Compare APC Racking & Cabinets
Comparing 5 products side-by-side — specifications, pricing and stock. Showing APC products in the Racking & Cabinets category.
| Specification | |||||
|---|---|---|---|---|---|
| Power | |||||
| AC input frequency | 50 - 60 Hz | — | — | — | 50/60 Hz |
| Load capacity | 2300 VA | — | — | — | 34600 VA |
| Maximum current | 10 A | — | — | — | 60 A |
| Maximum input current per phase | 10 A | — | — | — | — |
| Maximum power | 2300 W | — | — | — | — |
| Maximum total current draw per phase | 10 A | — | — | — | — |
| Nominal input voltage | 200-230 V | — | — | — | 400 V |
| Nominal output voltage | 208-230 V | — | — | — | 400 V |
| Number of phases | — | — | — | — | 3 |
| Ports & interfaces | |||||
| AC outlet types | C13 coupler | — | — | — | C13 coupler, C15 coupler, C19 coupler, C21 coupler |
| AC outlets quantity | 8 AC outlet(s) | — | — | — | 42 AC outlet(s) |
| Ethernet LAN (RJ-45) ports | — | — | — | — | 5 |
| Input connection type | IEC-320 C14 | — | — | — | — |
| Power plug | C14 coupler | — | — | — | — |
| USB ports quantity | — | — | — | — | 1 |
| Features | |||||
| Cable length | 1.98 m | — | — | — | — |
| Product colour | — | Black | Black | — | — |
| Rack capacity | — | — | 48U | — | — |
| Certificates | |||||
| Certification | cUL Listed, CE, CSA, EN 55022 Class A, EN 55024, EN 61000-3-2, EN 61000-3-3, GOST, IRAM, MIC, UL 60950, UL Listed, VDE, VCCI, REACH | — | — | — | — |
| Compliance certificates | RoHS | — | — | — | RoHS |
| Weight & dimensions | |||||
| Depth | 108 mm | — | 45 mm | — | 75 mm |
| Height | 44 mm | — | 2045 mm | — | 1826 mm |
| Weight | 2.27 kg | 1 kg | 2.5 kg | — | 11.7 kg |
| Width | 445 mm | — | 107 mm | — | 56 mm |
| Other features | |||||
| Dimensions (WxDxH) | — | 519 x 24 x 43 mm | — | — | — |
| Logistics data | |||||
| Harmonized System (HS) code | — | 85389099 | 85389099 | — | — |
| Total carbon footprint (kg of CO2e) | 915.89 | — | — | — | — |
| Management features | |||||
| Management platform | — | — | — | — | NMC3 |
| Monitoring | Current, Power, Voltage | — | — | — | — |
| Outlet control | Lock-out, Recycle, Turn off, Turn on | — | — | — | — |
| Design | |||||
| Mounting | Horizontal/Vertical | — | — | — | — |
| PDU types | Metered, Switched | — | — | — | Metered |
| Product colour | Black | — | — | — | Black |
| Rack capacity | 0U/1U | — | — | — | 0U |
| Type | — | — | — | — | Three-phase |
| Operational conditions | |||||
| Non-operating altitude | 1 - 15000 m | — | — | — | — |
| Operating altitude | 0 - 3000 m | — | — | — | — |
| Operating relative humidity (H-H) | 0 - 95% | — | — | — | — |
| Operating temperature (T-T) | 0 - 45 °C | — | — | — | — |
| Storage relative humidity (H-H) | 0 - 95% | — | — | — | — |
| Storage temperature (T-T) | -25 - 65 °C | — | — | — | — |
| Packaging data | |||||
| Package depth | 343 mm | 99 mm | 1113 mm | — | 262 mm |
| Package height | 70 mm | 54 mm | 163 mm | — | 2110 mm |
| Package weight | 3.45 kg | 1.14 kg | 2.95 kg | — | 17 kg |
| Package width | 470 mm | 565 mm | 64 mm | — | 132 mm |
| Packaging content | |||||
| Packaging content | Installation Guide, Rack Mounting Brackets, User Manual | — | — | — | — |
| Technical details | |||||
| Total carbon footprint (kg of CO2e) | — | — | 8.95 | — | — |
