Compare STARTECH HDMI Cables & Adapters
Comparing 5 products side-by-side — specifications, pricing and stock. Showing STARTECH products in the HDMI Cables & Adapters category.
| Specification | STARTECH StarTech.com 5m High Speed HDMI Cable to DVI Digital Video Monitor - Adapter cable - HDMI male to DVI-D male - 5 m - shielded - blackHDDVIMM5M £7.45 £8.94 inc VAT | STARTECH StarTech.com 0.5m High Speed HDMI Cable with Ethernet HDMI to HDMI Micro - HDMI cable with Ethernet - HDMI male to 19 pin micro HDMI Type D male - 50 cm - blackHDADMM50CM £4.42 £5.30 inc VAT | |||
|---|---|---|---|---|---|
| Power | |||||
| External power adapter | No | — | — | — | — |
| Features | |||||
| 3D | — | — | — | Yes | Yes |
| Audio Return Channel (ARC) | — | — | — | Yes | Yes |
| AWG wire size | — | — | — | 30/32 | 34 |
| Bandwidth | — | — | 18000 MB/s | — | 10200 MB/s |
| Cable jacket material | — | — | — | Polyvinyl chloride (PVC) | Polyvinyl chloride (PVC) |
| Cable length | 0.189 m | 5 m | 2 m | 5 m | 0.5 m |
| Cable shielding | — | — | — | — | Aluminum mylar foil |
| Cable type | — | — | Round cable | — | — |
| Chipset | — | — | Synaptics - VMR7100 | — | — |
| Colour depth | — | — | 10 bit | — | — |
| Colour sampling | — | — | 4:4:4 | — | — |
| Connector 1 | — | HDMI | DisplayPort | HDMI Type A (Standard) | HDMI Type A (Standard) |
| Connector 1 form factor | — | — | Straight | Straight | Straight |
| Connector 1 gender | — | Male | Male | Male | Male |
| Connector 2 | — | DVI-D | HDMI Type A (Standard) | HDMI Type A (Standard) | HDMI Type D (Micro) |
| Connector 2 form factor | — | — | Straight | Straight | Straight |
| Connector 2 gender | — | Male | Male | Male | Male |
| Connector contacts plating | — | Gold | Gold | Gold | Gold |
| Converter type | Active video converter | — | Active video converter | — | — |
| DisplayPort version | — | — | 1.4 | — | — |
| Dolby technologies | — | — | — | Dolby Digital Plus, Dolby TrueHD | Dolby Digital Plus, Dolby TrueHD |
| HDCP | — | — | Yes | Yes | Yes |
| HDCP version | — | — | 1.4/2.3 | 1.4 | 1.4 |
| HDMI Ethernet channel | — | — | — | Yes | Yes |
| HDMI version | — | — | 2.0b | 1.4b | 1.4b |
| High Dynamic Range (HDR) supported | — | — | Yes | — | — |
| Housing material | Plastic | — | — | — | — |
| Internal | No | — | — | — | — |
| Jacket material | — | — | Polyvinyl chloride (PVC) | — | — |
| Maximum refresh rate | — | — | 120 Hz | 120 Hz | 120 Hz |
| Maximum resolution | — | — | 4096 x 2160 pixels | — | — |
| Plug and Play | Yes | — | — | — | Yes |
| Product colour | — | Black | Black | White | Black |
| Refresh rate at maximum resolution | — | — | 60 Hz | — | — |
| Supported audio channels | — | — | 7.1 | — | — |
| Supported graphics resolutions | — | — | 2048 x 1536 (QXGA), 3840 x 2160, 2560 x 1440, 4096 x 2160, 1920 x 1200 (WUXGA), 3072 x 1728, 3200 x 1800 | 1920 x 1080 (HD 1080), 3840 x 2160, 4096 x 2160 | 1920 x 1080 (HD 1080), 3840 x 2160, 4096 x 2160 |
| Weight & dimensions | |||||
| Cable diameter | — | — | 5 mm | — | 4.2 mm |
| Depth | 234 mm | — | — | — | — |
| Height | 15 mm | — | — | — | — |
| Weight | 33 g | 320 g | 82 g | 218 g | 25 g |
| Width | 45 mm | — | — | — | — |
| Certificates | |||||
| Certification | — | RoHS | — | — | — |
| Compliance certificates | — | — | RoHS | CE, RoHS | CE, RoHS |
| Other features | |||||
| Chipset | AG6203 | — | — | — | — |
| Video | |||||
| Colour depth | 8 bit | — | — | — | — |
| Maximum refresh rate | 75 Hz | — | — | — | — |
| Maximum video resolution | 1920 x 1200 pixels | — | — | — | — |
| Supported video modes | 1080p | — | — | — | — |
| Video resolutions | 800 x 600,1024 x 768,1280 x 720,1280 x 800,1600 x 1200,1680 x 1050,1920 x 1080,1920 x 1200 | — | — | — | — |
| Technical details | |||||
| Compliance certificates | RoHS | — | — | — | — |
| Logistics data | |||||
| Harmonized System (HS) code | — | 84733080 | — | 84733080 | 84733080 |
| Master (outer) case height | 60 mm | — | 300 mm | 295 mm | 210 mm |
| Master (outer) case length | 110 mm | — | 400 mm | 425 mm | 500 mm |
| Master (outer) case width | 216 mm | — | 300 mm | 380 mm | 325 mm |
| Products per master (outer) case | 24 pc(s) | — | 100 pc(s) | 60 pc(s) | 200 pc(s) |
| Ports & interfaces | |||||
| Host interface | HDMI | — | — | — | — |
| Output interface | VGA | — | — | — | — |
| Operational conditions | |||||
| Operating relative humidity (H-H) | 0 - 75% | — | 10 - 90% | — | — |
| Operating temperature (T-T) | 0 - 70 °C | — | 0 - 40 °C | — | — |
| Storage temperature (T-T) | -10 - 80 °C | — | -10 - 70 °C | — | — |
| Packaging data | |||||
| Package depth | 50 mm | 397 mm | 200 mm | 220 mm | 220 mm |
| Package height | 18 mm | 10 mm | 10 mm | 15 mm | 15 mm |
| Package weight | 53 g | 260 g | 85 g | 228 g | 32 g |
| Package width | 50 mm | 142 mm | 170 mm | 200 mm | 125 mm |
| Quantity per pack | — | — | — | 1 pc(s) | 1 pc(s) |
| Packaging content | |||||
| Quantity per pack | — | — | 1 pc(s) | — | — |
| Sustainability | |||||
| Sustainability compliance | — | — | Yes | — | — |
