Compare STARTECH USB Cables & Adapters
Comparing 5 products side-by-side — specifications, pricing and stock. Showing STARTECH products in the USB Cables & Adapters category.
| Specification | |||||
|---|---|---|---|---|---|
| Power | |||||
| Input current | — | — | — | — | 1.5 A |
| Input current (max) | — | — | — | 5 A | — |
| Input voltage | — | — | 7 - 24 V | — | 100 - 240 V |
| Output current | — | — | — | — | 4 A |
| Output voltage | — | — | — | — | 12 V |
| Power consumption (typical) | — | — | — | — | 48 W |
| Power plug type | — | — | — | — | Type N |
| Power supply type | — | — | — | — | DC |
| Packaging content | |||||
| AC adapter included | — | — | — | — | Yes |
| Cables included | — | — | USB | — | USB |
| DIN rail kit included | — | — | Yes | — | — |
| Included power plug types | — | — | — | — | AU, EU, NA, UK |
| Manual | — | — | Yes | — | — |
| Quantity per pack | 1 pc(s) | 1 pc(s) | — | 1 pc(s) | — |
| Terminal block included | — | — | Yes | — | — |
| Features | |||||
| AWG wire size | 24/28 | 30 | — | 30 | — |
| Cable jacket material | — | Polyvinyl chloride (PVC) | — | Thermoplastic elastomer (TPE) | — |
| Cable length | — | — | 2.032 m | — | — |
| Cable shielding | — | Aluminum mylar foil | — | Aluminum mylar foil | — |
| Cable type | — | — | — | Round cable | — |
| Certification | — | — | RoHS, CE, FCC, TAA, REACH | — | — |
| Conductor material | — | — | — | Copper | — |
| Connector 1 | USB A | USB A | — | USB C | — |
| Connector 1 form factor | Straight | Straight | — | Straight | — |
| Connector 1 gender | Male | Male | — | Male | — |
| Connector 2 | USB B | USB C | — | USB C | — |
| Connector 2 form factor | Angled | Straight | — | Straight | — |
| Connector 2 gender | Male | Male | — | Male | — |
| Connector contacts plating | Nickel | Nickel | — | Nickel | — |
| Data transfer rate | — | — | 5000 Mbit/s | — | 5000 Mbit/s |
| Hot-swap | — | — | — | — | Yes |
| Housing material | — | — | Steel | — | Plastic |
| LED indicators | — | — | Power | — | Status |
| Maximum data transfer rate | 0.48 Gbit/s | 10 Gbit/s | — | 0.48 Gbit/s | — |
| Plug and Play | Yes | Yes | — | — | Yes |
| Product colour | Black | Black | Black | White | Black |
| Surge protection | — | — | Yes | — | — |
| USB Power Delivery (USB PD) | — | — | — | Yes | — |
| USB Power Delivery revision | — | — | — | 3.1 | — |
| USB Power Delivery up to | — | — | — | 240 W | — |
| USB Type-C DisplayPort Alternate Mode | — | — | — | No | — |
| USB version | USB 2.0 | USB 3.2 Gen 2 (3.1 Gen 2) | — | USB 2.0 | — |
| Weight & dimensions | |||||
| Cable diameter | — | — | — | 4 mm | — |
| Cable length | 2 m | 0.5 m | — | 3 m | — |
| Depth | — | — | 198 mm | — | 201 mm |
| Height | — | — | 31 mm | — | 24 mm |
| Weight | 64 g | 29 g | 357 g | — | 140 g |
| Width | — | — | 56 mm | — | 60 mm |
| Certificates | |||||
| Certification | CE, REACH | CE, REACH | — | — | — |
| Compliance certificates | RoHS | RoHS | — | CE, Federal Communications Commission (FCC), RoHS | — |
| Other features | |||||
| Chipset | — | — | Genesys Logic - GL3520 | — | VLI - VL812 |
| Technical details | |||||
| Compliance certificates | — | — | — | — | CE, RoHS |
| Ports & interfaces | |||||
| DC-in jack | — | — | — | — | Yes |
| Host interface | — | — | USB 3.2 Gen 1 (3.1 Gen 1) Type-B | — | USB 3.2 Gen 1 (3.1 Gen 1) Type-B |
| Hub interfaces | — | — | USB 3.2 Gen 1 (3.1 Gen 1) Type-A | — | USB 3.2 Gen 1 (3.1 Gen 1) Type-A |
| Ports quantity | — | — | 10 | — | 10 |
| Terminal block port | — | — | Yes | — | — |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | — | — | 10 | — | 10 |
| Sustainability | |||||
| Doesn't contain | — | — | — | Halogen | — |
| Sustainability compliance | — | — | — | — | Yes |
| Logistics data | |||||
| Harmonized System (HS) code | 84733080 | 84733080 | 84719000 | — | 84719000 |
| Master (outer) case height | — | — | 338 mm | 210 mm | 315 mm |
| Master (outer) case length | — | — | 526 mm | 320 mm | 415 mm |
| Master (outer) case width | — | — | 444 mm | 500 mm | 381 mm |
| Products per master (outer) case | — | — | 25 pc(s) | 80 pc(s) | 10 pc(s) |
| Performance | |||||
| Mean time between failures (MTBF) | — | — | 119388 h | — | — |
| Operational conditions | |||||
| Operating relative humidity (H-H) | — | — | 5 - 95% | — | 10 - 90% |
| Operating temperature (T-T) | — | — | 0 - 70 °C | -10 - 60 °C | 0 - 40 °C |
| Storage temperature (T-T) | — | — | -20 - 85 °C | -20 - 70 °C | -10 - 70 °C |
| Packaging data | |||||
| Package depth | 225 mm | 223 mm | 246 mm | 200 mm | 194 mm |
| Package height | 10 mm | 10 mm | 57 mm | 20 mm | 73 mm |
| Package weight | 68 g | 29 g | 600 g | 102 g | 639 g |
| Package width | 125 mm | 90 mm | 169 mm | 220 mm | 293 mm |
