Compare APC Racking & Cabinets
Comparing 5 products side-by-side — specifications, pricing and stock. Showing APC products in the Racking & Cabinets category.
| Specification | |||||
|---|---|---|---|---|---|
| Power | |||||
| AC input frequency | 50 - 60 Hz | — | — | — | 50/60 Hz |
| Load capacity | 7400 VA | — | — | — | 34600 VA |
| Maximum current | 32 A | — | — | — | 60 A |
| Maximum power | 7360 W | — | — | — | — |
| Nominal input voltage | 200, 208, 230, 220-240 V | — | — | — | 400 V |
| Nominal output voltage | — | — | — | — | 400 V |
| Number of phases | — | — | — | — | 3 |
| Ports & interfaces | |||||
| AC outlet types | C13 coupler, C19 coupler | — | — | — | C13 coupler, C15 coupler, C19 coupler, C21 coupler |
| AC outlets quantity | 24 AC outlet(s) | — | — | — | 42 AC outlet(s) |
| Ethernet LAN (RJ-45) ports | — | — | — | — | 5 |
| Power plug | IEC 60309 | — | — | — | — |
| USB ports quantity | — | — | — | — | 1 |
| Certificates | |||||
| Certification | EAC, EN 55022 class A, EN 55024, EN 61000-3-2, EN 61000-3-3, RCM, VDE | — | — | — | — |
| Compliance certificates | — | — | — | — | RoHS |
| Weight & dimensions | |||||
| Depth | 46 mm | — | 45 mm | — | 75 mm |
| Height | 1829 mm | — | 2045 mm | — | 1826 mm |
| Weight | 7.34 kg | 1 kg | 2.5 kg | — | 11.7 kg |
| Width | 56 mm | — | 107 mm | — | 56 mm |
| Other features | |||||
| Dimensions (WxDxH) | — | 519 x 24 x 43 mm | — | — | — |
| Logistics data | |||||
| Harmonized System (HS) code | — | 85389099 | 85389099 | — | — |
| Management features | |||||
| Management platform | — | — | — | — | NMC3 |
| Design | |||||
| Mounting | Vertical | — | — | — | — |
| On/off switch | No | — | — | — | — |
| PDU types | Switched | — | — | — | Metered |
| Product colour | Black | — | — | — | Black |
| Rack capacity | 0U | — | — | — | 0U |
| Type | Single-phase | — | — | — | Three-phase |
| Operational conditions | |||||
| Non-operating altitude | 0 - 15240 m | — | — | — | — |
| Operating altitude | 0 - 3048 m | — | — | — | — |
| Operating relative humidity (H-H) | 0 - 95% | — | — | — | — |
| Operating temperature (T-T) | -5 - 45 °C | — | — | — | — |
| Storage relative humidity (H-H) | 5 - 95% | — | — | — | — |
| Storage temperature (T-T) | -25 - 65 °C | — | — | — | — |
| Packaging data | |||||
| Package depth | 124 mm | 99 mm | 1113 mm | — | 262 mm |
| Package height | 2040 mm | 54 mm | 163 mm | — | 2110 mm |
| Package weight | 9.95 kg | 1.14 kg | 2.95 kg | — | 17 kg |
| Package width | 165 mm | 565 mm | 64 mm | — | 132 mm |
| Features | |||||
| Product colour | — | Black | Black | — | — |
| Rack capacity | — | — | 48U | — | — |
| Technical details | |||||
| Total carbon footprint (kg of CO2e) | — | — | 8.95 | — | — |
