Compare STARTECH Fibre Cables
Comparing 5 products side-by-side — specifications, pricing and stock. Showing STARTECH products in the Fibre Cables category.
| Specification | |||||
|---|---|---|---|---|---|
| Other features | |||||
| Attenuation (max) | — | 0.35 dB/km | — | 0.35 dB/km | 0.35 dB/km |
| Weight & dimensions | |||||
| Bending radius | — | 1 cm | — | 1 cm | 1 cm |
| Cable diameter | 3 mm | 2 mm | — | 2 mm | 2 mm |
| Weight | 139 g | — | 40 g | — | — |
| Features | |||||
| Cable length | 10 m | 5 m | 3 m | 3 m | 30 m |
| Cable type | — | — | — | LC/UPC | SC/UPC |
| Cladding diameter | 125 µm | 125 µm | 125 µm | 125 µm | 125 µm |
| Connector 1 | LC | LC | LC | LC | SC |
| Connector 1 gender | Male | Male | Male | Male | Female |
| Connector 2 | LC | SC | LC | LC | SC |
| Connector 2 gender | Male | Male | Male | Male | Male |
| Connector polish type | — | PC | — | UPC | — |
| Core diameter | 50 µm | 9 µm | 50 µm | 9 µm | 9 µm |
| Data transfer rate | 100 Gbit/s | 10 Gbit/s | 10 Gbit/s | 100 Gbit/s | 100 Gbit/s |
| Fiber mode structure | Multi-mode | Single-mode | Multi-mode | Single-mode | Single-mode |
| Fibre optic type | OM3 | OS2 | OM2 | OS2 | OS2 |
| Full duplex | Yes | Yes | Yes | — | — |
| Insertion loss | — | 0.3 dB | — | 0.3 dB | 0.3 dB |
| Jacket material | Low smoke zero halogen (LSZH) | Low smoke zero halogen (LSZH), Polypropylene | Low smoke zero halogen (LSZH) | Polypropylene, Low smoke zero halogen (LSZH) | Low smoke zero halogen (LSZH), Polypropylene |
| Product colour | Aqua colour | Yellow | Orange | Yellow | Yellow |
| Return loss | — | 55 dB | — | 55 dB | 55 dB |
| Wavelengths supported | 850 nm | 1260,1280,1300,1310,1383,1490,1550,1590,1600,1625 nm | — | 1260,1280,1300,1310,1383,1490,1550,1590,1600,1625 nm | 1260,1280,1300,1310,1383,1490,1550,1590,1600,1625 nm |
| Certificates | |||||
| Certification | CE | — | CE | — | — |
| Compliance certificates | REACH, RoHS | RoHS | REACH, RoHS | — | RoHS |
| Sustainability | |||||
| Doesn't contain | Halogen | — | Halogen | — | — |
| Sustainability compliance | — | Yes | — | — | Yes |
| Logistics data | |||||
| Harmonized System (HS) code | 85447000 | — | 85447000 | — | — |
| Master (outer) case height | 314 mm | 280 mm | — | 280 mm | 280 mm |
| Master (outer) case length | 478 mm | 380 mm | — | 380 mm | 380 mm |
| Master (outer) case width | 352 mm | 380 mm | — | 380 mm | 380 mm |
| Products per master (outer) case | 80 pc(s) | 400 pc(s) | — | 380 pc(s) | 64 pc(s) |
| Operational conditions | |||||
| Operating temperature (T-T) | -20 - 60 °C | -20 - 60 °C | -20 - 60 °C | -20 - 60 °C | -20 - 60 °C |
| Storage temperature (T-T) | -20 - 60 °C | -20 - 60 °C | -20 - 60 °C | -20 - 60 °C | -20 - 60 °C |
| Packaging data | |||||
| Package depth | 220 mm | 220 mm | 200 mm | 200 mm | 220 mm |
| Package height | 28 mm | 3 mm | 224 mm | 2 mm | 12 mm |
| Package weight | 148 g | 46.5 g | — | 19.2 g | 112.5 g |
| Package width | 200 mm | 200 mm | 8 mm | 220 mm | 200 mm |
| Packaging content | |||||
| Quantity per pack | 1 pc(s) | 1 pc(s) | — | 1 pc(s) | 1 pc(s) |
