Technical Specifications

Memory
Internal memory
16 GB
Internal memory type
DDR4-SDRAM
Maximum internal memory
16 GB
Memory clock speed
2666 MHz
Display
Anti-glare screen
Yes
Display brightness
320 cd/m²
Display diagonal
25.6 cm (10.1")
Display resolution
1920 x 1200 pixels
HD type
WUXGA
Native aspect ratio
16:10
Touchscreen
Yes
Graphics
Discrete graphics card
No
Discrete graphics card model
Not available
On-board GPU manufacturer
Intel
On-board graphics card
Yes
On-board graphics card family
Intel® HD Graphics
On-board graphics card model
Intel® HD Graphics
Storage
Card reader integrated
No
Number of SSDs installed
1
NVMe
Yes
Optical drive type
No
SSD capacity
256 GB
SSD form factor
M.2
SSD interface
PCI Express 3.0
Storage media
SSD
Total SSDs capacity
256 GB
Total storage capacity
256 GB
Power
AC adapter frequency
50 - 60 Hz
AC adapter input voltage
100 - 240 V
AC adapter power
90 W
Network
Antenna type
2x2
Bluetooth
Yes
Bluetooth version
5.0
Ethernet LAN
Yes
Ethernet LAN data rates
100,1000 Mbit/s
Top Wi-Fi standard
Wi-Fi 5 (802.11ac)
Wi-Fi
Yes
Wi-Fi standards
Wi-Fi 5 (802.11ac)
WLAN controller manufacturer
Intel
WLAN controller model
Intel Dual Band Wireless-AC 9560
Technical details
Box contents
ThinkSmart One Cable (1.83m)
Camera
Built-in camera
No
Audio
Built-in microphone
Yes
Built-in speaker(s)
Yes
Number of speakers
4
RMS rated power
12 W
Design
Cable lock slot
Yes
Cable lock slot type
Kensington
Colour name
Black
Product colour
Black
Certificates
Certification
TÜV Rheinland Ultra Low Noise
Compliance certificates
RoHS
Ports & interfaces
Combo headphone/mic port
Yes
DisplayPorts quantity
1
Ethernet LAN (RJ-45) ports
1
HDMI ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
Weight & dimensions
Depth (with stand)
200 mm
Height (with stand)
185.3 mm
Weight (with stand)
2.45 kg
Width (with stand)
240 mm
Packaging content
Keyboard included
Yes
Mouse included
Yes
Performance
Motherboard chipset
Intel SoC
Product type
All-in-One PC
Trusted Platform Module (TPM)
Yes
Trusted Platform Module (TPM) version
2.0
Software
Operating system architecture
64-bit
Operating system installed
Windows 11 IoT Enterprise SAC
Processor
Processor boost frequency
4.1 GHz
Processor cache
6 MB
Processor cache type
Smart Cache
Processor cores
4
Processor family
Intel® Core™ i5
Processor frequency
1.6 GHz
Processor generation
8th gen Intel® Core™ i5
Processor manufacturer
Intel
Processor model
i5-8365UE
