Compare TP-Link LAN - Media Converters
Comparing 4 products side-by-side — specifications, pricing and stock. Showing TP-Link products in the LAN - Media Converters category.
| Specification | ||||
|---|---|---|---|---|
| Power | ||||
| Power consumption (max) | 2.4 W | 1.8 W | 1.7 W | 2.49 W |
| Network | ||||
| Auto MDI/MDI-X | Yes | Yes | Yes | Yes |
| Cable types supported | Cat3, Cat4, Cat5, Cat5e | Cat5, Cat5e | Cat5, Cat5e, Cat6 | Cat3, Cat4, Cat5, Cat5e |
| Copper ethernet cabling technology | — | 1000BASE-LX, 1000BASE-T | — | — |
| Duplex system | Full, Half | — | Full, Half | Full, Half |
| Ethernet interface type | — | Gigabit Ethernet | Gigabit Ethernet | — |
| Ethernet LAN data rates | 10,100 Mbit/s | — | 10,100,1000 Mbit/s | 10,100 Mbit/s |
| Maximum data transfer rate | 100 Mbit/s | 1000 Mbit/s | 1000 Mbit/s | 100 Mbit/s |
| Networking standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x | IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3z | IEEE 802.3ab, IEEE 802.3x, IEEE 802.3z | IEEE 802.3, IEEE 802.3u |
| Certificates | ||||
| Compliance certificates | RoHS | RoHS | RoHS | RoHS |
| Ports & interfaces | ||||
| Connectivity technology | Wired | Wired | Wired | Wired |
| Ethernet LAN (RJ-45) ports | 1 | 1 | 1 | 1 |
| Fiber optic connector | SC | SC | SFP | SC |
| Fiber ports quantity | 1 | 1 | 1 | 1 |
| Weight & dimensions | ||||
| Depth | 73 mm | 73 mm | 73 mm | 73 mm |
| Height | 27 mm | 27 mm | 27 mm | 27 mm |
| Width | 95 mm | 95 mm | 94 mm | 95 mm |
| Performance | ||||
| Fiber mode structure | Multi-mode | Single-mode | Multi-mode, Single-mode | Single-mode |
| Maximum transfer distance | 2000 m | 15000 m | 10000 m | 20000 m |
| Wavelength | 1310 nm | 1310 nm | — | — |
| Wavelength-division multiplexing (WDM) | — | — | — | Yes |
| Logistics data | ||||
| Harmonized System (HS) code | 85176990 | 85176990 | 85176990 | 85176990 |
| Features | ||||
| Internal | No | No | No | No |
| LED indicators | Yes | Yes | Yes | Yes |
| Product colour | Black | Black | Black | Black |
| Packaging content | ||||
| Manual | Yes | — | — | Yes |
| Operational conditions | ||||
| Operating relative humidity (H-H) | 10 - 90% | 10 - 90% | 10 - 90% | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C | 0 - 40 °C | 0 - 40 °C | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90% | 5 - 90% | 5 - 90% | 5 - 90% |
| Storage temperature (T-T) | -40 - 70 °C | -40 - 70 °C | -40 - 70 °C | -40 - 70 °C |
| Packaging data | ||||
| Package depth | — | — | 204 mm | — |
| Package height | — | — | 65 mm | — |
| Package weight | — | — | 440 g | — |
| Package width | — | — | 65 mm | — |
