Product Comparison
Technical Specifications
Feature
General
Depth
26.9 cm
26.87 cm
26.9 cm
—
26.9 cm
Device Type
Firewall
Firewall
Firewall
—
Firewall
Height
4.37 cm
4.37 cm
4.37 cm
—
4.37 cm
Height (Rack Units)
1U
1U
1U
—
1U
Weight
3.63 kg
3.63 kg
3.63 kg
—
3.63 kg
Width
43.7 cm
43.69 cm
43.7 cm
—
43.7 cm
Power
Installed Qty
—
1
—
—
—
Max Supported Qty
—
1
—
—
—
Power Device
Internal power supply
Internal power supply
Internal power supply
—
Internal power supply
Power Provided
—
100 Watt
—
—
—
Voltage Required
AC 120/230 V (50/60 Hz)
AC 120/230 V (50/60 Hz)
AC 120/230 V (50/60 Hz)
—
AC 120/230 V (50/60 Hz)
Miscellaneous
Compliant Standards
CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, ICES-003 Class A, EN 61000-4-5, EN 61000-4-11, EN 61000-4-8, UL 60950-1, IEC 60950-1, EN 60950-1, GB 4943, Directive 2004/108/EC, VCCI Class A, KN24, KN22 Class A, EN 55022 Class A, FCC CFR47 Part 15 A, CNS 13438 Class A, EN 300 386, TVCN 7317, Directive 2006/108/EC, TCVN 7189, CAN/CSA-C22.2 No. 60950-1, AS/NZS CISPR22 Class A
CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, ICES-003 Class A, EN 61000-4-5, EN 61000-4-11, EN 61000-4-8, UL 60950-1, IEC 60950-1, EN 60950-1, GB 4943, Directive 2004/108/EC, VCCI Class A, KN24, KN22 Class A, EN 55022 Class A, FCC CFR47 Part 15 A, CNS 13438 Class A, EN 300 386, TVCN 7317, Directive 2006/108/EC, TCVN 7189, CAN/CSA-C22.2 No. 60950-1, AS/NZS CISPR22 Class A
CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, ICES-003 Class A, EN 61000-4-5, EN 61000-4-11, EN 61000-4-8, UL 60950-1, IEC 60950-1, EN 60950-1, GB 4943, Directive 2004/108/EC, VCCI Class A, KN24, KN22 Class A, EN 55022 Class A, FCC CFR47 Part 15 A, CNS 13438 Class A, EN 300 386, TVCN 7317, Directive 2006/108/EC, TCVN 7189, CAN/CSA-C22.2 No. 60950-1, AS/NZS CISPR22 Class A
—
CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, ICES-003 Class A, EN 61000-4-5, EN 61000-4-11, EN 61000-4-8, UL 60950-1, IEC 60950-1, EN 60950-1, GB 4943, Directive 2004/108/EC, VCCI Class A, KN24, KN22 Class A, EN 55022 Class A, FCC CFR47 Part 15 A, CNS 13438 Class A, EN 300 386, TVCN 7317, Directive 2006/108/EC, TCVN 7189, CAN/CSA-C22.2 No. 60950-1, AS/NZS CISPR22 Class A
Included Accessories
Mounting brackets
Mounting brackets
Mounting brackets
—
Mounting brackets
Networking
Airflow Direction
—
Front to back airflow
—
—
—
Capacity
Concurrent connections: 200000, New connections per second: 75000, VPN peers: 150, Security contexts: 2
Maximum concurrent sessions with AVC: 600000, New connections per second with AVC: 28000, VPN peers: 800, Concurrent firewall connections: 600000, New connections per second: 150000
Concurrent firewall connections: 600000, New connections per second: 150000, VPN peers: 800
—
Maximum concurrent sessions with AVC: 200000, New connections per second with AVC: 15000
Connectivity Technology
Wired
Wired
Wired
—
Wired
Features
1 fan
1 fan
1 fan
—
1 fan
Form Factor
Rack-mountable
Rack-mountable
Rack-mountable
—
Rack-mountable
Performance
Firewall throughput (UDP): 4.5 Gbps, Multiprotocol firewall throughput: 2.5 Gbps, IPsec VPN throughput (450B UDP L2L test): 1 Gbps
Firewall and Application Visibility and Control (AVC) throughput (1024B): 3 Gbps, Firewall and Application Visibility and Control (AVC) and Intrusion Prevention System (IPS) throughput (1024B): 3 Gbps, Transport Layer Security (TLS) throughput: 1.4 Gbps, NGIPS throughput (1024B): 3 Gbps, IPSec VPN throughput (1024B TCP w/Fastpath): 1.4 Gbps, Maximum inspection throughput: 7.5 Gbps, IPsec VPN throughput (450B UDP L2L test): 1.7 Gbps
Firewall throughput: 7.5 Gbps, Multiprotocol firewall throughput: 4.5 Gbps, IPsec VPN throughput (450B UDP L2L test): 1.7 Gbps
—
Firewall and Application Visibility and Control (AVC) throughput (1024B): 1.5 Gbps, Firewall and Application Visibility and Control (AVC) and Intrusion Prevention System (IPS) throughput (1024B): 1.5 Gbps, Firewall and Application Visibility and Control (AVC) throughput (450B): 550 Mbps, Firewall and Application Visibility and Control (AVC) and Intrusion Prevention System (IPS) throughput (450B): 550 Mbps, Transport Layer Security (TLS) throughput: 700 Mbps, NGIPS throughput (1024B): 1.5 Gbps, NGIPS throughput (450B): 550 Mbps, IPSec VPN throughput (1024B TCP w/Fastpath): 1 Gbps
Processor / Memory / Storage
Hard Drive
200 GB x 1
SSD 200 GB x 1
200 GB x 1
—
200 GB x 1
Processors Installed
—
1 x Intel
—
—
—
RAM
—
32 GB DDR4 SDRAM
—
—
—
Environmental Parameters
Humidity Range Operating
90% (non-condensing)
90% (non-condensing)
90% (non-condensing)
—
90% (non-condensing)
Max Operating Temperature
40 °C
40 °C
40 °C
—
40 °C
Min Operating Temperature
0 °C
0 °C
0 °C
—
0 °C
Connections & Expansion
Interfaces
8 x - RJ-45, 4 x - SFP (mini-GBIC), 1 x 1000Base-T (management) - RJ-45, 1 x serial - RJ-45, 1 x USB 3.0 - Type A
8 x 1000Base-T - RJ-45, 2 x 1000Base-X - SFP+, 1 x 1000Base-T (management) - RJ-45, 1 x serial - RJ-45, 1 x USB 3.0 - Type A, 2 x 10GBase-X - SFP (mini-GBIC)
8 x - RJ-45, 2 x Ethernet 1000 - SFP (mini-GBIC), 2 x 1Gb Ethernet/10Gb Ethernet - SFP+, 1 x 1000Base-T (management) - RJ-45, 1 x serial - RJ-45, 1 x USB 3.0 - Type A
—
8 x - RJ-45, 4 x - SFP (mini-GBIC), 1 x 1000Base-T (management) - RJ-45, 1 x serial - RJ-45, 1 x USB 3.0 - Type A
Manufacturer Warranty
Service & Support
Limited warranty - advance hardware replacement - 90 days - response time: 10 days
Limited warranty - advance hardware replacement - 90 days - response time: 10 days
Limited warranty - advance hardware replacement - 90 days - response time: 10 days
—
Limited warranty - advance hardware replacement - 90 days - response time: 10 days
Software / System Requirements
Software Included
—
Cisco Threat Defense 6.5
Cisco ASA 9.13.1
—
Cisco Threat Defense 6.4
