Compare APC UPS
Comparing 5 products side-by-side — specifications, pricing and stock. Showing APC products in the UPS category.
| Specification | APC APC Back-UPS Pro - UPS - tower, RGB lights - AC 230 V - 1320 Watt - 2200 VA - 1-phase - output connectors: 6 - black, midnightBGM2200B-GR £332.41 £398.89 inc VAT | APC Schneider Electric Easy UPS 3S E3SUPS20KHB - UPS - AC 400 V - 20 kW - 20000 VA - 3-phase - whiteE3SUPS20KHB £4829.86 £5795.83 inc VAT | |||
|---|---|---|---|---|---|
| Power | |||||
| Input current | — | — | — | 95 A | — |
| Number of phases | — | — | — | 3 | — |
| Battery | |||||
| Automatic battery test | Yes | Yes | — | — | — |
| Battery life (max) | — | 5 year(s) | — | — | — |
| Battery recharge time | — | 16 h | — | — | — |
| Battery technology | Lithium-Ion (Li-Ion) | Sealed Lead Acid (VRLA) | — | — | Sealed Lead Acid (VRLA) |
| Battery voltage | — | 24 V | — | — | 220 V |
| Cold start | — | Yes | — | — | — |
| Hot-swap battery | Yes | — | — | — | — |
| Number of batteries supported | — | 1 | — | — | 3 |
| Ports & interfaces | |||||
| AC outlet types | C13 coupler, C19 coupler | C13 coupler, Type F | IEC 60320 | — | — |
| AC outlets quantity | 9 AC outlet(s) | 6 AC outlet(s) | — | — | — |
| Cabling technology | — | 10/100/1000Base-T(X) | — | — | — |
| Ethernet LAN (RJ-45) ports | 1 | — | — | — | — |
| Power plug | C20 coupler | Type F | — | — | — |
| Serial interface | Yes | — | — | — | — |
| Serial interface type | — | RJ-45 | — | — | — |
| Serial ports quantity | 1 | — | — | — | — |
| SmartConnect port | — | — | No | — | — |
| SmartSlot | Yes | — | Yes | — | — |
| USB port | Yes | Yes | — | — | — |
| Features | |||||
| Audible alarm modes | — | Alarm when on battery, Low battery alarm, Overload alarm | — | — | — |
| Audible alarm(s) | Yes | Yes | — | — | — |
| Auto-restart | Yes | — | — | — | — |
| Automatic Voltage Regulation (AVR) | — | Yes | — | — | — |
| Compatibility | — | — | — | Easy UPS 3S 10-40kVA | — |
| Crest factor | 3:1 | — | — | — | — |
| Emergency Power Off (EPO) | Yes | — | — | — | — |
| EMI/RFI noise filtering | — | Yes | — | — | — |
| Input current Total Harmonic Distortion (THD) | — | — | — | — | 3% |
| Input frequency | 50/60 Hz | 50/60 Hz | — | — | 45/65 Hz |
| Input operation voltage (max) | 286 V | 302 V | — | — | 477 V |
| Input operation voltage (min) | 160 V | 168 V | — | — | 304 V |
| Input power factor | — | — | — | — | 0.99 |
| Maximum current | — | 12 A | — | — | 37 A |
| Mounting type | — | — | — | Wall-mount | — |
| Noise level | 55 dB | 45 dB | — | — | — |
| Number of input phases | — | — | — | — | 3 |
| Number of output phases | — | — | — | — | 3 |
| Output frequency | 50/60 Hz | 60 Hz | — | — | 50/60 Hz |
| Output operation voltage (max) | 240 V | 230 V | — | — | 415 V |
| Output operation voltage (min) | 220 V | — | — | — | 380 V |
| Output power | 2700 W | 1320 W | — | — | 20000 W |
| Output power capacity | 3 kVA | 2.2 kVA | — | — | 20 kVA |
| Output voltage Total Harmonic Distortion (THD) | — | — | — | — | 3% |
| Product colour | — | — | — | White | — |
| Product type | — | — | — | Backfeed box | — |
| Response time | 6 ms | 8 ms | — | — | — |
| Surge energy rating | 739 J | 1080 J | — | — | — |
| Surge protection | — | Yes | — | — | — |
| Surge protection features | — | Network | — | — | — |
| UPS topology | Line-Interactive | Line-Interactive | — | — | Double-conversion (Online) |
| Waveform | Sine | Sine | — | — | Pure sine |
| Design | |||||
| Cable length | — | 1.52 m | — | — | — |
| Control type | Touch | — | — | — | — |
| Display type | LCD | LCD | — | — | LED |
| Form factor | Rackmount | Tower | — | — | Tower |
| International Protection (IP) code | IP20 | IP20 | — | — | IP20 |
| LED indicators | Yes | — | — | — | — |
| Product colour | Black, Grey | Black | — | — | White |
| Rack capacity | 2U | 0U | — | — | — |
| Packaging content | |||||
| Cables included | RJ-45, USB cable | USB cable | — | — | — |
| Management card included | — | — | No | — | — |
| Manual | — | Yes | — | — | — |
| Quantity per pack | — | — | — | 1 pc(s) | — |
| Quick installation guide | — | — | — | — | Yes |
| Rack mount kit | Yes | — | — | — | — |
| Certificates | |||||
| Certification | — | IEC 62040-1-1 IEC 62040-2 | — | — | CE, EAC, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, RCM, WEEE, REACH |
| Compliance certificates | RoHS | — | — | REACH, RoHS | RoHS |
| Weight & dimensions | |||||
| Depth | 683 mm | 408.9 mm | — | 200 mm | 928 mm |
| Height | 86 mm | 292.1 mm | — | 300 mm | 1400 mm |
| Weight | 33.3 kg | 12.3 kg | — | 20 kg | 122 kg |
| Width | 432 mm | 104.1 mm | — | 550 mm | 380 mm |
| Logistics data | |||||
| Harmonized System (HS) code | — | — | — | — | 85078000 |
| Total carbon footprint (kg of CO2e) | — | — | 1030.49 | — | — |
| Other features | |||||
| Nominal input voltage | 230 V | — | — | — | — |
| Nominal output voltage | 230 V | — | — | — | — |
| Output voltage | — | — | — | — | 400 V |
| Operational conditions | |||||
| Non-operating altitude | 0 - 7620 m | 0 - 3048 m | — | — | 0 - 15000 m |
| Operating altitude | 0 - 3048 m | 0 - 3048 m | — | 0 - 2000 m | 0 - 999.9 m |
| Operating relative humidity (H-H) | 0 - 95% | 0 - 95% | — | — | 0 - 95% |
| Operating temperature (T-T) | 0 - 40 °C | 0 - 40 °C | — | 0 - 40 °C | 0 - 40 °C |
| Storage relative humidity (H-H) | 0 - 95% | 0 - 95% | — | — | 0 - 95% |
| Storage temperature (T-T) | -15 - 45 °C | -15 - 40 °C | — | -25 - 55 °C | -15 - 40 °C |
| Packaging data | |||||
| Package depth | 980 mm | 480 mm | — | 200 mm | 1014 mm |
| Package height | 458 mm | 155 mm | — | 300 mm | 1640 mm |
| Package weight | 41.5 kg | 14.5 kg | — | 20 kg | 158 kg |
| Package width | 600 mm | 355 mm | — | 550 mm | 563 mm |
| Sustainability | |||||
| Sustainability certificates | — | Green Premium | Green Premium | — | — |
| Sustainability compliance | Yes | — | — | Yes | — |
