Product Comparison

Technical Specifications

General
Aspect Ratio
16:9
Backlight Technology
WLED
Brightness
250 cd/m²
Built-in Devices
USB 3.2 Gen 1 hub
Colour
Raven black
Colour Gamut
99% BT.709, 99% sRGB
Colour Support
16.7 million colours
Contrast Ratio
1500:1 / 3000000:1 (dynamic)
Diagonal Size
24"
Dimensions (WxDxH)
53.98 cm x 19 cm x 50.58 cm - with stand (highest position)
Display Type
LED-backlit LCD monitor / TFT active matrix
Features
Integrated cable management, 8-bit Colour Depth, Natural Low Blue Light technology, modular camera support, ultra thin bezel design
Horizontal Refresh Rate
28 - 150 kHz
Horizontal Viewing Angle
178
Native Resolution
Full HD (1080p) 1920 x 1080 at 120 Hz
Panel Type
IPS
Pixel Per Inch
95
Pixel Pitch
0.2745 mm
Response Time
4 ms (extreme), 6 ms (normal)
Screen Coating
Anti-glare
Vertical Refresh Rate
48 - 120 Hz
Vertical Viewing Angle
178
Viewable Size
23.8"
Weight
5.1 kg
Display
Anti-glare screen
Yes
Yes
Backlight type
W-LED
W-LED
Colour depth
8 bit
Colour gamut
45%
99%
Colour gamut standard
NTSC
sRGB
Contrast ratio (dynamic)
3000000:1
3000000:1
Contrast ratio (typical)
1000:1
1000:1
Display brightness (typical)
250 cd/m²
250 cd/m²
Display diagonal
39.6 cm (15.6")
54.6 cm (21.5")
Display number of colours
16.7 million colours
16.7 million colours
Display resolution
1920 x 1080 pixels
1920 x 1080 pixels
Display technology
LED
LED
HD type
Full HD
Full HD
LED backlight
Yes
Maximum refresh rate
60 Hz
60 Hz
Native aspect ratio
16:9
16:9
NTSC coverage (typical)
45%
Panel type
IPS
IPS
Pixel density
141 ppi
102 ppi
Pixel pitch
0.1793 x 0.1793 mm
0.248 x 0.248 mm
Response time
14 ms
6 ms
Response time (fast)
6 ms
4 ms
Screen shape
Flat
Flat
sRGB coverage (typical)
99%
Touchscreen
No
No
Viewable size diagonal
19.4 cm
Viewable size, horizontal
47.6 cm
Viewable size, vertical
34.4 cm
26.8 cm
Viewing angle, horizontal
178°
178°
Viewing angle, vertical
178°
178°
Power
AC input frequency
50/60 Hz
AC input voltage
100 - 240 V
Energy consumption (SDR) per 1000 hours
8 kWh
Energy efficiency class (SDR)
C
Energy efficiency scale
A to G
European Product Registry for Energy Labelling (EPREL) code
550429
Input Voltage
AC 100-240 V (50/60 Hz)
Power consumption (max)
9.5 W
33 W
Power Consumption (Max)
66 Watt
Power Consumption (Off Mode)
0.3 Watt
Power consumption (off)
0.3 W
0.5 W
Power consumption (standby)
0.3 W
0.3 W
Power consumption (typical)
8 W
13.4 W
Power Consumption (Typical)
12 Watt
Power Consumption SDR (On mode)
12 kWh/1000h
Power Consumption Sleep
0.5 Watt
Power supply type
External
Network
Ethernet LAN
No
Miscellaneous
Cables Included
1 x DisplayPort cable - 1.8 m 1 x USB-A to USB-B cable - 1.8 m
Compliant Standards
RoHS, TUV Rheinland Flicker Free Certification, China Energy standard Tier 1, TUV Rheinland Low Blue Light (Hardware Solution), TÜV Rheinland Low Blue Light, Eyesafe Certified 2.0, TUV Rheinland Eye Comfort Certification (5-star)
Energy Class
Class C
Features
Security lock slot (cable lock sold separately), Tiny support
Localisation
English / United Kingdom
Security Slot Type
Kensington security slot
Ergonomics
Adjustable height (max)
1 cm
15.5 cm
Cable lock slot
Yes
Yes
Cable lock slot type
Kensington
Kensington
Cable management
Yes
Height adjustment
Yes
Yes
On Screen Display (OSD)
Yes
Yes
Panel mounting interface
100 x 100 mm
100 x 100 mm
Pivot
Yes
Pivot angle
-5 - 90°
Swivel angle range
-45 - 45°
Swivelling
Yes
Tilt adjustment
Yes
Tilt angle range
0 - 90°
-5 - 23.5°
VESA mounting
Yes
Yes
Performance
AMD FreeSync
No
Low Blue Light technology
Yes
NVIDIA G-SYNC
No
Weight & dimensions
Bezel width (bottom)
4.6 cm
Bezel width (side)
7.3 mm
2 mm
Bezel width (top)
2 mm
Depth (with stand)
108.4 mm
207.6 mm
Depth (without stand)
72.8 mm
Dimensions & Weight Details
Without stand - width: 53.98 cm - depth: 4.53 cm - height: 31.48 cm - weight: 3 kg With stand (highest position) - width: 53.98 cm - depth: 19 cm - height: 50.58 cm - weight: 5.1 kg With stand (lowest position) - width: 53.98 cm - depth: 19 cm - height: 35.08 cm - weight: 5.1 kg
Height (with stand)
235.5 mm
512.3 mm
Height (without stand)
339.1 mm
Weight (with stand)
860 g
5.5 kg
Weight (without stand)
3.2 kg
Width (with stand)
360 mm
489.3 mm
Width (without stand)
489.3 mm
Multimedia
Built-in camera
No
Yes
Built-in microphone
No
Yes
Built-in speaker(s)
No
Yes
Number of speakers
2
RMS rated power
6 W
Ports & interfaces
Built-in USB hub
Yes
Yes
Charging port type
USB Type-C
DisplayPort out quantity
0
DisplayPort version
1.2
DisplayPorts quantity
0
1
HDMI
No
Yes
HDMI ports quantity
0
1
HDMI version
1.4
Number of upstream ports
1
Number of USB Type-B upstream ports quantity
1
Number of USB Type-C upstream ports quantity
1
USB hub version
2.0 / 3.2 Gen 1 (3.1 Gen 1)
3.2 Gen 1 (3.1 Gen 1)
USB Type-A downstream ports quantity
1
USB Type-C DisplayPort Alternate Mode
Yes
USB Type-C downstream ports quantity
1
USB upstream port type
USB Type-C
USB Type-B
VGA (D-Sub) ports quantity
0
Packaging content
Cables included
AC
Power adapter included
Yes
Power cable length
1 m
Quick start guide
Yes
Stand included
Yes
Other features
Certification
ENERGY STAR CCC RoHS TÜV
EU Energy Label (D-class) ENERGY STAR® Certified EPEAT™ Gold Registered TCO Certified 9.0 TCO edge 2.0 Volatile Organic Compound Certification RoHS compliant Eyesafe Display 2.0, TÜV Low Blue Light (Hardware solution), TÜV Rheinland Eye Comfort
Compatible operating systems
Windows 10, Windows 11
Warranty period
3 year(s)
Design
Colour name
Raven Black
Product colour
Black
Black
Mechanical
Display Position Adjustments
Height, pivot (rotation), swivel, tilt
Height Adjustment
155 mm
Rotation Angle
180
Swivel Angle
90
Tilt Angle
-5/23.5
VESA Mounting Interface
100 x 100 mm
Sustainability
ENERGY STAR Certified
Yes
EPEAT Compliant
EPEAT Gold
TCO Certified
TCO Certified Edge Displays, TCO Certified, generation 10, for displays
Logistics data
Harmonized System (HS) code
85285210
Environmental Parameters
Humidity Range Operating
10 - 80% (non-condensing)
Max Operating Temperature
40 °C
Min Operating Temperature
0 °C
Software / System Requirements
Included Software
Lenovo ThinkColour
OS Required
Windows 10, Windows 11
Connectivity
Interfaces
USB-C 3.2 Gen 1 downstream (data, power up to 15W) 3 x USB 3.2 Gen 1 downstream USB-B 3.2 Gen 1 upstream HDMI DisplayPort 1.2 VGA
Packaging data
Package depth
75.9 mm
176 mm
Package height
279.9 mm
422 mm
Package weight
1.69 kg
8.1 kg
Package width
407.9 mm
568 mm
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Dimensions & Weight (Shipping)
Shipping Depth
11.2 cm
Shipping Height
42.2 cm
Shipping Weight
7.3 kg
Shipping Width
73.4 cm
