Compare APC Racking & Cabinets
Comparing 5 products side-by-side — specifications, pricing and stock. Showing APC products in the Racking & Cabinets category.
| Specification | |||||
|---|---|---|---|---|---|
| Power | |||||
| AC input frequency | 50 - 60 Hz | — | 50 - 60 Hz | 50 - 60 Hz | — |
| Load capacity | 22080 VA | — | 3680 VA | — | — |
| Maximum current | 32 A | — | 16 A | — | — |
| Maximum input current per phase | 32 A | — | 16 A | 30 A | — |
| Maximum power | 22000 W | — | 3680 W | — | — |
| Maximum total current draw per phase | — | — | 16 A | 30 A | — |
| Nominal input voltage | 400 V | — | 200-230 V | — | — |
| Nominal output voltage | 230 V | — | 208-230 V | — | — |
| Power protection features | Overload | — | — | — | — |
| Ports & interfaces | |||||
| AC outlet types | C13 coupler, C19 coupler | — | C13 coupler | — | — |
| AC outlets quantity | 42 AC outlet(s) | — | 8 AC outlet(s) | — | — |
| Input connection type | — | — | IEC-320 C20 | NEMA L6-30P | — |
| Output connections | 30 x IEC 320 C13 12 x IEC 320 C19 | — | — | 36x IEC 320 C13 6x IEC 320 C19 | — |
| Power plug | IEC309 | — | C20 coupler | — | — |
| Features | |||||
| Cable length | 1.83 m | — | 2.5 m | 3 m | — |
| Front door construction | — | Perforated | — | — | — |
| LED indicators | Yes | — | — | — | — |
| Material | — | Steel | — | — | — |
| Maximum weight capacity | — | 90 kg | — | — | — |
| Preassembled | — | Yes | — | — | — |
| Product colour | — | Black | — | — | Black |
| Rack capacity | — | 12U | — | — | — |
| Type | — | Wall mounted rack | — | — | — |
| Certificates | |||||
| Certification | EN 55022 A,EN 55024, EN 61000-3-2, EN 61000-3-3, FCC 15 A, ICES-003, VCCI A, VDE REACH: No SVHCs | — | cUL Listed, CE, CSA, EN 55022 Class A, EN 55024, EN 61000-3-2, EN 61000-3-3, GOST, IRAM, MIC, UL 60950, UL Listed, VDE, VCCI, REACH | CSA C22.2 No. 60950,IEC 60950,METI Denan,UL 60950-1,VDE RoHS,REACH | — |
| Compliance certificates | RoHS | — | RoHS | — | — |
| Weight & dimensions | |||||
| Depth | 51 mm | 600 mm | 108 mm | 44 mm | 107 mm |
| Height | 1829 mm | 620 mm | 44 mm | 1791 mm | 889 mm |
| Mounting depth (max) | — | 52.8 cm | — | — | — |
| Size (imperial) | — | 48.3 cm (19") | — | — | — |
| Weight | 8.72 kg | 19.2 kg | 2.27 kg | 6.84 kg | 2.18 kg |
| Width | 56 mm | 600 mm | 445 mm | 56 mm | 45 mm |
| Logistics data | |||||
| Harmonized System (HS) code | — | 85381000 | — | — | 85389099 |
| Total carbon footprint (kg of CO2e) | 57837.86 | — | 915.89 | 27252.29 | — |
| Management features | |||||
| Monitoring | Current, Power, Voltage | — | Current, Power, Voltage | — | — |
| Outlet control | — | — | Lock-out, Recycle, Turn off, Turn on | — | — |
| Design | |||||
| Mounting | Vertical | — | Horizontal/Vertical | — | — |
| PDU types | Metered | — | Metered, Switched | — | — |
| Product colour | Black | — | Black | Black | — |
| Rack capacity | 0U | — | 0U/1U | — | — |
| Operational conditions | |||||
| Non-operating altitude | 0 - 15000 m | — | 1 - 15000 m | — | — |
| Operating altitude | 0 - 3000 m | — | 0 - 3000 m | — | — |
| Operating relative humidity (H-H) | 5 - 95% | — | 0 - 95% | 5 - 95% | — |
| Operating temperature (T-T) | 0 - 55 °C | — | 0 - 45 °C | 5 - 45 °C | — |
| Storage relative humidity (H-H) | 5 - 95% | — | 0 - 95% | 5 - 95% | — |
| Storage temperature (T-T) | -25 - 65 °C | — | -25 - 65 °C | -25 - 65 °C | — |
| Packaging data | |||||
| Package depth | 112 mm | — | 343 mm | 107 mm | 848 mm |
| Package height | 2050 mm | — | 70 mm | 2000 mm | 163 mm |
| Package weight | 11.6 kg | — | 3.45 kg | 8.47 kg | 2.59 kg |
| Package width | 170 mm | — | 470 mm | 162 mm | 64 mm |
| Packaging content | |||||
| Packaging content | — | — | Installation Guide, Rack Mounting Brackets, User Manual | — | — |
| Technical details | |||||
| Total carbon footprint (kg of CO2e) | — | 70.33 | — | — | 7.86 |
