Compare STARTECH Racking & Cabinets
Comparing 5 products side-by-side — specifications, pricing and stock. Showing STARTECH products in the Racking & Cabinets category.
| Specification | STARTECH StarTech.com 2U Vented Server Rack Shelf, Center Mount 20in Deep Fixed Cantilever Tray, Rackmount Shelf for 19" AV/Data/Network Equipment w/ Cage Nuts & Screws, 200lbs Weight Capacity - 2U Network Rack Shelf - Rack shelf - black - 2U - 19"SHELF-2U-20-CENTER-V £67.72 £81.26 inc VAT | ||||
|---|---|---|---|---|---|
| Features | |||||
| Adjustable mounting rails | Yes | — | — | — | Yes |
| Back door construction | Mesh | — | — | — | — |
| Back door key lock | Yes | — | — | — | — |
| Cable management | Yes | — | — | — | Yes |
| Castor wheels | Yes | — | — | — | No |
| Certification | REACH | CE, REACH, TAA | — | CE, TAA, REACH | REACH, CE |
| Compliance industry standards | — | — | EIA/ECA-310-E | EIA RS310-D | — |
| Frame type | Closed | Open | — | — | Closed |
| Front door construction | Glass/Steel | — | — | — | Steel |
| Front door key lock | Yes | — | — | — | Yes |
| Housing material | — | — | SPCC | Steel | — |
| Key lock | Yes | — | — | — | — |
| Material | Steel | Steel | — | — | Steel |
| Maximum weight capacity | 800 kg | 56.7 kg | 91 kg | — | 90 kg |
| Mounting hole shape | Square | Square | — | — | Square |
| Number of fans | — | 0 fan(s) | — | — | — |
| Product colour | Black | Black | Black | Black | Black |
| Product design | 4-post | 2-post | — | — | 4-post |
| Rack capacity | 15U | 2U | 2U | 1U | 9U |
| Removable back door | Yes | — | — | — | — |
| Removable front door | Yes | — | — | — | Yes |
| Removable side panels | Yes | — | — | — | Yes |
| Side panel construction | Steel | — | — | — | Steel |
| Side panel key lock | Yes | — | — | — | Yes |
| Side panels included | — | — | — | — | Yes |
| Type | Freestanding rack | Wall mounted rack | Rack shelf | Cable ring | Wall mounted rack |
| Packaging content | |||||
| Cage nuts included | — | — | Yes | — | — |
| Quick installation guide | — | — | Yes | — | — |
| Screw type | — | — | M6 | — | — |
| Screws included | — | — | Yes | — | — |
| Washers included | — | — | Yes | — | — |
| Technical details | |||||
| Compliance certificates | RoHS | RoHS | — | RoHS | RoHS |
| Other features | |||||
| Compliance industry standards | EIA/ECA-310-E | EIA/ECA-310-E | — | — | EIA/ECA-310-E |
| Weight & dimensions | |||||
| Depth | 1000 mm | 151 mm | 356 mm | 101 mm | 551 mm |
| Height | 796 mm | 105 mm | 87 mm | 45 mm | 505 mm |
| Inner depth | 99.2 cm | — | — | — | 54.7 cm |
| Inner height | — | — | — | — | 40 cm |
| Inner width | 59.6 cm | 45 cm | — | — | 60.2 cm |
| Mounting depth (max) | 81.3 cm | — | — | — | 48 cm |
| Mounting depth (min) | 14 cm | — | — | — | 6 cm |
| Size (imperial) | — | 48.3 cm (19") | — | — | — |
| Weight | 58 kg | 748.7 g | 3.2 kg | 78 g | 21 kg |
| Width | 600 mm | 504 mm | 483 mm | 57 mm | 602 mm |
| Logistics data | |||||
| Harmonized System (HS) code | 85381000 | 85381000 | 85389099 | 85389099 | 85381000 |
| Master (outer) case height | 327 mm | — | 565 mm | — | 580 mm |
| Master (outer) case length | 1067 mm | — | 505 mm | — | 670 mm |
| Master (outer) case width | 873 mm | — | 570 mm | — | 640 mm |
| Products per master (outer) case | 1 pc(s) | — | 4 pc(s) | — | 1 pc(s) |
| Packaging data | |||||
| Manual | — | Yes | — | — | Yes |
| Mounting kit | — | Yes | — | — | — |
| Number of bolts | 16 | — | — | — | — |
| Number of leveling feets included | 4 pc(s) | — | — | — | — |
| Number of nuts | 24 | 8 | — | — | 36 |
| Number of screwdrivers | 1 | — | — | — | — |
| Number of screws | 50 | 14 | — | — | 36 |
| Number of washers included | 32 | — | — | — | — |
| Number of wrenches included | 2 | — | — | — | — |
| Nuts included | Yes | Yes | — | — | Yes |
| Package depth | 1067 mm | 533 mm | 560 mm | 225 mm | 635 mm |
| Package height | 327 mm | 116 mm | 120 mm | 46 mm | 590 mm |
| Package weight | 62.6 kg | 1.2 kg | 4.5 kg | 83 g | 22 kg |
| Package width | 873 mm | 168 mm | 550 mm | 125 mm | 675 mm |
| Quantity per pack | — | — | — | 1 pc(s) | — |
| Screws included | Yes | Yes | — | — | Yes |
| Wall mounting kit | — | Yes | — | — | — |
