Technical Specifications
Feature
General
Device Type
—
—
—
—
Network adapter
Form Factor
—
—
—
—
Plug-in card
Interface (Bus) Type
—
—
—
—
M.2 2230 (CNVio3)
Miscellaneous
Compliant Standards
—
—
—
—
UL, cUL, CB 62368-1, FIPS 140-3
Encryption Algorithm
—
—
—
—
PEAP, WPA2, 128-bit AES-CCMP, EAP-SIM, EAP-AKA, WPA3-Enterprise, WPA3-Personal, 256-bit AES-GCMP, EAP-TLS, EAP-TTLS, MSCHAPv2
Networking
Compliant Standards
—
—
—
—
IEEE 802.11, IEEE 802.11b, IEEE 802.11a, IEEE 802.11d, IEEE 802.11g, IEEE 802.11i, IEEE 802.11h, IEEE 802.11e, IEEE 802.11n, IEEE 802.11k, IEEE 802.11ac, IEEE 802.11w, IEEE 802.11r, IEEE 802.11u, IEEE 802.11v, IEEE 802.11ax, Wi-Fi CERTIFIED 6, Wi-Fi CERTIFIED 6E, IEEE 802.11az, IEEE 802.11be, Wi-Fi CERTIFIED 7, Bluetooth 5.4
Connectivity Technology
—
—
—
—
Wireless
Data Link Protocol
—
—
—
—
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.4, IEEE 802.11be (Wi-Fi 7)
Data Transfer Rate
—
—
—
—
5.8 Gbps
Features
—
—
—
—
WMM support, UEFI support, Wi-Fi Direct, Wi-Fi Miracast ready, 802.1x authentication, 2x2 MU-MIMO technology, WMM Power Save, Wi-Fi Agile Multiband, wireless radio enable/disable, MLO, MRU
Frequency Band
—
—
—
—
2.4 GHz, 5 GHz, 6 GHz, 320 MHz
Line Coding Format
—
—
—
—
4096 QAM
Performance
—
—
—
—
Channel bandwidth: 320 mhz
Weight & Dimensions
Depth
—
—
—
—
3 cm
Height
—
—
—
—
2.2 cm
Weight
—
—
—
—
3.06 g
Width
—
—
—
—
0.242 cm
Environmental Parameters
Humidity Range Operating
—
—
—
—
50 - 90% RH (non-condensing)
Max Operating Temperature
—
—
—
—
50 °C
Min Operating Temperature
—
—
—
—
0 °C
Software / System Requirements
OS Required
—
—
—
—
Linux, Windows 10, Windows 11
