Compare STARTECH HDMI Cables & Adapters
Comparing 5 products side-by-side — specifications, pricing and stock. Showing STARTECH products in the HDMI Cables & Adapters category.
| Specification | |||||
|---|---|---|---|---|---|
| Performance | |||||
| Audio output channels | 2.0 channels | — | — | 7.1 channels | — |
| Certification | — | — | — | CE, FCC, REACH | — |
| Chipset | Trigger - T5-302 | — | — | Parade - PS176, VIA/VLI - VL100 | — |
| DisplayPort output | No | — | — | No | — |
| DVI output | No | — | — | No | — |
| HDMI output | Yes | — | — | Yes | — |
| HDMI version | — | — | — | 2.0 | — |
| Internal memory | 16 MB | — | — | — | — |
| Maximum resolution | 1920 x 1200 pixels | — | — | 3840 x 2160 pixels | — |
| Number of displays supported | 1 | — | — | 1 | — |
| Refresh rate at maximum resolution | — | — | — | 60 Hz | — |
| Supported graphics resolutions | 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 800, 1280 x 960, 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1440 x 900, 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA) | — | — | 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 800 (WXGA), 1360 x 768 (WXGA), 1440 x 900, 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2048 x 1280, 2560 x 1600 (WQXGA), 3840 x 2160 | — |
| Supported video modes | 480p, 720p, 1080p | — | — | — | — |
| USB connector form factor | Straight | — | — | — | — |
| USB connector gender | Male | — | — | Male | — |
| USB connector type | USB Type-A | — | — | USB Type-C | — |
| USB pass-through | No | — | — | — | — |
| USB version | 3.2 Gen 1 (3.1 Gen 1) | — | — | — | — |
| VGA (D-Sub) output | — | — | — | No | — |
| Features | |||||
| Audio Return Channel (ARC) | — | Yes | — | — | — |
| AWG wire size | — | 30 | — | — | — |
| Bandwidth | — | 18000 MB/s | — | — | 32400 MB/s |
| Cable jacket material | — | Polyvinyl chloride (PVC) | — | — | — |
| Cable length | — | 2 m | 0.15 m | — | 0.3 m |
| Cable shielding | — | Aluminum mylar foil | — | — | — |
| Connector 1 | — | HDMI Type A (Standard) | Mini DisplayPort | — | DisplayPort |
| Connector 1 form factor | — | Straight | Straight | — | Straight |
| Connector 1 gender | — | Male | Male | — | Male |
| Connector 2 | — | HDMI Type A (Standard) | DVI-D + VGA (D-Sub) + HDMI | — | 2 x HDMI |
| Connector 2 form factor | — | Straight | Straight | — | Straight |
| Connector 2 gender | — | Male | Female | — | Female |
| Connector contacts plating | — | Gold | — | — | — |
| DisplayPort version | — | — | 1.2 | — | 1.4 |
| Dolby technologies | — | Dolby TrueHD, Dolby Atmos, Dolby Digital Plus | — | — | — |
| Dual Link DVI | — | — | No | — | — |
| HDCP | — | Yes | — | — | — |
| HDCP version | — | 2.2 | — | — | — |
| HDMI Ethernet channel | — | Yes | — | — | — |
| HDMI version | — | 2.0 | 1.4 | — | 2.0 |
| High Dynamic Range (HDR) supported | — | Yes | — | — | Yes |
| High Dynamic Range (HDR) technology | — | High Dynamic Range 10 (HDR10) | — | — | — |
| Latching connectors | — | — | — | — | Yes |
| Maximum refresh rate | — | 60 Hz | — | — | 60 Hz |
| Maximum resolution | — | — | 1920 x 1200 pixels | — | 3840 x 2160 pixels |
| Plug and Play | — | Yes | Yes | — | Yes |
| Power source | — | — | — | — | USB |
| Product colour | — | White | Black | — | Black, Grey |
| Supported audio channels | — | — | 5.1 | — | 7.1 |
| Supported digital audio channels (uncompressed) | — | 5.1, 7.1, 32 | — | — | — |
| Supported graphics resolutions | — | 4096 x 2160 | — | — | — |
| Supported video modes | — | — | 1080p | — | — |
| Windows operating systems supported | — | — | — | — | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64 |
| Certificates | |||||
| Certification | — | — | CE, FCC, REACH | — | — |
| Compliance certificates | — | CE, RoHS | RoHS | — | — |
| Technical details | |||||
| Compliance certificates | CE, RoHS | — | — | RoHS | — |
| Weight & dimensions | |||||
| Depth | 190 mm | — | 270 mm | 50 mm | 43 mm |
| Height | 12 mm | — | 15 mm | 13 mm | 14 mm |
| USB cable length | 0.062 m | — | — | 0.1 m | — |
| Weight | 25 g | 52 g | 57 g | 24 g | 53 g |
| Width | 25 mm | — | 45 mm | 33 mm | 105 mm |
| Packaging content | |||||
| Drivers included | Yes | — | — | — | — |
| Manual | Yes | — | — | — | — |
| Logistics data | |||||
| Harmonized System (HS) code | 84733020 | 84733080 | 84733080 | 84733020 | 84733080 |
| Master (outer) case height | 360 mm | 290 mm | — | 318 mm | 440 mm |
| Master (outer) case length | 370 mm | 430 mm | — | 362 mm | 331 mm |
| Master (outer) case width | 305 mm | 380 mm | — | 334 mm | 473 mm |
| Products per master (outer) case | 40 pc(s) | 78 pc(s) | — | 40 pc(s) | 70 pc(s) |
| Design | |||||
| Housing material | Plastic | — | — | Plastic | — |
| Integrated USB cable | Yes | — | — | Yes | — |
| Product colour | Black | — | — | Black | — |
| System requirements | |||||
| Minimum processor family | Core i5 | — | — | — | — |
| Minimum processor speed | 2.4 GHz | — | — | — | — |
| Minimum RAM | 4 GB | — | — | — | — |
| Windows operating systems supported | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows Vista x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 | — | — | — | — |
| Operational conditions | |||||
| Operating relative humidity (H-H) | 0 - 85% | — | 10 - 85% | 0 - 90% | — |
| Operating temperature (T-T) | 0 - 50 °C | — | 0 - 70 °C | 0 - 40 °C | — |
| Storage temperature (T-T) | -10 - 75 °C | — | -10 - 80 °C | -20 - 70 °C | — |
| Packaging data | |||||
| Package depth | 175 mm | 150 mm | 220 mm | 174 mm | 170 mm |
| Package height | 32 mm | 20 mm | 18 mm | 32 mm | 30 mm |
| Package weight | 144 g | 103 g | 66 g | 106 g | 110 g |
| Package width | 148 mm | 182 mm | 200 mm | 146 mm | 142 mm |
| Quantity per pack | — | 1 pc(s) | — | — | — |
| Quick installation guide | — | — | Yes | — | — |
