Compare ALLIED TELESIS Hubs & Switches
Comparing 3 products side-by-side — specifications, pricing and stock. Showing ALLIED TELESIS products in the Hubs & Switches category.
| Specification | ALLIED TELESIS Allied Telesis AT IE340-20GP - Switch - L3 - Managed - 8 x 10/100/1000 (PoE+) + 8 x 10/100/1000 (PoE) + 4 x Gigabit SFP - DIN rail mountable, wall-mountable - PoE+ (240 W) - DC powerAT-IE340-20GP-80 £1521.58 £1825.90 inc VAT | ||
|---|---|---|---|
| General | |||
| Authentication Method | RADIUS, TACACS+, Extensible Authentication Protocol (EAP) | — | — |
| Built-in Devices | SD card reader, SDHC card reader | — | — |
| Capacity | Priority queues: 8 | — | — |
| Device Type | Switch - 18 ports - L3 - Managed | — | — |
| Enclosure Type | Desktop, rack-mountable | — | — |
| Encryption Algorithm | DES, Triple DES, RSA, MD5, TLS, SHA-1, SSL 2.0, PEAP, TTLS, DSA, ECDSA, 128-bit AES, 192-bit AES, 256-bit AES, 256-bit SHA-2, 384-bit SHA-2, 512-bit SHA-2, RNG, 224-bit SHA-2 | — | — |
| Features | Flow control, DHCP support, auto-negotiation, BOOTP support, ARP support, IGMP snooping, Syslog support, port mirroring, DiffServ support, full duplex mode, RSTP support, MSTP support, DHCP snooping, ACL support, QoS, DAI, PVST+, STP Root Guard, UDLD, fanless, LLDP support, LACP, SNMP trap, Energy Efficient Ethernet, MIB, NAC, loop prevention, 802.1x authentication, 1.5MB packet buffer, IP source guard, EPSRing, BPDU, ICMP, CPP, SCP, AMF, DDM, NTP, AAA | — | — |
| Performance | Switching fabric bandwidth: 36 Gbps, Forwarding performance: 26.8 Mpps | — | — |
| Ports | 16 x 10/100/1000 (PoE+) + 2 x SFP (mini-GBIC) (uplink) | — | — |
| Remote Management Protocol | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, CLI, SNMP 6, SSH 6 | — | — |
| Routing Protocol | RIP, RIP-2, IGMPv2, IGMP, IGMPv3, static IPv6 routing, MLDv2, MLD, CIDR | — | — |
| Status Indicators | Status | — | — |
| Subtype | Gigabit Ethernet | — | — |
| Power | |||
| AC input frequency | 50 - 60 Hz | — | — |
| AC input voltage | 100 - 240 V | — | — |
| DC input voltage | — | — | 18 - 57 V |
| Power consumption (max) | — | — | 271 W |
| Power supply included | — | — | No |
| Redundant power supply (RPS) support | — | — | Yes |
| Voltage Required | AC 120/230 V | — | — |
| Network | |||
| 10G support | Yes | — | No |
| Broadcast storm control | — | — | Yes |
| Flow control support | Yes | — | Yes |
| Full duplex | Yes | — | Yes |
| IP routing | Yes | — | — |
| Link aggregation | — | — | Yes |
| Networking standards | IEEE 802.2, IEEE 802.3 | — | IEEE 1588, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.2, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Number of VLANs | 2048 | — | 4094 |
| Policy-based routing | — | — | Yes |
| Port mirroring | Yes | — | Yes |
| Spanning tree protocol | Yes | — | Yes |
| Virtual LAN features | — | — | Private VLAN, Tagged VLAN |
| VLAN support | Yes | — | Yes |
| Security | |||
| Access Control List (ACL) | Yes | — | Yes |
| Authentication | — | — | Guest VLAN, MAC-based authentication, Port-based authentication, Web-based authentication |
| BPDU filtering/protection | Yes | — | Yes |
| DHCP features | DHCP client | — | DHCP relay, DHCP server, DHCP snooping, DHCPv6 relay, DHCPv6 server |
| IGMP snooping | Yes | — | Yes |
| Loop protection | Yes | — | — |
| MAC address filtering | — | — | Yes |
| Password protection | — | — | Yes |
| SSH/SSL support | Yes | — | — |
| Management features | |||
| ARP inspection | — | — | Yes |
| Configuring Location Settings (CLI) | — | — | Yes |
| Quality of Service (QoS) support | Yes | — | Yes |
| Switch layer | L3 | — | L3 |
| Switch type | Managed | — | Managed |
| System event log | — | — | Yes |
| Traffic classification | — | — | Yes |
| Traffic shaping | — | — | Yes |
| Web-based management | — | — | Yes |
| Ports & interfaces | |||
| Basic switching RJ-45 Ethernet ports quantity | 16 | — | 16 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) | — | Gigabit Ethernet (10/100/1000) |
| Console port | — | — | RJ-45 |
| Installed SFP modules quantity | 2 | — | 0 |
| Installed SFP+ modules quantity | — | — | 0 |
| SFP module slots quantity | — | — | 4 |
| USB 2.0 ports quantity | — | — | 1 |
| Certificates | |||
| Certification | — | — | CE, FCC, ICES, RCM, TEC8, UL, VCCI RoHS, China-RoHS, WEEE |
| Logistics data | |||
| Country of origin | China | — | — |
| Harmonized System (HS) code | — | — | 85176990 |
| Weight & dimensions | |||
| Depth | 231 mm | — | 139 mm |
| Height | 44 mm | — | 153 mm |
| Weight | 3 kg | — | 2.34 kg |
| Width | 341 mm | — | 91 mm |
| Design | |||
| DIN rail mounting | — | — | Yes |
| Electromagnetic compatibility | — | — | EN 55024, EN 61000-6-2 |
| Housing material | — | — | Aluminium, Metal |
| International Protection (IP) code | — | — | IP30 |
| LED indicators | — | — | Yes |
| Product colour | Grey | — | Grey |
| Rack mounting | Yes | — | No |
| Stackable | — | — | No |
| Wall mountable | — | — | Yes |
| Performance | |||
| Export Control Classification Number (ECCN) | — | — | 5A992C |
| Fanless | — | — | Yes |
| Flash memory | 64 MB | — | 128 MB |
| Internal memory | 256 MB | — | 512 MB |
| Memory type | — | — | DDR-SDRAM |
| Noise level | 34 dB | — | — |
| Data transmission | |||
| Forwarding rate | — | — | 29.7 Mpps |
| Jumbo frames | — | — | 9000 |
| Jumbo frames support | Yes | — | Yes |
| Latency (1 Gbps) | 3.4 µs | — | — |
| Latency (10-100 Mbps) | 7.9 µs | — | — |
| MAC address table | 16000 entries | — | 16000 entries |
| Number of queues | — | — | 8 |
| Packet buffer memory | 1.5 MB | — | 1.5 MB |
| Switching capacity | 36 Gbit/s | — | 40 Gbit/s |
| Operational conditions | |||
| Heat dissipation | 72 BTU/h | — | 105.8 BTU/h |
| Operating altitude | 0 - 3000 m | — | 0 - 3000 m |
| Operating relative humidity (H-H) | 5 - 90% | — | 5 - 95% |
| Operating temperature (T-T) | 0 - 50 °C | — | -40 - 75 °C |
| Storage relative humidity (H-H) | 5 - 95% | — | 5 - 90% |
| Storage temperature (T-T) | -25 - 70 °C | — | -40 - 85 °C |
| Multicast features | |||
| Multicast support | Yes | — | Yes |
| Packaging data | |||
| Package depth | 360 mm | — | — |
| Package height | 150 mm | — | — |
| Package weight | 4.35 kg | — | — |
| Package width | 430 mm | — | — |
| Power over Ethernet (PoE) | |||
| Power over Ethernet (PoE) | Yes | — | Yes |
| Power over Ethernet (PoE) power per port | — | — | 15 W |
| Power over Ethernet plus (PoE+) ports quantity | 16 | — | 16 |
| Total Power over Ethernet (PoE) budget | 247 W | — | 240 W |
| Protocols | |||
| Routing protocols | — | — | BGP, OSPF, RIP |
