Compare STARTECH Fibre Cables
Comparing 5 products side-by-side — specifications, pricing and stock. Showing STARTECH products in the Fibre Cables category.
| Specification | |||||
|---|---|---|---|---|---|
| Other features | |||||
| Attenuation (max) | 0.35 dB/km | — | — | — | — |
| Weight & dimensions | |||||
| Bending radius | 1 cm | — | 7.5 mm | — | — |
| Cable diameter | 2 mm | — | 1.6 mm | — | — |
| Weight | — | 76 g | 31.8 g | 34 g | 140 g |
| Features | |||||
| Cable length | 15 m | 5 m | 1 m | 2 m | 10 m |
| Cable shape | — | — | Round | — | — |
| Cable type | LC/UPC | — | OFNR | — | — |
| Cladding diameter | 125 µm | 125 µm | 125 µm | 125 µm | 125 µm |
| Connector 1 | LC | LC | LC | LC | LC |
| Connector 1 gender | Male | Male | Male | Male | Male |
| Connector 2 | LC | ST | LC | LC | LC |
| Connector 2 gender | Male | Male | Male | Male | Male |
| Connector polish type | UPC | — | PC | — | — |
| Core diameter | 9 µm | 50 µm | 50 µm | 50 µm | 9 µm |
| Data transfer rate | 10 Gbit/s | 10 Gbit/s | 100 Gbit/s | 100 Gbit/s | 100 Gbit/s |
| Fiber mode structure | Single-mode | Multi-mode | Multi-mode | Multi-mode | Single-mode |
| Fibre optic type | OS2 | OM2 | OM4 | OM3 | OS1 |
| Full duplex | Yes | Yes | Yes | Yes | Yes |
| Insertion loss | 0.3 dB | — | — | — | — |
| Jacket material | Low smoke zero halogen (LSZH), Polypropylene | Low smoke zero halogen (LSZH) | Polyvinyl chloride (PVC) | Low smoke zero halogen (LSZH) | Low smoke zero halogen (LSZH) |
| Product colour | Yellow | Red | Violet | Turquoise | Yellow |
| Return loss | 55 dB | — | — | — | — |
| Wavelengths supported | 1260,1280,1300,1310,1383,1490,1550,1590,1600,1625 nm | — | 1300,850 nm | 850 nm | — |
| Certificates | |||||
| Certification | — | CE | — | — | — |
| Compliance certificates | CE | REACH, RoHS | RoHS, CE | RoHS | RoHS, CE |
| Sustainability | |||||
| Doesn't contain | — | Halogen | — | Halogen | — |
| Sustainability compliance | Yes | — | — | — | — |
| Logistics data | |||||
| Harmonized System (HS) code | — | 85447000 | — | 85447000 | 85447000 |
| Master (outer) case height | 280 mm | — | 270 mm | 325 mm | 403 mm |
| Master (outer) case length | 380 mm | — | 420 mm | 459 mm | 439 mm |
| Master (outer) case width | 380 mm | — | 420 mm | 416 mm | 407 mm |
| Products per master (outer) case | 80 pc(s) | — | 330 pc(s) | 240 pc(s) | 80 pc(s) |
| Operational conditions | |||||
| Operating temperature (T-T) | -20 - 60 °C | -20 - 60 °C | -20 - 60 °C | — | — |
| Storage temperature (T-T) | -20 - 60 °C | -20 - 60 °C | -20 - 60 °C | — | — |
| Packaging data | |||||
| Package depth | 220 mm | 220 mm | 180 mm | 220 mm | 220 mm |
| Package height | 12 mm | 20 mm | — | 13 mm | 25 mm |
| Package weight | 111.4 g | 100 g | 31.8 g | 43 g | 149 g |
| Package width | 200 mm | 200 mm | 230 mm | 200 mm | 200 mm |
| Packaging content | |||||
| Quantity per pack | 1 pc(s) | 1 pc(s) | 1 pc(s) | — | — |
