Compare CISCO MERAKI SECURITY Firewalls
Comparing 4 products side-by-side — specifications, pricing and stock. Showing CISCO MERAKI SECURITY products in the Firewalls category.
| Specification | CISCO MERAKI SECURITY Cisco Meraki MX67W - Security appliance - 1GbE - Wi-Fi 5 - 2.4 GHz, 5 GHz - desktopMX67W-HW £834.77 £1001.72 inc VAT | |||
|---|---|---|---|---|
| General | ||||
| Depth | 14.8 cm | 14.8 cm | — | 16.4 cm |
| Device Type | Security appliance | Security appliance | Security appliance | Security appliance |
| Height | 2.7 cm | 2.7 cm | — | 2.7 cm |
| Weight | 850 g | 1.12 kg | — | 830 g |
| Width | 28.3 cm | 28.4 cm | — | 23.9 cm |
| Power | ||||
| Installed Qty | 1 | 1 | 2 | 1 |
| Max Supported Qty | 1 | 1 | 2 | 1 |
| Power Device | External power adapter | External power adapter | Internal power supply | External power adapter |
| Power Over Ethernet (PoE) Supported | PoE | PoE+ | — | — |
| Power Provided | 100 Watt | 100 Watt | 250 Watt | 18 Watt |
| Power Redundancy | — | — | Yes | — |
| Voltage Required | — | — | AC 120/230 V (50/60 Hz) | — |
| Miscellaneous | ||||
| Cables Included | — | — | — | 2 x network cable |
| Included Accessories | — | — | — | Mounting kit |
| Aerial | ||||
| Antenna | — | — | — | External |
| Antenna Qty | — | — | — | 2 |
| Networking | ||||
| Authentication Method | — | — | Active Directory | — |
| Capacity | Maximum number of users: 75 | Maximum number of users: 50 | VPN tunnels (site-to-site): | Maximum number of users: 50 |
| Compliant Standards | — | — | — | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.1x, IEEE 802.11n, IEEE 802.11ac Wave 2 |
| Connectivity Technology | Wired | Wired, wireless | Wired | Wireless, wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet | Ethernet, Fast Ethernet, Gigabit Ethernet | Gigabit Ethernet | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2 |
| Data Transfer Rate | — | — | — | 1.3 Gbps |
| Features | 3G/4G USB Dongle Support, NAT support, firewall protection, VLAN support, wall mountable, firmware upgradable, Link Aggregation, DMZ support, DHCP support, VPN client, content filtering, Intrusion Prevention System (IPS), Intrusion Detection System (IDS), IP Security (IPSec) support, IPSec Virtual Private Network (VPN), layer 7 switching, Quality of Service (QoS), load balancing, MPLS VPN, static routing, traffic shaping, 802.1x authentication | 3G/4G USB Dongle Support, NAT support, firewall protection, VLAN support, wall mountable, firmware upgradable, Link Aggregation, DMZ support, DHCP support, VPN client, content filtering, Intrusion Prevention System (IPS), Intrusion Detection System (IDS), IP Security (IPSec) support, IPSec Virtual Private Network (VPN), layer 7 switching, Quality of Service (QoS), load balancing, MPLS VPN, static routing, traffic shaping, 802.1x authentication | Network monitoring, DMZ port, DHCP support, NAT support, VPN support, VLAN support, manageable, application level inspection, Link Aggregation, traffic shaping, Web Filtering, WAN failover, 3G/4G USB Dongle Support, firmware upgradable, Intrusion Prevention System (IPS), Intrusion Detection System (IDS) | Firewall protection, DHCP support, NAT support, load balancing, layer 7 switching, VLAN support, traffic shaping, content filtering, Intrusion Detection System (IDS), Intrusion Prevention System (IPS), firmware upgradable, wall mountable, IPSec Virtual Private Network (VPN), Quality of Service (QoS), MPLS VPN, 3G/4G USB Dongle Support, static routing, 802.1x authentication, Link Aggregation, VPN client, IP Security (IPSec) support, DMZ support |
| Form Factor | Desktop | Desktop | Rack-mountable | Desktop |
| Frequency Band | — | — | — | 2.4 GHz, 5 GHz |
| Network / Transport Protocol | IPSec, DHCP, L2TP, PPPoE | IPSec, DHCP, L2TP, PPPoE | TCP/IP, DHCP, IPSec | IPSec, DHCP |
| Performance | Firewall throughput: 1 Gbps, VPN throughput: 500 Mbps, Advanced security throughput: 750 Mbps | Firewall throughput: 450 Mbps, VPN throughput: 200 Mbps, Advanced security throughput: 300 Mbps | Firewall throughput: 4 Gbps, VPN throughput: 1 Gbps | Firewall throughput: 450 Mbps, VPN throughput: 200 Mbps, Advanced security throughput: 300 Mbps |
| Ports Qty | 10 | 10 | — | — |
| Remote Management Protocol | — | — | HTTP | — |
| Routing Protocol | Static IP routing, MPLS | Static IP routing, MPLS | — | Static IP routing, MPLS |
| Environmental Parameters | ||||
| Humidity Range Operating | 5 - 95% (non-condensing) | 5 - 95% (non-condensing) | 5 - 95% (non-condensing) | 5 - 95% (non-condensing) |
| Max Operating Temperature | 40 °C | 40 °C | 40 °C | 45 °C |
| Min Operating Temperature | 0 °C | 0 °C | 0 °C | 0 °C |
| Connections & Expansion | ||||
| Interfaces | 2 x 1000Base-T - RJ-45 (WAN), 1 x 1000Base-T - SFP, 8 x 1000Base-T - RJ-45, 2 x 1000Base-T (PoE) - RJ-45, 1 x USB 2.0 - Type A | 2 x 1000Base-T - RJ-45 (WAN), 8 x 1000Base-T - RJ-45, 2 x 1000Base-T (PoE+) - RJ-45, 1 x USB 2.0 - Type A | 2 x 10Gb Ethernet - SFP+ (WAN), 8 x 1000Base-T - RJ-45, 8 x - SFP (mini-GBIC), 8 x 10Gb Ethernet - SFP+, 1 x USB - Type A | 4 x 1000Base-T - RJ-45, 1 x 1000Base-T - RJ-45 (WAN), 1 x USB 2.0 - Type A |
| Manufacturer Warranty | ||||
| Service & Support | Limited warranty - advance hardware replacement - lifetime - response time: next day | Limited warranty - advance hardware replacement - lifetime - response time: next day | Limited warranty - lifetime - response time: next day | Limited warranty - advance hardware replacement - lifetime - response time: next day |
