight
- 1.5 kg kg
- Harmonized System (HS) code
- 85299097
Packaging data
- Package width
- 62 mm mm
- Package height
- 173 mm mm
- Package weight
- 480 g g
- Package depth
- 283 mm mm
Features
- Product type
- Remote control
- Ethernet LAN data rates
- 10,100 Mbit/s Mbit/s
- LED indicators
- Yes
- Compatible products
- Aten VP2730
- Product colour
- White
- Ethernet LAN
- Yes
- Reset function
- Yes
- Housing material
- Plastic
Power
- DC input voltage
- 5 V V
- Power consumption (typical)
- 0.8 W W
- Power source type
- DC, PoE
Weight & dimensions
- Width
- 83.2 mm mm
- Depth
- 147.6 mm mm
- Height
- 48 mm mm
- Weight
- 300 g g
Ports & interfaces
- Connectivity technology
- Wired
- Ethernet LAN (RJ-45) ports
- 1
Packaging content
- Quantity
- 1
- User guide
- Yes
