Product Comparison
Technical Specifications
General
Built-in Devices
3 x fans
6 x hot-swap fans
6 x fans
6 x fans
6 x hot-swap fans, 2 x rear fans
Front Accessible Bays Qty
4
24
10
24
—
Hot-Swap Bays Qty
4
24
10
24
6
Internal Bays Qty
4
24
10
24
8
Product Form Factor
Rack-mountable - 1U
Rack-mountable - 2U
Rack-mountable - 2U
Rack-mountable - 2U
Rack-mountable - 2U
Sensors
Temperature sensor, voltage sensor
Temperature sensor, voltage sensor
—
—
Temperature sensor, voltage sensor
Server Scalability
1-way
2-way
2-way
2-way
2-way
Type
Server
Server
Server
Server
Server
Power
80 PLUS Certification
80 PLUS Gold
80 PLUS Titanium
80 PLUS Titanium
80 PLUS Titanium
80 PLUS Titanium
Device Type
Power supply
Power supply
Power supply
Power supply
Power supply
Power Provided
300 Watt
2700 Watt
1300 Watt
2000 Watt
2700 Watt
Power Redundancy
—
Yes
Yes
Yes
Yes
Power Redundancy Scheme
—
1+1
1+1
1+1
1+1
Voltage Required
AC 100-240 V (50/60 Hz)
AC 100-127/200-240 V
AC 100-127/200-240 V
AC 100-127/200-240 V
AC 100-127/200-240 V
Network
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
—
—
—
—
Ethernet Controller
Realtek RTL8211F
—
—
—
—
Ethernet Ports
3 x Gigabit Ethernet
—
—
—
—
Remote Management Controller
Aspeed AST2600
—
—
—
—
Remote Management Protocol
IPMI 2.0
—
—
—
—
RAM
Effective Memory Speed
—
6000 MHz
6400 MHz
6400 MHz
6000 MHz
Installed Size
192 GB (max)
6144 GB (max)
8192 GB (max)
8192 GB (max)
6144 GB (max)
Rated Memory Speed
—
6000 MHz
6400 MHz
6400 MHz
6000 MHz
Slots
4 (Total) / 4 (empty)
24 (Total) / 24 (empty)
32 (Total) / 32 (empty)
32 (Total) / 32 (empty)
24 (Total) / 24 (empty)
Technology
DDR5 SDRAM
DDR5 SDRAM
DDR5 SDRAM
DDR5 SDRAM
DDR5 SDRAM
Hard Drive
Capacity
4
—
—
—
—
Interface Type
SATA 6Gb/s
PCI Express (NVMe) / U.2
SATA 6Gb/s / SAS 4.0 / PCI Express (NVMe)
SATA 6Gb/s / SAS 4.0 / PCI Express (NVMe)
PCI Express (NVMe) / U.2
Type
SSD - hot-swap
SSD - hot-swap
SSD - hot-swap
SSD - hot-swap
SSD - hot-swap
Miscellaneous
Compliant Standards
FCC SDOC Class A, DOC-A, CB, LVD, RCM, VCCI, BSMI, RoHS
FCC SDOC Class A, DOC-A, RoHS
FCC SDOC Class A, DOC-A, CB, LVD, RCM, VCCI, BSMI, NRTL, IC, sDoC, RoHS 2.0, RoHS
FCC SDOC Class A, DOC-A, CB, LVD, RCM, VCCI, BSMI, NRTL, IC, sDoC, RoHS 2.0, RoHS
FCC SDOC Class A, DOC-A, RoHS
Front Accessible Bays Qty
—
—
—
—
8
Hard Drive (2nd)
Capacity
2
—
—
—
—
Features
NVM Express (NVMe)
—
—
—
—
Type
SSD - M.2
—
—
—
—
Processor / Chipset
CPU
No CPU
No CPU
No CPU
No CPU
No CPU
CPU Socket
Socket AM5
Socket SP5
LGA4710 Socket
LGA4710 Socket
Socket SP5
CPU Upgradability
Upgradable
Upgradable
Upgradable
Upgradable
Upgradable
Max CPU Qty
1
2
2
2
2
Motherboard Name
S8016GM2NR-1U
Tyan S8261GM2NE-2T
R520G6SB
R520G6SB
Tyan S8261GM2NE-2T
Networking
Data Link Protocol
—
Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet
Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet, Fast Ethernet, Gigabit Ethernet
10 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet Controller
—
Realtek RTL8211F
Realtek RTL8211F
Realtek RTL8211F
Intel X550-AT2, Realtek RTL8211F
Ethernet Ports
—
2 x 10 Gigabit Ethernet, 1 x Gigabit Ethernet
—
—
2 x 10 Gigabit Ethernet, 1 x Gigabit Ethernet
Remote Management Controller
—
Aspeed AST2600
Aspeed AST2600
Aspeed AST2600
Aspeed AST2600
Remote Management Protocol
—
IPMI 2.0
IPMI 2.0
IPMI 2.0
IPMI 2.0
Weight & Dimensions
Depth
40 cm
85 cm
77 cm
77 cm
85 cm
Height
4.32 cm
8.7 cm
8.7 cm
8.7 cm
8.7 cm
Width
43.85 cm
44.8 cm
43.8 cm
43.8 cm
44.8 cm
Graphics Controller
Graphics Processor
ASPEED AST2600
ASPEED AST2600
ASPEED AST2600
ASPEED AST2600
ASPEED AST2600
Video Interfaces
VGA
VGA
Mini DisplayPort
Mini DisplayPort
VGA
Environmental Parameters
Humidity Range Operating
90% (non-condensing)
90% (non-condensing)
5 - 95% (non-condensing)
5 - 95% (non-condensing)
90% (non-condensing)
Max Operating Temperature
35 °C
35 °C
35 °C
35 °C
35 °C
Min Operating Temperature
10 °C
10 °C
10 °C
10 °C
10 °C
Connections & Expansion
Interfaces
1 x USB 3.1 Gen 1 4 x USB 3.2 Gen 1 3 x VGA - DB-15 3 x LAN (Gigabit Ethernet) - RJ-45
4 x USB 3.2 Gen 1 (2 front, 2 rear), 1 x VGA - DB-15, 2 x LAN (10Gigabit Ethernet) - RJ-45, 1 x LAN (Gigabit Ethernet) - RJ-45
1 x USB 3.0, 1 x Mini DisplayPort, 1 x LAN (Gigabit Ethernet) - RJ-45
1 x USB 3.0, 1 x Mini DisplayPort, 1 x LAN (Gigabit Ethernet) - RJ-45
4 x USB 3.2 Gen 1 (2 front, 2 rear), 1 x VGA - DB-15, 2 x LAN (10Gigabit Ethernet) - RJ-45, 1 x LAN (Gigabit Ethernet) - RJ-45
Slots
1 PCIe 5.0 x16
4 PCIe 5.0 x16
2 PCIe 5.0 x16, 2 Open Compute Project mezzanine (OCP) 3.0 (Mezzanine)
5 PCIe 5.0 x16, 2 Open Compute Project mezzanine (OCP) 3.0 (Mezzanine)
6 PCIe 5.0 x16
Monitor
Monitor Type
None
None.
None.
None.
None.
Operating System / Software
OS Provided
No operating system
No operating system
No operating system
No operating system
No operating system
Dimensions & Weight (Shipping)
Shipping Weight
—
—
34.5 kg
34.5 kg
—
Optical Storage
Type
No optical drive
No optical drive
No optical drive
No optical drive
No optical drive
