Compare Asus Graphics Cards
Comparing 5 products side-by-side — specifications, pricing and stock. Showing Asus products in the Graphics Cards category.
| Specification | Asus ASUS TUF Gaming GeForce RTX 5080 16GB - OC Edition - graphics card - GeForce RTX 5080 - 16 GB GDDR7 - PCI Express 5.0 - 2 x HDMI, 3 x DisplayPort90YV0M30-M0NA00 £1295.90 £1555.08 inc VAT | ||||
|---|---|---|---|---|---|
| General | |||||
| API Supported | OpenGL 4.6 | DirectX 12, OpenGL 4.5 | — | — | — |
| Boost Clock | 2550 MHz | 1506 MHz | — | — | — |
| Boost Clock (OC) | 2580 MHz | — | — | — | — |
| Bus Type | PCI Express 5.0 | PCI Express 3.0 | — | — | — |
| Core Clock | — | 1266 MHz | — | — | — |
| CUDA Cores | 3840 | 384 | — | — | — |
| Device Type | Graphics card - low profile | Graphics card - low profile - fanless | — | — | — |
| Features | NVIDIA Blackwell GPU architecture, NVIDIA DLSS 4, AUTO-EXTREME technology, Dual ball Bearing Fans, 5th gen Tensor Cores, 4th gen Ray Tracing Cores, Dual Slot Fan Cooler, HDCP | Native HDMI, ASUS 0-dB thermal solution, Nvidia PhysX-Ready, NVIDIA Adaptive Vertical Sync, AUTO-EXTREME technology, HDCP | — | — | — |
| Graphics Engine | NVIDIA GeForce RTX 5060 | NVIDIA GeForce GT 1030 | — | — | — |
| Interfaces Details | DisplayPort, 2 x HDMI | DVI-D (Single-Link), HDMI | — | — | — |
| Max Monitors Supported | 3 | — | — | — | — |
| Max Resolution | 7680 x 4320 | — | — | — | — |
| Max Resolution Details | — | DVI: 1920 x 1200 | — | — | — |
| VR Ready | Yes | — | — | — | — |
| Processor | |||||
| CUDA | Yes | Yes | Yes | Yes | Yes |
| CUDA cores | 3840 | — | 10752 | 10752 | 384 |
| FireStream | — | No | — | — | — |
| Graphics processor | GeForce RTX 5060 | GeForce GT 1030 | GeForce RTX 5080 | GeForce RTX 5080 | GeForce GT 730 |
| Graphics processor family | NVIDIA | NVIDIA | NVIDIA | NVIDIA | NVIDIA |
| Maximum displays per videocard | 4 | — | 4 | 4 | 4 |
| Maximum resolution | 7680 x 4320 pixels | 1920 x 1200 pixels | 7680 x 4320 pixels | 7680 x 4320 pixels | 3840 x 2160 pixels |
| Parallel processing technology support | Not supported | — | Not supported | Not supported | Not supported |
| Processor boost clock speed | 2550 MHz | 1506 MHz | 2700 MHz | 2700 MHz | 902 MHz |
| Processor boost clock speed (OC mode) | — | — | — | — | 927 MHz |
| Processor frequency | — | 1266 MHz | — | — | — |
| Processor frequency (OC mode) | 2580 MHz | — | — | 2730 MHz | — |
| Memory | |||||
| Data transfer rate | 28 Gbit/s | — | 30 Gbit/s | 30 Gbit/s | — |
| Discrete graphics card memory | — | 2 GB | 16 GB | 16 GB | 2 GB |
| Graphics card memory type | GDDR7 | GDDR5 | GDDR7 | GDDR7 | GDDR5 |
| Memory bus | 128 bit | 64 bit | 256 bit | 256 bit | — |
| Memory clock speed | — | 6008 MHz | — | — | 5010 MHz |
| Size | 8 GB | 2 GB | — | — | — |
| Power | |||||
| Minimum system power supply | 550 W | — | 850 W | 850 W | 300 W |
| Supplementary power connectors | 1x 8-pin | — | 1x 16-pin | 1x 16-pin | — |
| Design | |||||
| Bracket height | — | — | — | Full-Height (FH) | — |
| Cooling technology | — | — | ASUS Axial-tech | ASUS Axial-tech | — |
| Cooling type | Active | Passive | Active | Active | Passive |
| Form factor | — | — | Full-Height/Full-Length (FH/FL) | Full-Height/Full-Length (FH/FL) | — |
| Illumination | — | — | Yes | Yes | — |
| Illumination colour | — | — | Multi | Multi | — |
| Number of fans | 3 fan(s) | — | 3 fan(s) | 3 fan(s) | — |
| Number of slots | 2 | 1 | 3.6 | 2.5 | 1 |
| Product colour | Multicolour | — | Multicolour | Black, Brown | Black, Blue |
| SFF ready | — | — | — | Yes | — |
| Weight & dimensions | |||||
| Depth | 38 mm | 40 mm | 72 mm | 50 mm | 18 mm |
| Height | 69 mm | 69 mm | 146 mm | 126 mm | 105 mm |
| Length | 175.8 mm | 173 mm | 348 mm | 304 mm | 148 mm |
| Weight | — | — | 1.94 kg | — | — |
| Performance | |||||
| DirectX version | — | 12.0 | — | 12 Ultimate | — |
| Dual Link DVI | No | — | No | No | No |
| HDCP | Yes | Yes | Yes | Yes | Yes |
| HDCP version | 2.3 | — | 2.3 | 2.3 | — |
| NPU performance up to | 627 TOPs | — | — | 1801 TOPs | — |
| NVIDIA G-SYNC | Yes | — | Yes | Yes | — |
| OpenGL version | 4.6 | 4.5 | 4.6 | 4.6 | 4.6 |
| Overclocked (OC) edition | Yes | — | — | Yes | — |
| PhysX | — | Yes | — | — | — |
| TV tuner integrated | — | — | — | No | No |
| Virtual Reality (VR) ready | Yes | — | Yes | Yes | — |
| Ports & interfaces | |||||
| DisplayPort version | 2.1a | — | — | 2.1b | — |
| DisplayPorts quantity | 1 | 0 | 3 | 2 | 0 |
| DVI-D ports quantity | 0 | 1 | 0 | 0 | 0 |
| DVI-I ports quantity | 0 | 0 | 0 | 0 | 0 |
| HDMI ports quantity | 2 | 1 | 2 | 1 | 4 |
| HDMI version | 2.1 | — | 2.1b | 2.1b | 1.4b |
| Interface type | PCI Express 5.0 | PCI Express 3.0 | PCI Express 5.0 | PCI Express 5.0 | PCI Express x1 |
| Mini DisplayPorts quantity | — | — | 0 | 0 | — |
| Mini HDMI ports quantity | — | — | 0 | 0 | — |
| Thunderbolt 3 ports quantity | — | — | 0 | 0 | — |
| USB Type-C ports quantity | — | — | — | 1 | — |
| VGA (D-Sub) ports quantity | — | 0 | — | — | — |
| Logistics data | |||||
| Harmonized System (HS) code | — | 84733020 | — | — | 84733020 |
| Packaging content | |||||
| Manual | — | — | — | Yes | Yes |
| Power cord included | — | — | — | Yes | — |
| Packaging data | |||||
| Package depth | 55 mm | — | 266 mm | — | — |
| Package height | 218 mm | — | 99 mm | — | — |
| Package type | Box | — | Box | Box | Box |
| Package weight | — | — | 3.01 kg | — | — |
| Package width | 300 mm | — | 425.9 mm | — | — |
| System requirements | |||||
| Windows operating systems supported | Yes | — | Yes | Windows 10 x64, Windows 11 x64 | — |
