Product Comparison

Technical Specifications

Feature
General
Built-in Devices
Led panel
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Trusted Platform Module (TPM 1.2) Security Chip
Front Accessible Bays Qty
1
Hot-Swap Bays Qty
8
Internal Bays Qty
4
Localisation
Region: United Kingdom
Product Form Factor
Tower - 4U
Ultra micro tower
Server Scalability
2-way
1-way
Type
Server
Server
Graphics
Video Interfaces
VGA, DisplayPort
Power
80 PLUS Certification
80 PLUS Titanium
Device Type
Power supply - hot-plug
Power supply
Installed Qty
2
Max Supported Qty
2
Power Provided
1000 Watt
180 Watt
Power Redundancy
Yes
Power Redundancy Scheme
1+1
Voltage Required
AC 100-120/200-240 V
AC 100-240 V (50/60 Hz)
Network
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet Controller
Broadcom BCM5719
Ethernet Ports
4 x Gigabit Ethernet
4 x Gigabit Ethernet
Features
Wake on LAN (WoL), PXE support
Wake on LAN (WoL), ACPI support, PXE support
Interface (Bus) Type
Open Compute Project mezzanine (OCP) 3.0
Remote Management Controller
Integrated Lights-Out 6
Integrated Lights-Out 6
Remote Management Protocol
IPMI 2.0, SNMP 3, SMASH CLP
Cache Memory
Cache Per Processor
30 MB
6 MB
Installed Size
L3 Cache - 30 MB
6 MB
RAM
Configuration Features
2 x 32 GB
1 x 16 GB
Effective Memory Speed
4400 MHz
2400 MHz
Features
Registered, slots 17 - 32 are available in two-processor configuration only, HPE SmartMemory
HP SmartMemory, unbuffered
Form Factor
DIMM 288-pin
DIMM 288-pin
Installed Size
64 GB (installed) / 8 TB (max)
16 GB (installed) / 512 GB (max)
RAM Supported
512 GB registered - Advanced ECC Load-Reduced - Advanced ECC
Rated Memory Speed
5600 MHz
2400 MHz
Slots
32 (Total) / 30 (empty)
16 (Total) / 15 (empty)
Technology
DDR5 SDRAM - Advanced ECC
DDR5 SDRAM - Advanced ECC
Hard Drive
Capacity
2 x 960 GB
1 x 1 TB
Interface Type
SATA 6Gb/s
SATA 6Gb/s
Type
SSD
HDD
Miscellaneous
Compliant Standards
ACPI 6.1, ASHRAE Class A3, ASHRAE Class A4, FIPS 140-3, SMBIOS 3.1, UEFI 2.7, UEFI Class 3, Redfish API, AES, Triple DES, TLS v1.2, APML, ErP Lot 9
ACPI, FCC Class B certified, EN 61000-3-2, ICES-003, EN 61000-3-3, EN55024, CISPR 22, FCC CFR47 Part 15, WEEE, GB 9254, CNS 13438
Included Accessories
3 standard fans, HPE standard heatsink
Manufacturer Selling Program
HPE Smart Choice
HPE Smart Choice
Security Slot Type
Kensington security slot
Kensington security slot
Theft/Intrusion Protection
Padlock eye, security lock slot (cable lock sold separately)
Security lock slot (cable lock sold separately)
Connections & Expansion
Bays
8 (total) / 6 (free) x hot-swap 2.5" SFF
4 (total) / 3 (free) x internal 3.5" LFF
Interfaces
1 x VGA 1 x serial 4 x LAN (Gigabit Ethernet) 1 x HPE iLO - RJ-45 4 x USB 3.2 Gen 1 (1 front, 2 rear, 1 top) 1 x USB 2.0 (1 bottom) 1 x HPE iLO - Type A (1 in front)
1 x VGA 1 x DisplayPort 1.1a 4 x USB 3.2 Gen 1 - Type A (4 rear) 2 x USB 3.2 Gen 2 (2 in front) 4 x LAN (Gigabit Ethernet)
Slots
4 (total) / 4 (free) x PCIe 5.0 x16 (x8 mode)
1 (total) / 1 (free) x PCIe 5.0 x16 - low-profile 1 (total) / 1 (free) x PCIe 4.0 x8 - low-profile (x4 mode)
Storage Controller
Buffer Size
4 GB
Channel Qty
8
Controller Interface Type
Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)
RAID Level
RAID 0, RAID 1, RAID 5, RAID 10, RAID 50, RAID 60
RAID 0, RAID 1, RAID 5, RAID 10
Storage Controller Name
HPE MR408i-o Gen11 SPDM
Type
1 x RAID - OCP
SATA
Processor / Chipset
Chipset Type
Intel C741
Intel C262
Clock Speed
2.4 GHz
3.7 GHz
CPU
Intel Xeon Silver 4510
Intel Pentium Gold G7400
CPU Qty
1
1
CPU Socket
LGA4677 Socket-E
CPU Upgradability
Upgradable
Upgradable
L2 cache
2.5 MB
Max CPU Qty
2
1
Max Turbo Speed
4.1 GHz
Number of Cores
12-core
Dual-Core
Processor Main Features
Intel Turbo Boost Technology 2, Hyper-Threading Technology
Intel Turbo Boost Technology
Weight & Dimensions
Depth
71.2 cm
46.7 cm
Height
46.2 cm
25.54 cm
Weight
24.73 kg
7.97 kg
Width
17.4 cm
37.7 cm
Sustainability
ENERGY STAR Certified
Yes
Environmental Parameters
Humidity Range Operating
8 - 90% RH (non-condensing)
8 - 90% RH (non-condensing)
Max Operating Temperature
35 °C
35 °C
Min Operating Temperature
10 °C
10 °C
Monitor
Monitor Type
None
None
Operating System / Software
OS Certified
SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, Oracle Solaris
OS Provided
No operating system
Software
HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download)
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Limited warranty - parts and labour - 1 year - on-site
Optical Storage
Type
No optical drive
No optical drive
Graphics Controller
Video Interfaces
VGA
Video Memory
16 MB
