Product Comparison
Technical Specifications
General
Bundled Services
—
3 years Essential Protection Service Suite and Cloud Secure Edge for 1 year SIA-Basic (10 users) and 1 year SPA-Advanced (3 users)
—
—
—
Depth
13.5 cm
13.5 cm
—
—
—
Device Type
Security appliance
Security appliance
—
—
—
Height
3.5 cm
3.5 cm
—
—
—
Weight
820 g
830 g
—
—
—
Width
19 cm
19 cm
—
—
—
Power
Power Consumption Operational
16.84 Watt
—
—
—
—
Power Device
External power adapter
External power adapter
—
—
—
Power Provided
36 Watt
36 Watt
—
—
—
Voltage Required
AC 120/230 V (50/60 Hz)
AC 100-240 V (50/60 Hz)
—
—
—
Miscellaneous
Compliant Standards
FIPS 140-2 Level 2, ICSA Firewall certified, ICSA Antivirus, Common Criteria, FCC Class B certified, ICES Class B, EMC, LVD, RoHS, C-Tick, VCCI Class B, UL, cUL, TUV GS, CB, WEEE, REACH, BSMI, KCC, MSIP, CoC
FIPS 140-2 Level 2, ICSA Firewall certified, ICSA Antivirus, Common Criteria, FCC Class B certified, ICES Class B, EMC, LVD, RoHS, C-Tick, VCCI Class B, UL, cUL, TUV GS, CB, Mexico CoC, WEEE, REACH, BSMI, KCC, MSIP, ANATEL
—
—
—
MTBF
51.1 years
46 years
—
—
—
Pricing Type
—
SonicWall Promotional Tradeup
—
—
—
Networking
Authentication Method
RADIUS, LDAP, XAUTH authentication
RADIUS, LDAP, XAUTH authentication
—
—
—
Capacity
Virtual interfaces (VLANs): 64, SSL VPN licences: 1 (maximum 50), VPN tunnels (site-to-site): 50, IPSec VPN clients: 5 (maximum 200), SPI connections: 750000, DPI connections: 150000, DPI SSL connections: 25000, Single Sign-On (SSO) users: 1000, Manageable access points: 16
Virtual interfaces (VLANs): 128, SSL VPN licences: 2 (maximum 150), VPN tunnels (site-to-site): 150, IPSec VPN clients: 5 (maximum 200), SPI connections: 1000000, DPI connections: 250000, DPI SSL connections: 35000, Single Sign-On (SSO) users: 2500, Manageable access points: 32
—
—
—
Connectivity Technology
Wired
Wired
—
—
—
Data Link Protocol
Gigabit Ethernet
Gigabit Ethernet, 2.5 Gigabit Ethernet
—
—
—
Encryption Algorithm
DES, Triple DES, MD5, SHA-1, 128-bit AES, 192-bit AES, 256-bit AES
DES, Triple DES, MD5, SHA-1, 128-bit AES, 192-bit AES, 256-bit AES
—
—
—
Features
SD-WAN support, VLAN support, firewall protection, VPN support, NAT support, Quality of Service (QoS), DHCP server, DHCP relay, Deep Packet Inspection (DPI), content filtering, antivirus analysis, anti-spam protection, Stateful Packet Inspection (SPI), DoS attack prevention, IPv4 support, IPv6 support, Jumbo Frames support, VLAN trunking, port mirroring, bandwidth control, Common Access Card (CAC) reader support, NetFlow, PAT support, 3G/4G USB Dongle Support, Single Sign-On (SSO) support, Dead Peer Detection (DPD), IPSec NAT-Traversal (NAT-T), DDos attack prevention
SD-WAN support, VLAN support, firewall protection, VPN support, NAT support, Quality of Service (QoS), DHCP server, DHCP relay, Deep Packet Inspection (DPI), content filtering, antivirus analysis, anti-spam protection, Stateful Packet Inspection (SPI), DoS attack prevention, IPv4 support, IPv6 support, Jumbo Frames support, VLAN trunking, port mirroring, bandwidth control, Common Access Card (CAC) reader support, NetFlow, PAT support, 3G/4G USB Dongle Support, Single Sign-On (SSO) support, Dead Peer Detection (DPD), IPSec NAT-Traversal (NAT-T), DDos attack prevention
—
—
—
Form Factor
Desktop
Desktop
—
—
—
Network / Transport Protocol
TCP/IP, PPTP, UDP/IP, L2TP, ICMP/IP, IPSec, PPPoE, DHCP
TCP/IP, PPTP, UDP/IP, L2TP, ICMP/IP, IPSec, PPPoE, DHCP
—
—
—
Performance
Firewall throughput: 2 Gbps, Threat prevention throughput: 750 Mbps, Application throughput: 1 Gbps, IPS throughput: 1 Gbps, Anti-malware throughput: 750 Mbps, TLS/SSL inspection and decryption throughput: 300 Mbps, VPN throughput (IPSec): 750 Mbps, Connection rate: 6000 connections per second
Firewall throughput: 3.5 Gbps, Threat prevention throughput: 1.5 Gbps, Application throughput: 2 Gbps, IPS throughput: 2 Gbps, Anti-malware throughput: 1.5 Gbps, TLS/SSL inspection and decryption throughput: 600 Mbps, VPN throughput (IPSec): 1.5 Gbps, Connection rate: 12000 connections per second
—
—
—
Remote Management Protocol
SNMP 2, SNMP 3, HTTP, HTTPS, CLI, SSH
SNMP 2, SNMP 3, HTTP, HTTPS, CLI, SSH
—
—
—
Routing Protocol
OSPF, RIP-1, RIP-2, BGP, static IP routing, policy-based routing (PBR)
OSPF, RIP-1, RIP-2, BGP, static IP routing, policy-based routing (PBR)
—
—
—
Status Indicators
Link/activity, power, secure, SSD activity, test mode
Link/activity, power, secure, SSD activity, test mode
—
—
—
Environmental Parameters
Humidity Range Operating
5 - 95% (non-condensing)
5 - 95% (non-condensing)
—
—
—
Max Operating Temperature
40 °C
40 °C
—
—
—
Min Operating Temperature
0 °C
0 °C
—
—
—
Connections & Expansion
Interfaces
6 x 1000Base-T - RJ-45, 2 x 1000Base-T - RJ-45 (WAN), 2 x USB 3.0 - Type A, 1 x console - RJ-45
6 x 1000Base-T - RJ-45, 2 x 1000Base-T - RJ-45 (WAN), 2 x 2.5Gb Ethernet - SFP+, 2 x USB 3.0 - Type A, 1 x console - RJ-45
—
—
—
Software / System Requirements
OS Provided
SonicOS 7.0
SonicOS 7.0
—
—
—
Manufacturer Warranty
Service & Support
—
Limited warranty - 1 year
—
—
—
Dimensions & Weight (Shipping)
Shipping Weight
1.41 kg
1.43 kg
—
—
—
IP Telephony
VoIP Protocols
SIP, H.323 v3, H.323 v4, H.323 v1, H.323 v2, H.323 v5
SIP, H.323 v3, H.323 v4, H.323 v1, H.323 v2, H.323 v5
—
—
—
