Product Comparison
Technical Specifications
Feature
General
Built-in Devices
Led panel
Led panel
Led panel
Led panel
Led panel
Embedded Security
—
—
Trusted Platform Module (TPM 2.0) Security Chip
Trusted Platform Module (TPM) Security Chip
Trusted Platform Module (TPM) Security Chip
Hot-Swap Bays Qty
8
8
8
8
8
Localisation
Region: EMEA
Region: Europe
Region: EMEA
Region: Germany, Switzerland, Austria, France, United Kingdom, Scotland, Ireland
Region: Germany, Switzerland, Austria, France, United Kingdom, Ireland, Scotland
Product Form Factor
Rack-mountable - 1U
Rack-mountable - 1U
Rack-mountable - 2U
Rack-mountable - 2U
Rack-mountable - 1U
Server Scalability
1-way
2-way
2-way
2-way
2-way
Type
Server
Server
Server
Server
Server
Power
80 PLUS Certification
80 PLUS Titanium
—
80 PLUS Titanium
80 PLUS Titanium
80 PLUS Titanium
Device Type
Power supply - hot-plug
Power supply - hot-plug
Power supply - hot-plug
Power supply - hot-plug
Power supply - hot-plug
Installed Qty
2
1
2
2
2
Max Supported Qty
2
2
2
2
2
Power Provided
1000 Watt
1000 Watt
1000 Watt
1000 Watt
1000 Watt
Power Redundancy
Yes
Optional
Yes
Yes
Optional
Power Redundancy Scheme
1+1
1+1 (with optional power supply)
1+1
1+1
1+1 (with optional power supply)
Voltage Required
AC 100-120/200-240 V (50/60 Hz)
AC 100-120/200-240 V
AC 100-240 V (50/60 Hz)
—
AC 100-240 V
Network
Compliant Standards
—
—
—
OCP 3.0
—
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet, Fast Ethernet, Gigabit Ethernet
—
Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet Controller
Broadcom BCM5719
Broadcom BCM57416
—
Broadcom BCM5719
Broadcom BCM5719
Ethernet Ports
4 x Gigabit Ethernet
2 x 10 Gigabit Ethernet
—
4 x Gigabit Ethernet
4 x Gigabit Ethernet
Features
PXE support, Wake on LAN (WoL)
Wake on LAN (WoL), PXE support
—
Wake on LAN (WoL), PXE support
PXE support, Wake on LAN (WoL)
Interface (Bus) Type
Open Compute Project mezzanine (OCP) 3.0
Open Compute Project mezzanine (OCP) 3.0
—
Open Compute Project mezzanine (OCP) 3.0
Open Compute Project mezzanine (OCP) 3.0
Remote Management Controller
Integrated Lights-Out 6
Integrated Lights-Out 6
—
Integrated Lights-Out 6
Integrated Lights-Out 6
Remote Management Protocol
IPMI 2.0, SNMP 3
IPMI 2.0, SNMP 3
—
—
SNMP 3, SMASH CLP, IPMI 2.0
Cache Memory
Cache Per Processor
64 MB
64 MB
64 MB
30 MB
30 MB
Installed Size
L3 Cache - 64 MB
L3 Cache - 64 MB
L3 Cache - 64 MB
30 MB
L3 Cache - 30 MB
RAM
Configuration Features
2 x 32 GB
2 x 32 GB
2 x 32 GB
2 x 32 GB
2 x 32 GB
Effective Memory Speed
4800 MHz
2400 MHz
4800 MHz
4400 MHz
4400 MHz
Features
Registered, HPE SmartMemory, Online Spare Memory
HPE SmartMemory, registered
Registered, HPE SmartMemory, slots 13 - 24 are available in two-processor configuration only
HPE SmartMemory, registered, slots 17 - 32 are available in two-processor configuration only
HPE SmartMemory, registered
Form Factor
DIMM 288-pin
—
DIMM 288-pin
DIMM 288-pin
DIMM 288-pin
Installed Size
64 GB (installed) / 3 TB (max)
64 GB (installed) / 6 TB (max)
64 GB (installed) / 6 TB (max)
64 GB (installed) / 8 TB (max)
64 GB (installed) / 8 TB (max)
Rated Memory Speed
4800 MHz
2400 MHz
4800 MHz
5600 MHz
5600 MHz
Slots
12 (Total) / 10 (empty)
12 (Total) / 10 (empty)
24 (Total) / 22 (empty)
32 (Total) / 30 (empty)
32 (Total) / 30 (empty)
Technology
DDR5 SDRAM - Advanced ECC
DDR5 SDRAM - Advanced ECC
DDR5 SDRAM
DDR5 SDRAM
DDR5 SDRAM - Advanced ECC
Hard Drive
Capacity
—
—
2 x 480 GB
—
—
Interface Type
—
—
SATA
—
—
Type
—
—
SSD
—
—
Miscellaneous
Compliant Standards
AES, FIPS 140-2, Triple DES, IPv6 Ready, PCI DSS, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1, SMBIOS 3.1, Redfish API, ErP Lot 9, UEFI 2.7, UEFI Class 3, Active Directory v1.0, APML 1.0
WEEE, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, ACPI 6.1, UEFI, SMBIOS 3.1, Redfish API, AES, Triple DES
AES, FIPS 140-2, Triple DES, IPv6 Ready, PCI DSS, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1, SMBIOS 3.1, UEFI 2.7, Redfish API, APML 1.0, Active Directory v1.0
AES, TLS v1.2, ACPI 6.3, ASHRAE Class A3, ASHRAE Class A4, ErP Lot 9, WEEE 2002/95/EC, FIPS 140-2, low halogen, Triple DES, SMBIOS 3.2, Redfish API
ASHRAE Class A3, ASHRAE Class A4, TLS v1.2, AES, FIPS 140-2, IPv6 Ready, PCI DSS, WEEE 2002/95/EC, ACPI 6.4, ErP Lot 9
Included Accessories
7 x standard fans, HPE Easy Install Rail 2 Kit, HPE standard heatsink
5 x standard fans
6 x standard fans, HPE standard heatsink, HPE Easy Install Rail 2 Kit
HPE Easy Install Rails
5 x standard fans
Manufacturer Selling Program
HPE Smart Choice
HPE Smart Choice
HPE Smart Choice
HPE Smart Choice
HPE Smart Choice
Service & Support
—
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
—
—
—
Voltage Required
—
—
—
AC 100-240 V
—
Connections & Expansion
Bays
8 (total) / 6 (free) x hot-swap 2.5" SFF
8 (total) / 6 (free) x hot-swap 2.5" SFF
8 (total) / 6 (free) x hot-swap 2.5" SFF
1 (total) / 1 (free) x external Universal Media Bay 8 (total) / 8 (free) x hot-swap 2.5" SFF
1 (total) / 1 (free) x external Universal Media Bay 8 (total) / 6 (free) x hot-swap 2.5"
Interfaces
1 x HPE iLO (1 in front) (service port) 1 x HPE iLO - RJ-45 1 x VGA 4 x LAN (Gigabit Ethernet) 5 x USB 3.2 Gen 1 (1 front, 2 rear, 2 internal)
1 x HPE iLO (1 in front) (service port) 5 x USB 3.1 Gen 1 (1 front, 2 rear, 2 internal) 1 x VGA 4 x LAN (Gigabit Ethernet)
1 x HPE iLO (1 in front) (service port), 5 x USB 3.2 Gen 1 (1 front, 2 rear, 2 internal), 1 x VGA, 2 x LAN (1/10 Gigabit Ethernet)
1 x USB 3.0 (1 in front) (HPE iLO Service Port) 4 x USB 3.0 (2 rear, 2 internal) 1 x HPE iLO - RJ-45 (1 rear) 1 x VGA (1 rear) 4 x LAN (Gigabit Ethernet)
1 x HPE iLO - Type A (1 in front) 1 x HPE iLO - RJ-45 4 x USB 3.2 Gen 1 (1 front, 2 rear, 1 internal) 1 x VGA 4 x LAN (Gigabit Ethernet) 1 x USB 2.0
Slots
1 (total) / 1 (free) x PCIe 5.0 x16 - full-length, full-height (x16 mode)
1 (total) / 1 (free) x PCIe 5.0 x16 (x16 mode)
1 (total) / 1 (free) x PCIe 5.0 x16 (x16 mode)
2 (total) / 2 (free) x FlexibleLOM 1 (total) / 1 (free) x PCIe 5.0 x16 - full-length, full-height 1 (total) / 1 (free) x PCIe 5.0 x16 - full-length, full-height (x8 mode) 1 (total) / 1 (free) x PCIe 5.0 x16 - half-length, full-height (x8 mode)
2 (total) / 1 (free) x PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0 (x16 mode)
Storage Controller
Buffer Size
4 GB
4 GB
4 GB
4 GB
4 GB
Channel Qty
8
8
8
8
8
Controller Interface Type
Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)
Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)
—
Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)
Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60
—
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60
—
Storage Controller Name
HPE MR408i-o Gen11 SPDM
HPE MR408i-o Gen11 SPDM
—
HPE MR408i-o Gen11 SPDM
HPE MR408i-o Gen11 SPDM
Type
1 x RAID - OCP
1 x RAID - OCP
—
1 x RAID - OCP
1 x RAID - OCP
Hard drive
Capacity
2 x 480 GB
2 x 480 GB
—
2 x 960 GB
2 x 960 GB
Interface Type
SATA
SATA 6Gb/s
—
SATA
SATA
Type
SSD
SSD
—
SSD - 2.5"
SSD - 2.5"
Processor / Chipset
Chipset Type
—
—
—
Intel C741
Intel C741
Clock Speed
3 GHz
3 GHz
3 GHz
2.4 GHz
2.4 GHz
CPU
AMD EPYC 9124
AMD EPYC 9124
AMD EPYC 9124
Intel Xeon Silver 4510
Intel Xeon Silver 4510
CPU Qty
1
1
1
1
1
CPU Upgradability
Upgradable
Upgradable
Upgradable
Upgradable
Upgradable
Max CPU Qty
1
2
2
2
2
Max Turbo Speed
3.7 GHz
3.7 GHz
3.7 GHz
4.1 GHz
4.1 GHz
Number of Cores
16-core
16-core
16-core
12-core
12-core
Processor Main Features
—
—
—
—
Intel Turbo Boost Technology 2, Hyper-Threading Technology
Networking
Data Link Protocol
—
—
Gigabit Ethernet, 10 Gigabit Ethernet
—
—
Ethernet Controller
—
—
Broadcom BCM57416
—
—
Ethernet Ports
—
—
2 x 10 Gigabit Ethernet
—
—
Features
—
—
Wake on LAN (WoL), PXE support
—
—
Interface (Bus) Type
—
—
Open Compute Project mezzanine (OCP) 3.0
—
—
Remote Management Controller
—
—
Integrated Lights-Out 6
—
—
Remote Management Protocol
—
—
IPMI 2.0, SNMP 3
—
—
Weight & dimensions
Depth
64.94 cm
64.94 cm
—
72.7 cm
75.31 cm
Height
4.29 cm
4.29 cm
—
8.75 cm
4.29 cm
Shipping Depth
—
24.2 cm
—
—
—
Shipping Height
—
91.6 cm
—
—
—
Shipping Width
—
60 cm
—
—
—
Weight
12.56 kg
12.7 kg
—
16 kg
14.56 kg
Width
43.46 cm
44.89 cm
—
44.8 cm
43.46 cm
Weight & Dimensions
Depth
—
—
64.64 cm
—
—
Height
—
—
8.75 cm
—
—
Weight
—
—
16.78 kg
—
—
Width
—
—
43.47 cm
—
—
Sustainability
ENERGY STAR Certified
Yes
Yes
—
—
Yes
ENERGY STAR Version
4.0
3.0
4.0
—
3.0
Environmental Parameters
Humidity Range Operating
8 - 90% RH (non-condensing)
8 - 90% RH (non-condensing)
8 - 90% RH (non-condensing)
8 - 90% RH (non-condensing)
8 - 90% RH (non-condensing)
Max Operating Temperature
35 °C
35 °C
35 °C
35 °C
35 °C
Min Operating Temperature
10 °C
10 °C
10 °C
10 °C
10 °C
Monitor
Monitor Type
None
None
None.
None
None
Operating System / Software
OS Certified
CentOS, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, SuSE Linux Enterprise Server 12 SP3, Red Hat Enterprise Linux 7.4, Red Hat Enterprise Linux 7.5, VMware vSphere 6.5 (ESXi) Update 2, VMware vSphere 6.7 (ESXi)
—
—
Microsoft Windows Server, VMware ESXi, Red Hat Enterprise Linux, Canonical Ubuntu, Oracle Linux
—
OS Provided
—
No operating system
—
No operating system
No operating system
Software
HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download)
—
—
HPE Server UEFI
HPE Server UEFI
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
—
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Dimensions & Weight (Shipping)
Shipping Depth
91.6 cm
—
99.8 cm
—
—
Shipping Height
24.2 cm
—
27 cm
—
—
Shipping Weight
—
—
26.2 kg
—
—
Shipping Width
60 cm
—
60 cm
—
—
Storage controllers
Storage Controller Name
—
—
HPE MR408i-o Gen11 SPDM
—
—
Type
—
—
1 x RAID - OCP
—
—
Optical Storage
Type
No optical drive
No optical drive
No optical drive
No optical drive
No optical drive
Graphics Controller
Video Interfaces
VGA
VGA
VGA
VGA
VGA
Video Memory
16 MB
16 MB
16 MB
16 MB
16 MB
