Product Comparison

Technical Specifications

General
Aspect Ratio
16:9
Backlight Technology
WLED
Brightness
250 cd/m²
Built-in Devices
USB 3.2 Gen 1 hub
Colour
Raven black
Colour Gamut
99% BT.709, 99% sRGB
Colour Support
16.7 million colours
Contrast Ratio
1500:1 / 3000000:1 (dynamic)
Diagonal Size
24"
Dimensions (WxDxH)
53.98 cm x 19 cm x 50.58 cm - with stand (highest position)
Display Type
LED-backlit LCD monitor / TFT active matrix
Features
Integrated cable management, 8-bit Colour Depth, Natural Low Blue Light technology, modular camera support, ultra thin bezel design
Horizontal Refresh Rate
28 - 150 kHz
Horizontal Viewing Angle
178
Native Resolution
Full HD (1080p) 1920 x 1080 at 120 Hz
Panel Type
IPS
Pixel Per Inch
95
Pixel Pitch
0.2745 mm
Response Time
4 ms (extreme), 6 ms (normal)
Screen Coating
Anti-glare
Vertical Refresh Rate
48 - 120 Hz
Vertical Viewing Angle
178
Viewable Size
23.8"
Weight
5.1 kg
Display
Anti-glare screen
Yes
Yes
Backlight type
W-LED
W-LED
Colour depth
8 bit
Colour gamut
99%
99%
Contrast ratio (dynamic)
3000000:1
Contrast ratio (typical)
3000:1
1500:1
Display brightness (typical)
300 cd/m²
350 cd/m²
Display diagonal
86.4 cm (34")
68.6 cm (27")
Display number of colours
16.7 million colours
16.7 million colours
Display resolution
3440 x 1440 pixels
2560 x 1440 pixels
Display technology
LED
LED
HD type
Wide Quad HD
Wide Quad HD
High Dynamic Range (HDR) supported
Yes
Yes
High Dynamic Range (HDR) technology
High Dynamic Range 10 (HDR10)
LED backlight
Yes
Yes
Maximum refresh rate
120 Hz
120 Hz
Native aspect ratio
21:9
16:9
Panel type
VA
IPS
Pixel density
110 ppi
109 ppi
Pixel pitch
0.2318 x 0.2318 mm
0.2331 x 0.2331 mm
Response time
6 ms
6 ms
Response time (extreme)
4 ms
Response time (fast)
4 ms
4 ms
Screen curvature rating
1500R
Screen shape
Curved
Flat
sRGB coverage (typical)
99%
99%
Touchscreen
No
No
Viewing angle, horizontal
178°
178°
Viewing angle, vertical
178°
178°
Power
AC input frequency
50/60 Hz
50/60 Hz
AC input voltage
100 - 240 V
100 - 240 V
Energy consumption (HDR) per 1000 hours
36 kWh
28.8 kWh
Energy consumption (SDR) per 1000 hours
25 kWh
16.9 kWh
Energy efficiency class (HDR)
G
G
Energy efficiency class (SDR)
E
D
Energy efficiency scale
A to G
A to G
Input Voltage
AC 100-240 V (50/60 Hz)
Power Consumption (Max)
66 Watt
Power consumption (max)
200 W
90 W
Power Consumption (Off Mode)
0.3 Watt
Power consumption (off)
0.5 W
0.3 W
Power consumption (standby)
0.5 W
0.5 W
Power Consumption (Typical)
12 Watt
Power consumption (typical)
30 W
17 W
Power Consumption SDR (On mode)
12 kWh/1000h
Power Consumption Sleep
0.5 Watt
Power supply type
Internal
Internal
Network
Ethernet LAN
Yes
No
Miscellaneous
Cables Included
1 x DisplayPort cable - 1.8 m 1 x USB-A to USB-B cable - 1.8 m
Compliant Standards
RoHS, TUV Rheinland Flicker Free Certification, China Energy standard Tier 1, TUV Rheinland Low Blue Light (Hardware Solution), TÜV Rheinland Low Blue Light, Eyesafe Certified 2.0, TUV Rheinland Eye Comfort Certification (5-star)
Energy Class
Class C
Features
Security lock slot (cable lock sold separately), Tiny support
Localisation
English / United Kingdom
Security Slot Type
Kensington security slot
Ergonomics
Adjustable height (max)
15.5 cm
15.5 cm
Cable lock slot
Yes
Yes
Cable lock slot type
Kensington
Kensington
Cable management
Yes
Height adjustment
Yes
Yes
Panel mounting interface
100 x 100 mm
100 x 100 mm
Pivot
Yes
Pivot angle
-90 - 90°
Swivel angle range
-45 - 45°
-45 - 45°
Swivelling
Yes
Yes
Tilt adjustment
Yes
Yes
Tilt angle range
-5 - 23.5°
-5 - 23.5°
VESA mounting
Yes
Yes
Performance
AMD FreeSync
No
No
Low Blue Light technology
Yes
Yes
NVIDIA G-SYNC
No
No
Windows operating systems supported
Windows 10, Windows 11
Weight & dimensions
Bezel width (bottom)
1.22 cm
Bezel width (side)
2 mm
2 mm
Bezel width (top)
2 mm
Depth (with stand)
220 mm
195 mm
Depth (without stand)
114.7 mm
46 mm
Dimensions & Weight Details
Without stand - width: 53.98 cm - depth: 4.53 cm - height: 31.48 cm - weight: 3 kg With stand (highest position) - width: 53.98 cm - depth: 19 cm - height: 50.58 cm - weight: 5.1 kg With stand (lowest position) - width: 53.98 cm - depth: 19 cm - height: 35.08 cm - weight: 5.1 kg
Height (with stand)
545.4 mm
539.3 mm
Height (without stand)
356.5 mm
357.1 mm
Weight (with stand)
9.2 kg
6.5 kg
Weight (without stand)
6.4 kg
4.3 kg
Width (with stand)
806.1 mm
613.6 mm
Width (without stand)
806.1 mm
613.6 mm
Multimedia
Built-in camera
No
No
Built-in microphone
No
No
Built-in speaker(s)
No
No
Ports & interfaces
Built-in USB hub
Yes
Yes
DisplayPort out quantity
0
0
DisplayPort version
1.4
1.4
DisplayPorts quantity
1
1
HDMI
Yes
Yes
HDMI ports quantity
1
1
HDMI version
2.1
2.1
Headphone out
No
Number of upstream ports
1
1
Number of USB Type-B upstream ports quantity
1
Number of USB Type-C upstream ports quantity
1
USB Power Delivery (USB PD)
Yes
USB Power Delivery up to
100 W
USB Type-A downstream ports quantity
3
3
USB Type-C DisplayPort Alternate Mode
Yes
No
USB Type-C downstream ports quantity
1
1
USB upstream port type
USB Type-C
USB Type-B
VGA (D-Sub) ports quantity
0
0
Packaging content
Cables included
DisplayPort, USB Type-C to USB Type-C
Quick start guide
Yes
Stand included
Yes
Other features
Certification
EU Energy Label (E-class) TCO Certified 10.0 TCO Edge 2.1 Eyesafe® Certified 2.0 TÜV Rheinland® Eye Comfort Certification (5-star) TÜV Rheinland® Flicker Free TÜV Rheinland® Low Blue Light (Hardware Solution)
ENERGY STAR Certified, TCO 10.0, TCO Edge 2.1, EPEAT Gold, RoHS, EU Energy Efficiency Level (Level-D), Eyesafe Display 2.0, TÜV Low Blue Light (Hardware solution), TÜV Rheinland Flicker Free, TÜV Low Blue Light, TÜV Rheinland Eye Comfort 3.0 (5 Stars)
Compliance certificates
RoHS
Ethernet LAN (RJ-45) ports
1
Ethernet LAN data rates
10,100,1000 Mbit/s
Video colour modes
BT.709
Design
Colour name
Eclipse black
Eclipse Black
Feet colour
Black
Front bezel colour
Black
Market positioning
Professional
Product colour
Black
Black
Mechanical
Display Position Adjustments
Height, pivot (rotation), swivel, tilt
Height Adjustment
155 mm
Rotation Angle
180
Swivel Angle
90
Tilt Angle
-5/23.5
VESA Mounting Interface
100 x 100 mm
Sustainability
ENERGY STAR Certified
Yes
EPEAT Compliant
EPEAT Gold
Sustainability certificates
ENERGY STAR, EPEAT Gold
TCO Certified
TCO Certified Edge Displays, TCO Certified, generation 10, for displays
Environmental Parameters
Humidity Range Operating
10 - 80% (non-condensing)
Max Operating Temperature
40 °C
Min Operating Temperature
0 °C
Software / System Requirements
Included Software
Lenovo ThinkColour
OS Required
Windows 10, Windows 11
Connectivity
Interfaces
USB-C 3.2 Gen 1 downstream (data, power up to 15W) 3 x USB 3.2 Gen 1 downstream USB-B 3.2 Gen 1 upstream HDMI DisplayPort 1.2 VGA
Packaging data
Package depth
186 mm
195 mm
Package height
495 mm
539.3 mm
Package weight
13.7 kg
Package width
980 mm
613.6 mm
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Dimensions & Weight (Shipping)
Shipping Depth
11.2 cm
Shipping Height
42.2 cm
Shipping Weight
7.3 kg
Shipping Width
73.4 cm
