Compare Netgear Hubs & Switches
Comparing 5 products side-by-side — specifications, pricing and stock. Showing Netgear products in the Hubs & Switches category.
| Specification | Netgear NETGEAR AV Line M4250-9G1F-PoE+ - Switch - L3 - Managed - 8 x 10/100/1000 (8 PoE+) + 1 x 10/100/1000 + 1 x Gigabit SFP - side to side airflow - desktop - PoE+ (110 W)GSM4210PD-100EUS £618.88 £742.66 inc VAT | Netgear NETGEAR Smart GS752TPP - V3 - switch - L3 Lite - smart - 48 x 10/100/1000 (PoE+) + 4 x Gigabit SFP - rack-mountable - PoE+ (760 W)GS752TPP-300EUS £704.27 £845.12 inc VAT | Netgear NETGEAR GS324P - Switch - unmanaged - 16 x 10/100/1000 (PoE+) + 8 x 10/100/1000 - rack-mountable, desktop - PoE+ (190 W)GS324P-100EUS £220.49 £264.59 inc VAT | Netgear NETGEAR GS308PP - Switch - unmanaged - 8 x 10/100/1000 (PoE+) - desktop, wall-mountable - PoE+ (83 W) - DC powerGS308PP-100EUS £92.60 £111.12 inc VAT | |
|---|---|---|---|---|---|
| General | |||||
| Capacity | VLANs supported: 64 IP multicast groups: 128 | — | — | — | — |
| Device Type | Switch - 8 ports - L3 - smart | — | — | — | — |
| Enclosure Type | Desktop, wall-mountable | — | — | — | — |
| Features | QoS, VLAN management, LED status indicators, fanless, VLAN support, EEE, security slot (Kensington security lock compatible), VoIP support, web GUI management portal, DoS protection, loop prevention, rate limit, port mirroring, metal housing, uninterrupted PoE, WRR queuing, Link Aggregation, port trunking, port-based VLAN, IGMP snooping, IGMP snooping v2, IGMP snooping v3, DHCP client, DSCP Marking, ToS, full duplex capability, flow control, store and forward | — | — | — | — |
| Jumbo Frame Support | 9216 bytes | — | — | — | — |
| MAC Address Table Size | 4K entries | — | — | — | — |
| Performance | Packet buffer size: 1.5 MB Bandwidth: 16 Gbps | — | — | — | — |
| PoE Budget | 62 W | — | — | — | — |
| Ports | 8 x 10/100/1000 (PoE+) | — | — | — | — |
| Power Over Ethernet (PoE) | PoE+ | — | — | — | — |
| Routing Protocol | Static IP routing, IGMP, IGMPv2, IGMPv3 | — | — | — | — |
| Status Indicators | Power, PoE max, link/activity/speed, PoE | — | — | — | — |
| Subtype | Gigabit Ethernet | — | — | — | — |
| Power | |||||
| AC input frequency | — | 50 - 60 Hz | — | 50 - 60 Hz | — |
| AC input voltage | — | 220 - 240 V | — | 100 - 240 V | — |
| DC input voltage | — | — | — | — | 54 V |
| Electric Current Required | 1.25 A | — | — | — | — |
| Input current | — | — | — | 3 A | 1.66 A |
| Power consumption (max) | — | — | 861 W | 210 W | 87.9 W |
| Power consumption (typical) | — | — | 49 W | — | — |
| Power Consumption Operational | 6 Watt | — | — | — | — |
| Power Device | External power adapter | — | — | — | — |
| Power source | AC/DC | AC/DC | AC | — | — |
| Power supply included | — | Yes | — | — | — |
| Voltage Required | DC 54 V | — | — | — | — |
| Network | |||||
| 10G support | — | — | — | No | No |
| Auto MDI/MDI-X | — | — | — | Yes | Yes |
| Auto-negotiation | — | — | — | Yes | Yes |
| Auto-sensing | — | — | — | — | Yes |
| Broadcast storm control | — | Yes | — | — | — |
| Flow control support | Yes | — | — | — | Yes |
| Full duplex | — | Yes | — | Yes | Yes |
| IPv4 routes | — | — | 32 | — | — |
| IPv6 routes | — | — | 32 | — | — |
| Link aggregation | — | Yes | — | — | — |
| Networking standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3az | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3x | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3x | IEEE 802.1p, IEEE 802.3at | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
| Number of VLANs | 64 | — | 256 | — | — |
| Port mirroring | Yes | — | — | — | — |
| Port trunking | Yes | — | — | — | — |
| Rate limiting | Yes | Yes | — | — | — |
| Spanning tree protocol | — | Yes | — | — | — |
| Virtual LAN features | Port-based VLAN | — | — | — | — |
| VLAN support | Yes | — | Yes | — | — |
| Security | |||||
| Access Control List (ACL) | — | Yes | Yes | — | — |
| Access Control List (ACL) IPv4 entries | — | — | 100 | — | — |
| Authentication | — | MAC-based authentication | — | — | — |
| Authentication type | — | RADIUS | — | — | — |
| BPDU filtering/protection | — | Yes | — | — | — |
| DHCP features | DHCP client | DHCP Option 82, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 relay, DHCPv6 server, DHCPv6 snooping | DHCP snooping, DHCPv6 client | — | — |
| IGMP snooping | Yes | Yes | — | — | — |
| Loop protection | — | Yes | — | — | — |
| Password protection | Yes | — | — | — | — |
| Queue scheduling algorithms | Priority queuing (PQ), Strict Priority Queue (SPQ), Weighted Round Robin (WRR) | — | — | Weighted Round Robin (WRR) | — |
| SSH/SSL support | — | Yes | — | — | — |
| Management features | |||||
| ARP inspection | — | — | Yes | — | — |
| Quality of Service (QoS) support | Yes | Yes | — | Yes | Yes |
| Switch layer | L2/L3 | L2/L3 | L2/L3/L4 | — | — |
| Switch type | Managed | Managed | Managed | Unmanaged | Unmanaged |
| Other features | |||||
| Bandwidth | 16 Gbit/s | — | — | — | — |
| Connectivity technology | Wired | — | — | — | — |
| Networking features | Ethernet, Fast Ethernet, Gigabit Ethernet | — | — | — | — |
| Power requirements | 100 - 240 VAC | — | — | — | — |
| Ports & interfaces | |||||
| Basic switching RJ-45 Ethernet ports quantity | 8 | 8 | 48 | 24 | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) | Gigabit Ethernet (10/100/1000) | Gigabit Ethernet (10/100/1000) | Gigabit Ethernet (10/100/1000) | Gigabit Ethernet (10/100/1000) |
| Installed SFP modules quantity | — | 0 | 4 | 0 | — |
| Installed SFP+ modules quantity | — | 0 | — | 0 | — |
| Power connector | — | — | — | — | DC-in jack |
| USB Type-A ports quantity | — | — | 1 | — | — |
| Performance | |||||
| Built-in processor | — | Yes | Yes | — | — |
| Flash memory | — | — | 64 MB | — | — |
| Internal memory | — | 2048 MB | 512 MB | — | — |
| Mean time between failures (MTBF) | 859126 h | — | 1296949 h | 1193574 h | 2752476 h |
| Noise level | — | 30.06 dB | 39.3 dB | — | — |
| Processor frequency | — | 1250 MHz | 800 MHz | — | — |
| Processor manufacturer | — | — | ARM | — | — |
| Processor model | — | ARM Cortex-A9 | ARM Cortex-A55 | — | — |
| Certificates | |||||
| Certification | CE, EN, FCC, VCCI | — | CE, FCC Class A, RCM, ICES Class A, VCCI, KC, BSMI, UKCA | CB, CE LVD, UL | CE Mark, FCC Part 15 Class A, IC Class A, RCM, VCCI, BSMI, KC |
| Compliance certificates | BSMI, CE, Federal Communications Commission (FCC), KC, VCCI | — | — | — | — |
| Weight & dimensions | |||||
| Depth | — | 140 mm | 310 mm | 206 mm | 102 mm |
| Height | — | 40 mm | 432 mm | 43 mm | 27 mm |
| Weight | 522 g | 967 g | 5.03 kg | 2.44 kg | 600 g |
| Width | — | 210 mm | 440 mm | 330 mm | 236 mm |
| Design | |||||
| Electromagnetic compatibility | — | — | — | CE, FCC 15 A, IC A, RCM, VCCI, KC | — |
| Form factor | — | — | — | 1U | — |
| Housing material | Metal | — | — | Metal | Metal |
| LED indicators | Activity, Link, PoE, Power, Speed, System | PoE, Power, Status | — | Activity, Link, PoE, Power, Speed | Activity, Link, PoE, Power, Speed |
| Number of fans | — | — | 3 fan(s) | 1 fan(s) | — |
| Product colour | Grey | Black | Grey | Black | Black |
| Rack mounting | — | Yes | Yes | Yes | Yes |
| Redundant fans support | — | — | Yes | — | — |
| Wall mountable | — | — | — | — | Yes |
| Logistics data | |||||
| Harmonized System (HS) code | — | — | — | 85176990 | 85176990 |
| Operational conditions | |||||
| Heat dissipation | — | 559.555 BTU/h | 2944.6 BTU/h | 718.2 BTU/h | 300.6 BTU/h |
| Non-operating altitude | — | 0 - 3000 m | — | — | — |
| Operating altitude | 0 - 3000 m | 0 - 3000 m | — | 0 - 3000 m | 0 - 3000 m |
| Operating relative humidity (H-H) | 0 - 90% | 0 - 90% | 0 - 90% | 10 - 90% | 0 - 90% |
| Operating temperature (T-T) | 0 - 40 °C | 0 - 50 °C | 0 - 50 °C | 0 - 45 °C | 0 - 40 °C |
| Storage relative humidity (H-H) | 0 - 95% | 0 - 95% | 0 - 95% | 10 - 95% | — |
| Storage temperature (T-T) | -20 - 70 °C | -20 - 70 °C | -20 - 70 °C | -20 - 70 °C | -20 - 70 °C |
| Multicast features | |||||
| IPv4 multicast entries | — | 2000 | — | — | — |
| Multicast support | — | Yes | Yes | — | — |
| Number of multicast groups filtered | 128 | — | 512 | — | — |
| Data transmission | |||||
| Jumbo frames | 9216 | — | — | 10000 | 9216 |
| Jumbo frames support | Yes | — | — | Yes | Yes |
| Latency (1 Gbps) | — | — | 4.411 µs | 4 µs | 3 µs |
| Latency (10-100 Mbps) | — | — | 9.617 µs | — | — |
| MAC address table | 4000 entries | 16000 entries | 16000 entries | 8000 entries | 4000 entries |
| Packet buffer memory | 1.5 MB | — | 1.5 MB | 0.192 MB | 0.192 MB |
| Packet forwarding rate (1 Gbps) | — | — | — | 1448000 pps | 1448000 pps |
| Store-and-forward | — | Yes | — | — | — |
| Supported data transfer rates | 10/100/1000 Mbps | — | — | — | — |
| Switching capacity | — | 24 Gbit/s | 104 Gbit/s | 48 Gbit/s | 16 Gbit/s |
| Packaging content | |||||
| Manual | — | Yes | — | — | — |
| User guide | — | Yes | — | — | — |
| Power over Ethernet (PoE) | |||||
| Power over Ethernet (PoE) | No | Yes | Yes | Yes | Yes |
| Power over Ethernet (PoE) power per port | — | 30 W | 760 W | 30 W | 30 W |
| Power over Ethernet (PoE) type supported | — | — | — | — | PoE+ |
| Power over Ethernet plus (PoE+) ports quantity | 8 | 8 | 48 | 16 | 8 |
| Total Power over Ethernet (PoE) budget | 62 W | 110 W | — | 190 W | 130 W |
