Product Comparison
Technical Specifications
Feature
General
Authentication Method
Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2)
—
RADIUS, TACACS+, Secure Shell v.2 (SSH2), Secure Shell (SSH)
RADIUS
Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2)
Capacity
Switched virtual interfaces (SVIs): 16 ARP entries: 1024 IPv4 routes (Unicast): 512 IPv6 routes (Unicast): 512 IGMP groups: 512 MLD groups: 512 IPv4 ACL entries (ingress): 256 IPv6 ACL entries (ingress): 128 MAC ACL entries (ingress): 256
—
Packet buffer size: 8 MB
Link aggregation ports: 8 IPv4 routes (static): 32 VLANs supported: 256 Access Control Entries (ACEs) per ACL: 480 Packet buffer size: 1.5 MB
Switched virtual interfaces (SVIs): 16 ARP entries: 1024 IPv4 routes (Unicast): 512 IPv6 routes (Unicast): 512 IGMP groups: 512 MLD groups: 512 IPv4 ACL entries (ingress): 256 IPv6 ACL entries (ingress): 128 MAC ACL entries (ingress): 256
Compliant Standards
IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s, IEEE 802.3az
—
IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3ad (LACP), IEEE 802.1D, IEEE 802.1w, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1ab (LLDP), IEEE 802.1x
IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.2af
IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s, IEEE 802.3at, IEEE 802.3az
Device Type
Switch - 52 ports - Managed - stackable
—
Switch - 48 ports - L3 - Managed - stackable
Switch - 52 ports - L3 - Managed
Switch - 24 ports - Managed - stackable
Enclosure Type
Side to side airflow rack-mountable 1U
—
Front and side to back rack-mountable 1U
Rack-mountable 1U
Side to side airflow rack-mountable 1U
Encryption Algorithm
SSL
—
FIPS 140-2, SSL
SSL
SSL
Features
Flow control, BOOTP support, ARP support, VLAN support, DiffServ support, IPv6 support, SNTP support, sFlow, MSTP support, TFTP support, MLD snooping, LACP support, LLDP support, port based access control, DHCP client, Energy Efficient Ethernet, MIB, NAC, NDP, SNMP support, ICMP, EntityMIB, DNS client, LLDP-MED, UDP, RSTP, IPv6 addressing
—
UTM, UDLD, VRRP support, DWRR, CoS, ToS, EQS, RPVST+, BPDU, Address Resolution Protocol, LLDP, TPM
Flow control, DHCP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, IPv6 support, half duplex mode, full duplex mode, STP support, MSTP support, ACL support, QoS, TPM, LLDP support, LACP, Energy Efficient Ethernet, CoS, BPDU Filter, PoE Class 4
Flow control, BOOTP support, ARP support, VLAN support, DiffServ support, IPv6 support, SNTP support, sFlow, MSTP support, TFTP support, ACL support, MLD snooping, TPM, fanless, LACP support, LLDP support, DHCP client, MIB, NDP, SNMP support, ICMP, DNS client, LLDP-MED, UDP, RSTP, IPv6 addressing
Flash Memory
16 GB
—
16 GB
256 MB
16 GB
Jumbo Frame Support
—
—
9220 bytes
9216 bytes
9198 bytes
MAC Address Table Size
8192 entries
—
32768 entries
16000 entries
8192 entries
Max Units In A Stack
—
—
8
—
—
Performance
Switching capacity: 176 Gbps Throughput: 98.6 Mpps Latency (1 Gbps): 1.9 µs Latency (10 Gbps): 1.8 µs
—
Latency (1 Gbps): 2.28 µs, Latency (10 Gbps): 1.46 µs
Switching capacity: 176 Gbps Throughput: 130.95 Mpps Latency (1 Gbps): 2.2 µs Latency (10 Gbps): 1.2 µs
Packet buffer size: 12.38 MB Throughput: 41.6 Mpps Switching capacity: 56 Gbps Latency (1 Gbps): 1.5 µs
PoE Budget
—
—
370 W
370 W
370 W
Ports
48 x 10/100/1000 + 4 x 1 Gigabit / 10 Gigabit SFP+
—
48 x 10/100/1000 (PoE+) + 4 x 1 Gigabit / 10 Gigabit SFP+ (uplink)
48 x 10/100/1000 (PoE) + 4 x 1 Gigabit / 10 Gigabit SFP+
24 x 10/100/1000 (PoE+) + 4 x Gigabit SFP
Power Over Ethernet (PoE)
—
—
PoE+
PoE
PoE
Processor
1 x ARM A9: 1.016 GHz
—
1 x ARM Cortex-A72: 1.8 GHz
1 x ARM: 800 MHz
1 x ARM A9: 1.016 GHz
RAM
4 GB DDR3 SDRAM
—
8 GB DDR4 SDRAM
512 MB SDRAM
—
Remote Management Protocol
—
—
RMON, CLI, MIB
SNMP 1, RMON, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, RADIUS
Remote Management Protocol
Routing Protocol
IGMPv2, IGMPv3
—
IGMP, IGMPv2, IGMPv3, RIP-2, OSPFv2, OSPFv3, MLD, MLDv2
Static IP routing
IGMPv2, IGMPv3
Status Indicators
—
—
—
Port status, power, PoE
—
Subtype
10 Gigabit Ethernet
—
Gigabit Ethernet
Gigabit Ethernet
Gigabit Ethernet
Power
Power Consumption Operational
20.6 Watt
—
—
460 Watt
32.7 Watt
Power Device
Internal power supply
—
Internal power supply
Internal power supply
Internal power supply
Power Provided
65 Watt 0.5 A
—
—
—
—
Voltage Required
AC 220 V (50/60 Hz)
—
—
AC 100-127/200-240 V (50/60 Hz)
AC 100-240 V (50/60 Hz)
Miscellaneous
Compliant Standards
FCC Class A certified, CISPR 24, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-3-3, Laser Class 1, UL 60950-1 Second Edition, EN 60825, VCCI Class A, EN 60825-1:2007, CAN/CSA C22.2 No. 60950 Second Edition, IEC 60825-1:2007 Class 1, EN 55022/CISPR 22 Class A, RFC1213, RFC1493, RFC2674, IEC/EN 60950-1, RFC768, RFC2460, RFC2925, RFC1591, RFC783, RFC792
—
EN 62368-1:2014+A11:2017, EN 62368-1:2020+A11:2020, UL 62368-1 Third Edition, CAN/CSA C22.2 No. 62368-1:19 Third Edition, IEC 62368-1: 2014 Second Edition, IEC 62368-1:2018 Third Edition, CNS 15598-1:2020, GB 4943.1-2022, KC 62368-1: 2021-08, EN 55032:2015 /A11:2020, Class A, EN 61000-3-2:2019, EN 61000-3-3:2013, FCC 47 CFR part 15B:2021 Class A, ICES-003 Issue 7: 2020 Class A, VCCI-CISPR 32 Class A, CISPR 32:2016 Class A, AS/NZS CISPR 32:2015 Class A, CNS 15936: 2020 Class A, KS C 9832, EN 60825-1:2014, IEC 60825-1:2014 Class 1, Laser Class 1, CISPR 35: 2016, EN 55035:2017+A11:2020, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11, EN 61000-3-2, EN 61000-3-3, IEC 61000-3-2, IEC 61000-3-3, EN 63000:2018, IEC 63000:2018
VCCI, CISPR 24, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-3-3, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60950-1, EN 60825-1, CNS 13438, EN 55024:2010, FCC CFR47 Part 15 A, ICES-003 issue 6 Class A, UL 62368-1 Second Edition, CISPR 32 Class A, EN 62368-1:2014, EN 55032:2015+AC:2016, CISPR 35, SSL, IEC 62368-1: 2014 Second Edition, EN 55035:2017
CISPR 24, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-3-3, UL 60950-1, IEC 60950-1, EN 60950-1, EN 60825-1, CAN/CSA C22.2 No. 60950, CNS 13438, FCC CFR47 Part 15 A, ICES-003 issue 6 Class A, UL 62368-1 Second Edition, CISPR 32 Class A, EN 62368-1:2014, VCCI-CISPR 32:2016 Class A, CISPR 35, EN 55035:2017, EN 55032:2015/AC:2016-07 Class A, EN55024:2010:A1, IEC 62368-1 Second Edition
Localisation
Localisation
—
English / United Kingdom
English / United Kingdom
English / United Kingdom
MTBF
—
—
—
57 years
—
Pricing Type
—
—
BTO
—
—
Service & Support
—
—
—
—
Limited warranty - lifetime
Weight & Dimensions
Depth
24.74 cm
—
30.43 cm
32.26 cm
26.82 cm
Height
4.39 cm
—
4.37 cm
4.39 cm
4.39 cm
Weight
3.42 kg
—
4.87 kg
4.52 kg
4.19 kg
Width
44.2 cm
—
44.25 cm
44.25 cm
44.2 cm
Environmental Parameters
Humidity Range Operating
15 - 95% (non-condensing)
—
5 - 95% (non-condensing)
15 - 95% (40 °C)
15 - 95% (non-condensing)
Humidity Range Storage
15 - 90% (non-condensing)
—
5 - 95% (non-condensing)
15 - 95% (60 °C)
15 - 90% (non-condensing)
Max Operating Temperature
45 °C
—
45 °C
40 °C
45 °C
Max Storage Temperature
—
—
70 °C
70 °C
—
Min Operating Temperature
0 °C
—
0 °C
0 °C
0 °C
Min Storage Temperature
—
—
-40 °C
-40 °C
—
Connections & Expansion
Interfaces
24 x 10/100/1000 Base-T RJ-45 4 x 1/10Gbit LAN SFP+ 1 x USB-C console 1 x USB Type A
—
48 x 10/100/1000 Base-T RJ-45 PoE+ - 30 W, 4 x 100/1000/10G SFP+ uplink, 1 x USB-C console, 1 x console RJ-45, 1 x management, 1 x USB Type A host
48 x 10/100/1000 Base-T RJ-45 PoE - 370 W, 4 x 1/10Gbit LAN SFP+
24 x 10/100/1000 Base-T RJ-45 PoE Class 4 - 370 W 4 x Gigabit LAN SFP 1 x USB Type A 1 x USB-C console
Manufacturer Warranty
Service & Support
Limited warranty - lifetime
—
Limited warranty - lifetime
Limited warranty - lifetime
—
