Compare STARTECH Monitor Mounts
Comparing 5 products side-by-side — specifications, pricing and stock. Showing STARTECH products in the Monitor Mounts category.
| Specification | |||||
|---|---|---|---|---|---|
| General | |||||
| Package Content | Pole, baseplate, 3 x M6x15 screws, cable-management clip (pole), pole cap, height-adjustment ring, crossbar, 2 x VESA monitor mounts, 8 x M4x12 screws, 8 x M4x30 screws, 8 x plastic spacers, allen wrench (3mm), allen wrench (4mm), 2 x cable-management clips (crossbar) | Monitor arm, 2 x VESA monitor mount, EVA cushion, 8 x VESA screws, cable clip, M3 hex key, M6 hex key, crossbar, 2 x crossbar endcaps, 4 x M6x12 screws, 5 x M6 cap nuts, grab handle | Crossbar, 2 x VESA monitor mounts, 8 x M4x12 screws, 8 x M4x30 screws, 4 x washers, 4 x concrete anchors, 8 x spacers, hex key, 2 x plastic covers, 2 x cable-management clips, wall plate, 2 x mounting arms, crossbar cap, mounting arm retainer, 3 x M8x16 screws, 3 x mounting-arm washers, 2 x mounting-arm caps, wall plate retainer, level, 4 x M8x60 screws, crossbar retainer | — | — |
| Ergonomics | |||||
| Adjustable depth | — | Yes | — | — | — |
| Cable management | Yes | Yes | Yes | — | — |
| Depth adjustment range | — | 160 - 574 mm | — | — | — |
| Height adjustment | Yes | Yes | — | — | Yes |
| Height adjustment range | — | 202 - 529 mm | — | — | — |
| Pivot angle | — | -180 - 180° | — | — | — |
| Rotating | — | Yes | — | — | — |
| Swivelling | — | Yes | — | — | — |
| Tilt adjustment | — | Yes | — | — | — |
| AV Furniture | |||||
| Adjustable Feet | Yes | — | — | — | — |
| Adjustments | Height, tilt | Height, tilt, swivel, rotation, pivot | Tilt, swivel, rotation | — | Height |
| Assembly Required | Yes | Yes | — | — | — |
| Cable Management | — | — | — | — | Integrated cable management |
| Design | Adjustable arm | Articulating, mechanical spring | Adjustable arm | — | — |
| Max Load Weight | 8 kg | 30 kg | 10 kg | — | 16 kg |
| Mounting Components | — | — | — | 2 VESA mount brackets | — |
| Pan | — | — | 180° | — | — |
| Placing / Mounting | Stand mountable | Desk-mountable | Wall-mountable | Monitor | Desktop |
| Recommended Display Size | 24" | 17"-27" | 15"-24" | — | 24" |
| Recommended Use | LCD display | 2 LCD displays | — | Thin client | — |
| Rotation | 0 - 360° | 360° | 360° | — | — |
| Swivel | 360° | -15 - 15° | 180° | — | 360° |
| TAA Compliant | — | Yes | — | — | — |
| Tilt | -15 - 15° | -15 - 65° | -15 - 15° | — | -15 - 15° |
| Type | Stand | Mounting kit | Bracket | Mounting component | Stand |
| VESA Mounting Interface | — | — | — | 100 x 100 mm, 75 x 75 mm | — |
| Design | |||||
| Anti-theft function | — | No | — | — | — |
| Housing material | Plastic, Steel | Aluminium, Plastic, Steel | — | — | Aluminium, Plastic, Stainless steel |
| Orientation | — | — | Landscape | — | — |
| Product colour | Black | Black | Black | — | Stainless steel |
| Other features | |||||
| Certification | CE, REACH | — | — | — | CE, REACH |
| Compliance certificates | RoHS | Trade Agreements Act (TAA) | RoHS, CE | — | RoHS |
| VESA mounting | — | — | — | — | Yes |
| Weight & dimensions | |||||
| Depth | 950 mm | 640 mm | 680 mm | 120 mm | 180 mm |
| Height | 410 mm | 529 mm | 193 mm | 1.5 mm | 410 mm |
| Package weight | — | — | — | 600 g | — |
| Shipping Dimensions (WxDxH) / Weight | — | — | — | — | 70.5 cm x 30 cm x 11.8 cm / 6.2 kg |
| Weight | 6.2 kg | 6 kg | 3.2 kg | — | 7.28 kg |
| Width | 180 mm | 793 mm | 75 mm | 305 mm | 950 mm |
| Compatibility Information | |||||
| Designed For | P/N: ACCSMNT, DK30A2DH, DK30C2DAGPD, DK30C2HAGPD, PXT101YUK, TB3DK2DPM2, TB3DK2DPPD, USB3SDOCKDD, USB3SDOCKHD, USB3SDOCKHDV | — | — | — | — |
| Mounting | |||||
| Desk thickness (min) | — | 2 cm | — | — | — |
| Distance to the wall (max) | — | — | 58.5 cm | — | — |
| Distance to the wall (min) | — | — | 16.5 cm | — | — |
| Extension arm (max) | — | — | 58.5 cm | — | — |
| Maximum screen size | 61 cm (24") | 68.6 cm (27") | 61 cm (24") | — | 61 cm (24") |
| Maximum VESA mount | 100 x 100 mm | 100 x 100 mm | 100 x 100 mm | — | 100 x 100 mm |
| Maximum weight capacity | 8 kg | 30 kg | 10 kg | — | 8 kg |
| Maximum weight capacity (per display) | — | 15 kg | — | — | — |
| Minimum screen size | — | 43.2 cm (17") | 38.1 cm (15") | — | — |
| Minimum VESA mount | 75 x 75 mm | 75 x 75 mm | 75 x 75 mm | — | 75 x 75 mm |
| Mounting | Freestanding | Clamp | — | — | Freestanding |
| Mounting type | Desk | Desk | Wall | — | Desk |
| Number of displays supported | 2 | — | — | — | — |
| Panel mounting interface | — | — | — | — | 75 x 75,100 x 100 mm |
| Recommended Use | — | — | 2 monitors | — | 2 monitors |
| Packaging content | |||||
| Grommet base plate included | Yes | — | — | — | — |
| Manual | Yes | Yes | Yes | Yes | Yes |
| Number of cable clips | 3 | 1 | 2 | — | 3 |
| Number of end caps included | — | — | — | — | 1 pc(s) |
| Number of screws | 19 | 12 | 8 | 28 | 19 |
| Number of spacers included | 8 | — | 1 | — | 8 |
| Number of washers included | — | — | 11 | 4 | — |
| Screws included | Yes | Yes | Yes | Yes | Yes |
| VESA mount included | Yes | Yes | Yes | — | — |
| Washers included | — | — | — | Yes | — |
| Wrench included | Yes | — | — | — | Yes |
| Wrench type | — | Hexagonal wrench | Hexagonal wrench | — | Hexagonal wrench |
| Logistics data | |||||
| Harmonized System (HS) code | 85299097 | — | 85299097 | — | 85299097 |
| Master (outer) case height | — | 171 mm | 268 mm | 140 mm | 250 mm |
| Master (outer) case length | — | 352 mm | 723 mm | 225 mm | 320 mm |
| Master (outer) case width | — | 800 mm | 392 mm | 325 mm | 730 mm |
| Products per master (outer) case | — | 1 pc(s) | 4 pc(s) | 20 pc(s) | 2 pc(s) |
| Features | |||||
| Material | — | — | — | Steel | — |
| Mounting type | — | — | — | Screw | — |
| Panel mounting interface | — | — | — | 75 x 75,100 x 100 mm | — |
| Product colour | — | — | — | Black | — |
| Recommended chassis type | — | — | — | SFF | — |
| Type | — | — | — | Monitor stand-mounted CPU holder | — |
| Technical details | |||||
| Maximum stand height | 40.6 cm | — | — | — | — |
| Package depth | — | — | — | 125 mm | — |
| Package height | — | — | — | 20 mm | — |
| Package width | — | — | — | 310 mm | — |
| Packaging data | |||||
| Package depth | 305 mm | 352 mm | 710 mm | — | 31 mm |
| Package height | 121 mm | 171 mm | 122 mm | — | 13 mm |
| Package weight | 7.43 kg | 6.3 kg | 4.4 kg | — | 7.38 kg |
| Package width | 717 mm | 800 mm | 188 mm | — | 72 mm |
| Manufacturer Warranty | |||||
| Service & Support | Limited warranty - 5 years | Limited warranty - 10 years | Limited warranty - 5 years | Limited warranty - 5 years | Limited warranty - 5 years |
