Product Comparison
Technical Specifications
Feature
General
Authentication Method
RADIUS, TACACS+
—
RADIUS, TACACS+, Secure Shell v.2 (SSH2), Secure Shell (SSH)
RADIUS
Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2)
Capacity
Switched virtual interfaces (SVIs): 128 IPv4 host table capacity: 8000 IPv6 host table capacity: 8000 IPv4 routes (Unicast): 2000 IPv6 routes (Unicast): 2000 IGMP groups: 1000 MLD groups: 1000 IPv4 ACL entries (ingress): 1000 IPv6 ACL entries (ingress): 1000 MAC ACL entries (ingress): 1000 IPv4 ACL entries (egress): 512 IPv6 ACL entries (egress): 256 MAC ACL entries (egress): 512
—
Packet buffer size: 8 MB
Link aggregation ports: 8 IPv4 routes (static): 32 VLANs supported: 256 Access Control Entries (ACEs) per ACL: 480 Packet buffer size: 1.5 MB
Switched virtual interfaces (SVIs): 16 ARP entries: 1024 IPv4 routes (Unicast): 512 IPv6 routes (Unicast): 512 IGMP groups: 512 MLD groups: 512 IPv4 ACL entries (ingress): 256 IPv6 ACL entries (ingress): 128 MAC ACL entries (ingress): 256
Compliant Standards
IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at
—
IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3ad (LACP), IEEE 802.1D, IEEE 802.1w, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1ab (LLDP), IEEE 802.1x
IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.2af
IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s, IEEE 802.3at, IEEE 802.3az
Device Type
Switch - 12 ports - L3 - Managed - stackable
—
Switch - 48 ports - L3 - Managed - stackable
Switch - 52 ports - L3 - Managed
Switch - 24 ports - Managed - stackable
Enclosure Type
Rack-mountable 1U
—
Front and side to back rack-mountable 1U
Rack-mountable 1U
Side to side airflow rack-mountable 1U
Encryption Algorithm
MD5, SSL, FIPS 140-2
—
FIPS 140-2, SSL
SSL
SSL
Features
Layer 2 switching, ARP support, DiffServ support, VRRP support, QoS, TPM, ECMP, UDLD, fanless, DWRR, MIB, CoS, ToS, BPDU, SSM, NTP, security slot (Kensington security lock compatible), RPVST+, DNS support, IGMP support, UDLD, Auto MDIX, web GUI management portal, UTM, EQS
—
UTM, UDLD, VRRP support, DWRR, CoS, ToS, EQS, RPVST+, BPDU, Address Resolution Protocol, LLDP, TPM
Flow control, DHCP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, IPv6 support, half duplex mode, full duplex mode, STP support, MSTP support, ACL support, QoS, TPM, LLDP support, LACP, Energy Efficient Ethernet, CoS, BPDU Filter, PoE Class 4
Flow control, BOOTP support, ARP support, VLAN support, DiffServ support, IPv6 support, SNTP support, sFlow, MSTP support, TFTP support, ACL support, MLD snooping, TPM, fanless, LACP support, LLDP support, DHCP client, MIB, NDP, SNMP support, ICMP, DNS client, LLDP-MED, UDP, RSTP, IPv6 addressing
Flash Memory
16 GB
—
16 GB
256 MB
16 GB
Jumbo Frame Support
9198 bytes
—
9220 bytes
9216 bytes
9198 bytes
MAC Address Table Size
32000 entries
—
32768 entries
16000 entries
8192 entries
Max Units In A Stack
8
—
8
—
—
Performance
Switching capacity: 68 Gbps Throughput: 50.5 Mpps Latency (1 Gbps): 3.8 µs Latency (10 Gbps): 2.9 µs Packet buffer size: 12.38 MB Stacking bandwidth: 20 Gbps
—
Latency (1 Gbps): 2.28 µs, Latency (10 Gbps): 1.46 µs
Switching capacity: 176 Gbps Throughput: 130.95 Mpps Latency (1 Gbps): 2.2 µs Latency (10 Gbps): 1.2 µs
Packet buffer size: 12.38 MB Throughput: 41.6 Mpps Switching capacity: 56 Gbps Latency (1 Gbps): 1.5 µs
PoE Budget
139 W
—
370 W
370 W
370 W
Ports
12 x 10/100/1000 (PoE+) + 2 x 100/1000 (uplink) + 2 x 1 Gigabit / 10 Gigabit SFP+
—
48 x 10/100/1000 (PoE+) + 4 x 1 Gigabit / 10 Gigabit SFP+ (uplink)
48 x 10/100/1000 (PoE) + 4 x 1 Gigabit / 10 Gigabit SFP+
24 x 10/100/1000 (PoE+) + 4 x Gigabit SFP
Power Over Ethernet (PoE)
PoE+
—
PoE+
PoE
PoE
Processor
1 x ARM: 1.2 GHz
—
1 x ARM Cortex-A72: 1.8 GHz
1 x ARM: 800 MHz
1 x ARM A9: 1.016 GHz
RAM
8 GB DDR4 SDRAM
—
8 GB DDR4 SDRAM
512 MB SDRAM
—
Remote Management Protocol
SNMP, SNMP 3, SNMP 2c, CLI
—
RMON, CLI, MIB
SNMP 1, RMON, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, RADIUS
Remote Management Protocol
Routing Protocol
OSPF, RIP-2, OSPFv2, OSPFv3, ECMP
—
IGMP, IGMPv2, IGMPv3, RIP-2, OSPFv2, OSPFv3, MLD, MLDv2
Static IP routing
IGMPv2, IGMPv3
Status Indicators
—
—
—
Port status, power, PoE
—
Subtype
Gigabit Ethernet
—
Gigabit Ethernet
Gigabit Ethernet
Gigabit Ethernet
Power
Power Consumption Operational
28 Watt
—
—
460 Watt
32.7 Watt
Power Device
Internal power supply
—
Internal power supply
Internal power supply
Internal power supply
Voltage Required
AC 90-264 V (50/60 Hz)
—
—
AC 100-127/200-240 V (50/60 Hz)
AC 100-240 V (50/60 Hz)
Miscellaneous
Compliant Standards
EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-3-3, ICES-003 Class A, RoHS, Laser Class 1, WEEE, VCCI Class A, EN 50581:2012, IEC 60950-1:2005 + A1:2009 + A2:2013, DoE Level VI, CISPR 35, EN 60825-1:2014, IEC 62368-1: 2014 Second Edition, EN 61000-3-2:2019, IEC 60825-1:2014 Class 1, UL 62368-1 Third Edition, EN 61000-3-3:2013/A1:2019, IEC 62368-1:2018 Third Edition, EN 55035:2017+A11:2020, EN 62368-1:2014+A11:2017 2nd Ed., EN 62368-1:2020+A11:2020 3rd Ed., BS EN 62368-1:2020 + A11:2020 3rd Ed, CNS 15598-1:2020, CISPR 32 Ed 2.1: 2019 Class A, CISPR 35 Ed 1.0:2016, CSA 22.2 No.62368-1 Third Edition, EN 55032:2015 + A11:2020 Class A, FCC 47 CFR part 15B:2014 Class A
—
EN 62368-1:2014+A11:2017, EN 62368-1:2020+A11:2020, UL 62368-1 Third Edition, CAN/CSA C22.2 No. 62368-1:19 Third Edition, IEC 62368-1: 2014 Second Edition, IEC 62368-1:2018 Third Edition, CNS 15598-1:2020, GB 4943.1-2022, KC 62368-1: 2021-08, EN 55032:2015 /A11:2020, Class A, EN 61000-3-2:2019, EN 61000-3-3:2013, FCC 47 CFR part 15B:2021 Class A, ICES-003 Issue 7: 2020 Class A, VCCI-CISPR 32 Class A, CISPR 32:2016 Class A, AS/NZS CISPR 32:2015 Class A, CNS 15936: 2020 Class A, KS C 9832, EN 60825-1:2014, IEC 60825-1:2014 Class 1, Laser Class 1, CISPR 35: 2016, EN 55035:2017+A11:2020, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11, EN 61000-3-2, EN 61000-3-3, IEC 61000-3-2, IEC 61000-3-3, EN 63000:2018, IEC 63000:2018
VCCI, CISPR 24, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-3-3, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60950-1, EN 60825-1, CNS 13438, EN 55024:2010, FCC CFR47 Part 15 A, ICES-003 issue 6 Class A, UL 62368-1 Second Edition, CISPR 32 Class A, EN 62368-1:2014, EN 55032:2015+AC:2016, CISPR 35, SSL, IEC 62368-1: 2014 Second Edition, EN 55035:2017
CISPR 24, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-3-3, UL 60950-1, IEC 60950-1, EN 60950-1, EN 60825-1, CAN/CSA C22.2 No. 60950, CNS 13438, FCC CFR47 Part 15 A, ICES-003 issue 6 Class A, UL 62368-1 Second Edition, CISPR 32 Class A, EN 62368-1:2014, VCCI-CISPR 32:2016 Class A, CISPR 35, EN 55035:2017, EN 55032:2015/AC:2016-07 Class A, EN55024:2010:A1, IEC 62368-1 Second Edition
Included Accessories
Rack kit (2 post)
—
—
—
—
Localisation
English / United Kingdom
—
English / United Kingdom
English / United Kingdom
English / United Kingdom
MTBF
—
—
—
57 years
—
Pricing Type
—
—
BTO
—
—
Service & Support
—
—
—
—
Limited warranty - lifetime
Weight & Dimensions
Depth
30.5 cm
—
30.43 cm
32.26 cm
26.82 cm
Height
4.39 cm
—
4.37 cm
4.39 cm
4.39 cm
Weight
3.24 kg
—
4.87 kg
4.52 kg
4.19 kg
Width
25.4 cm
—
44.25 cm
44.25 cm
44.2 cm
Environmental Parameters
Humidity Range Operating
5 - 95% RH (non-condensing)
—
5 - 95% (non-condensing)
15 - 95% (40 °C)
15 - 95% (non-condensing)
Humidity Range Storage
5 - 95% RH (non-condensing)
—
5 - 95% (non-condensing)
15 - 95% (60 °C)
15 - 90% (non-condensing)
Max Operating Temperature
45 °C
—
45 °C
40 °C
45 °C
Max Storage Temperature
70 °C
—
70 °C
70 °C
—
Min Operating Temperature
0 °C
—
0 °C
0 °C
0 °C
Min Storage Temperature
-40 °C
—
-40 °C
-40 °C
—
OS Required
AOS-CX
—
—
—
—
Connections & Expansion
Interfaces
12 x 10/100/1000 Base-T RJ-45 PoE Class 4 2 x 1/10Gbit LAN SFP+ 2 x 1000Base-T 1 x console RJ-45 1 x console (USB) Type C 1 x USB Type A host
—
48 x 10/100/1000 Base-T RJ-45 PoE+ - 30 W, 4 x 100/1000/10G SFP+ uplink, 1 x USB-C console, 1 x console RJ-45, 1 x management, 1 x USB Type A host
48 x 10/100/1000 Base-T RJ-45 PoE - 370 W, 4 x 1/10Gbit LAN SFP+
24 x 10/100/1000 Base-T RJ-45 PoE Class 4 - 370 W 4 x Gigabit LAN SFP 1 x USB Type A 1 x USB-C console
Manufacturer Warranty
Service & Support
Limited warranty - lifetime
—
Limited warranty - lifetime
Limited warranty - lifetime
—
