Compare STARTECH Switchers & Splitters
Comparing 5 products side-by-side — specifications, pricing and stock. Showing STARTECH products in the Switchers & Splitters category.
| Specification | |||||
|---|---|---|---|---|---|
| Power | |||||
| AC adapter input current | 1.5 A | — | 1 A | — | 0.4 A |
| AC adapter input voltage | 100 - 240 V | — | 100 - 240 V | — | 100 - 240 V |
| AC adapter output current | — | — | 3 A | — | 2 A |
| AC adapter output voltage | 12 V | — | 12 V | — | 5 V |
| AC input voltage | — | 100 - 240 V | — | 100 - 240 V | — |
| Input current | — | 0.3 A | — | 1 A | — |
| Output current | — | 1 A | — | 0.2 A | — |
| Output voltage | — | 5 V | — | 5 V | — |
| Power consumption (typical) | — | — | — | 5 W | — |
| Power plug type | — | — | — | — | Type H |
| USB powered | — | Yes | — | — | — |
| Packaging content | |||||
| AC adapter included | Yes | — | Yes | — | — |
| Cables included | Phone (RJ-11) | USB Type-A to Micro-USB Type-B | — | — | — |
| Included power plug types | — | — | — | AU, EU, NA, UK | — |
| Manual | — | Yes | Yes | — | — |
| Mounting brackets included | Yes | — | — | — | — |
| Remote control included | Yes | — | Yes | — | Yes |
| Software CD | — | — | Yes | — | — |
| User guide | — | — | — | Yes | — |
| Features | |||||
| Audio output channels | 7.1 channels | — | 7.1 channels | — | 7.1 channels |
| Cable length | — | 0.5 m | — | — | — |
| Certification | — | — | — | CE, FCC, REACH | — |
| Data transfer rate | — | 18 Gbit/s | — | — | — |
| Full HD | — | — | — | Yes | — |
| HD type | — | 4K Ultra HD | Full HD | 4K Ultra HD | — |
| HDCP | Yes | Yes | — | Yes | Yes |
| High Dynamic Range (HDR) supported | — | Yes | — | — | — |
| Housing material | — | Acrylonitrile butadiene styrene (ABS) | — | — | — |
| LED indicators | Activity, Power | Power | Yes | Yes | Power |
| Material | — | — | Aluminium | — | — |
| Maximum operating distance | — | 5 m | — | — | — |
| Maximum refresh rate | — | 60 Hz | — | 60 Hz | 60 Hz |
| Maximum resolution | 3840 x 2160 pixels | 4096 x 2160 pixels | 1920 x 1200 pixels | 3840 x 2160 pixels | 3840 x 2160 pixels |
| Plug and Play | — | — | — | Yes | — |
| Power LED | — | — | — | Yes | — |
| Product colour | Black | Black | Black | Black | Black |
| Remote control type | IR | — | RS232, Telnet, IR | — | — |
| Supported graphics resolutions | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1600 (WQXGA) | — | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 640 x 480 (VGA) | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1600 (WQXGA), 3840 x 2160 | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1600 (WQXGA), 3840 x 2160 |
| Supported video modes | — | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p | 1080p, 720p | 720p, 1080p | — |
| Technical details | |||||
| Audio support | Yes | — | — | — | Yes |
| Compliance certificates | RoHS | CE, RoHS | RoHS | RoHS | RoHS |
| Maximum cable length | — | — | — | 5 m | — |
| Supported audio channels | — | 7.1 | — | 7.1 | — |
| Certificates | |||||
| Certification | CE, FCC | — | CE, FCC, TAA | — | CE, FCC |
| Ports & interfaces | |||||
| DC-in jack | Yes | — | — | — | Yes |
| HDMI in | 2 | — | 4 | — | 2 |
| HDMI ports quantity | — | — | 8 | — | — |
| HDMI version | 1.4 | 2.0 | — | 2.0 | 2.0 |
| Number of HDMI outputs | 1 | — | 4 | — | 1 |
| RJ-45 input ports | — | — | 1 | — | — |
| RS-232 ports | — | — | 1 | — | — |
| Video out | — | 2x HDMI | — | 4x HDMI | — |
| Video port type | — | HDMI | HDMI | HDMI | HDMI |
| Video ports quantity | — | 2 | — | 4 | — |
| Weight & dimensions | |||||
| Depth | — | 65 mm | 436 mm | 165 mm | 80 mm |
| Dimensions (WxDxH) | — | — | 250 x 436 x 49 mm | — | — |
| Height | — | 19 mm | 49 mm | 65 mm | 20 mm |
| Weight | — | 92 g | 2.8 kg | 506 g | 105 g |
| Width | — | 55 mm | 250 mm | 64 mm | 50 mm |
| Logistics data | |||||
| Harmonized System (HS) code | 85176990 | — | 85176990 | 85176990 | 85176990 |
| Master (outer) case height | — | 220 mm | — | — | — |
| Master (outer) case length | — | 470 mm | — | — | — |
| Master (outer) case width | — | 630 mm | — | — | — |
| Products per master (outer) case | — | 60 pc(s) | — | — | — |
| Operational conditions | |||||
| Operating relative humidity (H-H) | 0 - 80% | 5 - 90% | 20 - 90% | 20 - 90% | 10 - 85% |
| Operating temperature (T-T) | 0 - 50 °C | 0 - 70 °C | 0 - 40 °C | 0 - 40 °C | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 70 °C | -10 - 80 °C | -20 - 60 °C | -20 - 60 °C | -10 - 80 °C |
| Packaging data | |||||
| Package depth | 156 mm | 145 mm | 575 mm | 212 mm | 153 mm |
| Package height | 63 mm | 30 mm | 142 mm | 55 mm | 55 mm |
| Package weight | 835 g | 168 g | 4.3 kg | — | 383 g |
| Package width | 235 mm | 190 mm | 412 mm | 148 mm | 217 mm |
| Sustainability | |||||
| Sustainability compliance | — | Yes | — | — | — |
