Compare STARTECH Switchers & Splitters
Comparing 5 products side-by-side — specifications, pricing and stock. Showing STARTECH products in the Switchers & Splitters category.
| Specification | |||||
|---|---|---|---|---|---|
| Power | |||||
| AC adapter input current | — | — | 0.3 A | 0.6 A | — |
| AC adapter input voltage | — | 100 - 240 V | — | — | — |
| AC adapter output current | — | — | 1 A | 1.5 A | — |
| AC adapter output voltage | — | — | 5 V | 12 V | — |
| AC input voltage | — | — | 100 - 240 V | 100 - 240 V | 100 - 240 V |
| Input current | — | — | — | — | 0.35 A |
| Output current | — | — | — | — | 1 A |
| Output voltage | — | — | — | — | 5 V |
| Power consumption (typical) | — | 5 W | 5 W | 18 W | 0.1 W |
| Power plug type | — | — | — | Type M | — |
| Packaging content | |||||
| AC adapter included | — | — | Yes | — | Yes |
| Cables included | — | — | USB Type-A to Micro-USB Type-B | — | — |
| Manual | — | — | — | Yes | Yes |
| Mounting kit | — | — | Yes | Yes | — |
| Plug adapter type | — | — | — | NA, EU, UK, AU | — |
| Quick start guide | — | — | Yes | — | — |
| Remote control included | — | — | Yes | Yes | — |
| Ports & interfaces | |||||
| Audio output | — | 3.5 mm | — | — | — |
| Audio ports quantity | — | — | — | — | 2 |
| Digital audio optical out | — | 1 | — | — | — |
| HDMI in | — | 1 | 2 | 1 | — |
| HDMI ports quantity | — | — | — | 3 | — |
| HDMI version | — | 2.0b | — | — | 2.0b |
| Number of HDMI outputs | — | 2 | 1 | 2 | — |
| USB port type | — | — | Micro-USB | — | — |
| Video out | — | — | — | — | 4x HDMI |
| Video port type | — | — | HDMI | HDMI | HDMI |
| Video ports quantity | — | — | — | — | 4 |
| Performance | |||||
| Audio output channels | 2.0 channels | — | — | — | — |
| Chipset | Synaptics VMM5310 | — | — | — | — |
| DisplayPort output | No | — | — | — | — |
| DVI output | No | — | — | — | — |
| HDCP | Yes | — | — | — | — |
| HDCP version | 2.2 | — | — | — | — |
| HDMI output | Yes | — | — | — | — |
| HDMI ports quantity | 3 | — | — | — | — |
| HDMI version | 2.0 | — | — | — | — |
| High Dynamic Range (HDR) supported | Yes | — | — | — | — |
| Maximum resolution | 3840 x 2160 pixels | — | — | — | — |
| Number of displays supported | 3 | — | — | — | — |
| Refresh rate at maximum resolution | 60 Hz | — | — | — | — |
| USB connector form factor | Straight | — | — | — | — |
| USB connector gender | Male | — | — | — | — |
| USB connector type | USB Type-C | — | — | — | — |
| Features | |||||
| Audio output channels | — | — | 7.1 channels | 7.1 channels | — |
| Extended display identification data (EDID) | — | — | — | Yes | — |
| HD type | — | — | — | — | 4K Ultra HD |
| HDCP | — | — | — | Yes | — |
| Housing material | — | Metal | — | — | Metal |
| LED indicators | — | Yes | Yes | Yes | Yes |
| Material | — | — | Metal | Aluminium, Plastic | — |
| Maximum operating distance | — | — | 5 m | 10 m | 5 m |
| Maximum refresh rate | — | — | — | — | 60 Hz |
| Maximum resolution | — | — | 7680 x 4320 pixels | 1920 x 1200 pixels | 3840 x 2160 pixels |
| Plug and Play | — | — | Yes | Yes | Yes |
| Product colour | — | Black | Black | Black | Black |
| Rack mounting | — | — | — | Yes | — |
| Supported graphics resolutions | — | — | 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1080, 2560 x 1440, 3440 x 1440, 3840 x 2160, 4096 x 2160, 5120 x 1440, 7680 x 4320 | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA) | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 3840 x 2160 |
| Supported video modes | — | — | — | 1080p, 720p | — |
| Technical details | |||||
| Audio support | — | — | — | — | Yes |
| Compliance certificates | CE, RoHS | RoHS | CE, RoHS | RoHS | CE, RoHS |
| Supported audio channels | — | — | — | — | 7.1 |
| Sustainability compliance | Yes | — | — | — | — |
| Certificates | |||||
| Certification | — | CE, FCC, REACH | — | CE, FCC, TAA, REACH | — |
| Weight & dimensions | |||||
| Depth | 105 mm | 205 mm | 90 mm | 156 mm | 180 mm |
| Height | 14 mm | 65 mm | 14 mm | 20 mm | 14 mm |
| USB cable length | 0.3 m | — | — | — | — |
| Weight | 72 g | 355 g | 87 g | 290 g | 248 g |
| Width | 43 mm | 115 mm | 44 mm | 65 mm | 62 mm |
| Logistics data | |||||
| Harmonized System (HS) code | — | — | — | 85176990 | — |
| Master (outer) case height | 440 mm | — | 280 mm | — | 318 mm |
| Master (outer) case length | 331 mm | — | 400 mm | — | 300 mm |
| Master (outer) case width | 473 mm | — | 550 mm | — | 443 mm |
| Products per master (outer) case | 70 pc(s) | — | 40 pc(s) | — | 20 pc(s) |
| Design | |||||
| Housing material | Plastic | — | — | — | — |
| Product colour | Grey | — | — | — | — |
| Group 38959 | |||||
| Master (outer) case height | — | 350 mm | — | — | — |
| Master (outer) case length | — | 425 mm | — | — | — |
| Master (outer) case width | — | 353 mm | — | — | — |
| Products per master (outer) case | — | 30 pc(s) | — | — | — |
| Video | |||||
| Maximum refresh rate | — | 60 Hz | — | — | — |
| Supported graphics resolutions | — | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 3840 x 2160 | — | — | — |
| Operational conditions | |||||
| Operating relative humidity (H-H) | 0 - 85% | 20 - 90% | 5 - 90% | 0 - 80% | 20 - 90% |
| Operating temperature (T-T) | 0 - 40 °C | 0 - 40 °C | 0 - 70 °C | 0 - 40 °C | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C | -20 - 60 °C | -10 - 80 °C | -20 - 60 °C | -20 - 60 °C |
| Packaging data | |||||
| Package depth | 170 mm | 202 mm | 179 mm | 294 mm | 150 mm |
| Package height | 30 mm | 69 mm | 50 mm | 72 mm | 55 mm |
| Package weight | 124 g | — | 312 g | 853 g | 500 g |
| Package width | 142 mm | 114 mm | 123 mm | 197 mm | 213 mm |
| Group 22061 | |||||
| Supported audio channels | — | 7.1 | — | — | — |
| Sustainability | |||||
| Sustainability compliance | — | — | Yes | — | — |
| System requirements | |||||
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64 | — | — | — | — |
