Product Comparison

Technical Specifications

General
Aspect Ratio
16:9
16:9
Backlight Technology
WLED
WLED
Brightness
250 cd/m²
250 cd/m²
Built-in Devices
KVM Switch, 1080p webcam, USB 3.2 Gen 1 hub
USB 3.2 Gen 1 hub
Colour
Black
Raven black
Colour Gamut
99% sRGB
99% BT.709, 99% sRGB
Colour Support
16.7 million colours
16.7 million colours
Contrast Ratio
1000:1
1500:1 / 3000000:1 (dynamic)
Diagonal Size
22"
24"
Dimensions (WxDxH)
48.93 cm x 20.76 cm x 51.23 cm - with stand (highest position)
53.98 cm x 19 cm x 50.58 cm - with stand (highest position)
Display Type
LED-backlit LCD monitor / TFT active matrix
LED-backlit LCD monitor / TFT active matrix
Energy Class
Class D
Energy Label QR Code URL
Https://eprel.ec.europa.eu/qr/1541483
Features
2 mm bezel (side), Natural Low Blue Light technology
Integrated cable management, 8-bit Colour Depth, Natural Low Blue Light technology, modular camera support, ultra thin bezel design
Horizontal Refresh Rate
28 - 150 kHz
Horizontal Viewing Angle
178
178
Native Resolution
Full HD (1080p) 1920 x 1080 at 60 Hz
Full HD (1080p) 1920 x 1080 at 120 Hz
Panel Type
IPS
IPS
Pixel Per Inch
102
95
Pixel Pitch
0.248 mm
0.2745 mm
Response Time
4 ms (extreme), 6 ms (typical)
4 ms (extreme), 6 ms (normal)
Screen Coating
Anti-glare
Anti-glare
Vertical Refresh Rate
48 - 120 Hz
Vertical Viewing Angle
178
178
Viewable Size
23.8"
Weight
5.5 kg
5.1 kg
Display
Anti-glare screen
Yes
Backlight type
W-LED
Colour depth
8 bit
Colour gamut
99%
Colour gamut standard
sRGB
Contrast ratio (dynamic)
3000000:1
Contrast ratio (typical)
1000:1
Display brightness (typical)
250 cd/m²
Display diagonal
54.6 cm (21.5")
Display number of colours
16.7 million colours
Display resolution
1920 x 1080 pixels
Display technology
LED
HD type
Full HD
Maximum refresh rate
60 Hz
Native aspect ratio
16:9
Panel type
IPS
Pixel density
102 ppi
Pixel pitch
0.248 x 0.248 mm
Response time
6 ms
Response time (fast)
4 ms
Screen shape
Flat
sRGB coverage (typical)
99%
Touchscreen
No
Viewable size, horizontal
47.6 cm
Viewable size, vertical
26.8 cm
Viewing angle, horizontal
178°
Viewing angle, vertical
178°
Power
AC input frequency
50/60 Hz
AC input voltage
100 - 240 V
Input Voltage
AC 100-240 V (50/60 Hz)
AC 100-240 V (50/60 Hz)
Power Consumption (Max)
33 Watt
66 Watt
Power consumption (max)
33 W
Power Consumption (Off Mode)
0.3 Watt
Power consumption (off)
0.5 W
Power consumption (standby)
0.3 W
Power Consumption (Typical)
13.4 Watt
12 Watt
Power consumption (typical)
13.4 W
Power Consumption SDR (On mode)
12 kWh/1000h
12 kWh/1000h
Power Consumption Sleep
0.5 Watt
Power supply type
External
Audio Input
Type
Microphone
Miscellaneous
Cables Included
1 x DisplayPort cable - 1.8 m 1 x USB-A to USB-B cable - 1.8 m
Compliant Standards
RoHS, TUV Rheinland Eye Comfort Certification, TUV Rheinland Low Blue Light (Hardware Solution), Eyesafe Certified 2.0
RoHS, TUV Rheinland Flicker Free Certification, China Energy standard Tier 1, TUV Rheinland Low Blue Light (Hardware Solution), TÜV Rheinland Low Blue Light, Eyesafe Certified 2.0, TUV Rheinland Eye Comfort Certification (5-star)
Energy Class
Class C
Features
Tiny support
Security lock slot (cable lock sold separately), Tiny support
Localisation
English / United Kingdom
English / United Kingdom
Security Slot Type
Kensington security slot
Viewable Size
21.5"
Ergonomics
Adjustable height (max)
15.5 cm
Cable lock slot
Yes
Cable lock slot type
Kensington
Cable management
Yes
Height adjustment
Yes
On Screen Display (OSD)
Yes
Panel mounting interface
100 x 100 mm
Pivot
Yes
Pivot angle
-5 - 90°
Swivel angle range
-45 - 45°
Swivelling
Yes
Tilt angle range
-5 - 23.5°
VESA mounting
Yes
Performance
AMD FreeSync
No
Low Blue Light technology
Yes
NVIDIA G-SYNC
No
Weight & dimensions
Bezel width (bottom)
4.6 cm
Bezel width (side)
2 mm
Bezel width (top)
2 mm
Depth (with stand)
207.6 mm
Depth (without stand)
72.8 mm
Dimensions & Weight Details
With stand (highest position) - width: 48.93 cm - depth: 20.76 cm - height: 51.23 cm - weight: 5.5 kg With stand (lowest position) - width: 48.93 cm - depth: 20.76 cm - height: 35.73 cm - weight: 5.5 kg Without stand - width: 48.93 cm - depth: 7.28 cm - height: 33.91 cm - weight: 3.2 kg
Without stand - width: 53.98 cm - depth: 4.53 cm - height: 31.48 cm - weight: 3 kg With stand (highest position) - width: 53.98 cm - depth: 19 cm - height: 50.58 cm - weight: 5.1 kg With stand (lowest position) - width: 53.98 cm - depth: 19 cm - height: 35.08 cm - weight: 5.1 kg
Height (with stand)
512.3 mm
Height (without stand)
339.1 mm
Weight (with stand)
5.5 kg
Weight (without stand)
3.2 kg
Width (with stand)
489.3 mm
Width (without stand)
489.3 mm
Multimedia
Built-in camera
Yes
Built-in microphone
Yes
Built-in speaker(s)
Yes
Number of speakers
2
RMS rated power
6 W
Ports & interfaces
Built-in USB hub
Yes
DisplayPort version
1.2
DisplayPorts quantity
1
HDMI
Yes
HDMI ports quantity
1
HDMI version
1.4
Number of upstream ports
1
Number of USB Type-B upstream ports quantity
1
USB hub version
3.2 Gen 1 (3.1 Gen 1)
USB Type-A downstream ports quantity
1
USB upstream port type
USB Type-B
Packaging content
Cables included
AC
Power adapter included
Yes
Power cable length
1 m
Quick start guide
Yes
Stand included
Yes
Other features
Certification
EU Energy Label (D-class) ENERGY STAR® Certified EPEAT™ Gold Registered TCO Certified 9.0 TCO edge 2.0 Volatile Organic Compound Certification RoHS compliant Eyesafe Display 2.0, TÜV Low Blue Light (Hardware solution), TÜV Rheinland Eye Comfort
Compatible operating systems
Windows 10, Windows 11
Warranty period
3 year(s)
Mechanical
Display Position Adjustments
Height, pivot (rotation), swivel, tilt
Height, pivot (rotation), swivel, tilt
Height Adjustment
155 mm
Rotation Angle
180
Swivel Angle
90
Tilt Angle
-5/23.5
VESA Mounting Interface
100 x 100 mm
100 x 100 mm
Sustainability
ENERGY STAR Certified
Yes
Yes
EPEAT Compliant
EPEAT Gold
EPEAT Gold
TCO Certified
TCO Certified Edge Displays, TCO Certified, generation 10, for displays
Environmental Parameters
Humidity Range Operating
10 - 80% (non-condensing)
Max Operating Temperature
40 °C
Min Operating Temperature
0 °C
Software / System Requirements
Included Software
Lenovo ThinkColour
Lenovo ThinkColour
OS Required
Windows 10, Windows 11
Windows 10, Windows 11
Connectivity
Interfaces
DisplayPort 1.2 HDMI USB 3.2 Gen 1 USB-B 3.2 Gen 1 upstream
USB-C 3.2 Gen 1 downstream (data, power up to 15W) 3 x USB 3.2 Gen 1 downstream USB-B 3.2 Gen 1 upstream HDMI DisplayPort 1.2 VGA
Built-in Webcam
Max Video Resolution
1080p
Audio
Output Power / Channel
3 Watt
Type
Speakers - stereo
Packaging data
Package depth
176 mm
Package height
422 mm
Package weight
8.1 kg
Package width
568 mm
Design
Product colour
Black
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Limited warranty - 3 years
Dimensions & Weight (Shipping)
Shipping Depth
17.6 cm
11.2 cm
Shipping Height
42.2 cm
42.2 cm
Shipping Weight
8.1 kg
7.3 kg
Shipping Width
56.8 cm
73.4 cm
Input
Type
Touchscreen
