Compare TP-Link Access Point/Extenders
Comparing 5 products side-by-side — specifications, pricing and stock. Showing TP-Link products in the Access Point/Extenders category.
| Specification | |||||
|---|---|---|---|---|---|
| Power | |||||
| AC input frequency | — | — | — | 50/60 Hz | — |
| AC input voltage | — | — | — | 100 - 240 V | — |
| DC voltage range | — | — | — | — | 12 V |
| Output current | — | — | 0.6 A | — | — |
| Output voltage | — | 24 V | 9 V | — | — |
| Power consumption (max) | — | — | — | 9.5 W | — |
| Power consumption (typical) | — | 10.5 W | — | — | — |
| Power over Ethernet (PoE) | — | Yes | Yes | — | Yes |
| Power over Ethernet (PoE) type supported | — | Passive PoE | — | — | — |
| Network | |||||
| Cabling technology | — | — | — | 10/100Base-T(X) | — |
| Ethernet LAN interface type | — | — | — | Fast Ethernet | — |
| Networking standards | — | — | — | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n | — |
| Security algorithms | — | — | — | 64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK | — |
| Top Wi-Fi standard | — | — | — | Wi-Fi 5 (802.11ac) | — |
| Wi-Fi | — | — | — | Yes | — |
| Wi-Fi band | — | — | — | Dual-band (2.4 GHz / 5 GHz) | — |
| Wi-Fi data rate (max) | — | — | — | 867 Mbit/s | — |
| Wi-Fi standards | — | — | — | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) | — |
| WLAN data transfer rates supported | — | — | — | 300 Mbit/s | — |
| Features | |||||
| 2.4 GHz | Yes | Yes | Yes | — | Yes |
| 5 GHz | Yes | Yes | No | — | Yes |
| 6 GHz | Yes | No | No | — | No |
| Airtime Fairness (ATF) | Yes | Yes | — | — | Yes |
| Automatic channel scanning | — | — | — | — | Yes |
| Automatic channel selection | — | — | — | — | Yes |
| Band steering | — | Yes | — | — | Yes |
| BeamForming | Yes | Yes | — | — | Yes |
| Bluetooth | Yes | — | — | — | — |
| Bluetooth version | 5.2 | — | — | — | — |
| Ethernet LAN data rates | 2500 Mbit/s | 10,100,1000 Mbit/s | 10,100 Mbit/s | — | 10,100,1000,2500 Mbit/s |
| Flow control support | — | — | — | — | Yes |
| Frequency band | — | 2.4 - 5 GHz | — | — | 2.4 - 5 GHz |
| Maximum data transfer rate | 9300 Mbit/s | 1200 Mbit/s | 300 Mbit/s | — | 5400 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 574 Mbit/s | 300 Mbit/s | 300 Mbit/s | — | 574 Mbit/s |
| Maximum data transfer rate (5 GHz) | 2880 Mbit/s | 867 Mbit/s | — | — | 4804 Mbit/s |
| Maximum data transfer rate (6 GHz) | 5760 Mbit/s | — | — | — | — |
| MIMO | Yes | Yes | — | — | Yes |
| MIMO type | Multi User MIMO | Multi User MIMO | — | — | Multi User MIMO |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n | — | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Number of users | 380 user(s) | — | — | — | 250 user(s) |
| Quality of Service (QoS) support | Yes | Yes | — | — | Yes |
| Rate limiting | — | Yes | — | — | Yes |
| Transmitting power (CE) | — | 27 dBm | — | — | — |
| Transmitting power (FCC) | — | 22 dBm | 20 dBm | — | — |
| Virtual LAN features | — | VLAN mapping | — | — | VLAN mapping |
| VLAN support | Yes | Yes | — | — | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | — | Yes | Yes | — | — |
| Wireless isolation | — | — | Yes | — | — |
| Packaging content | |||||
| AC adapter included | No | Yes | Yes | — | — |
| Cables included | — | — | LAN (RJ-45) | — | — |
| Mounting kit | Yes | Yes | — | — | Yes |
| PoE adapter included | — | — | Yes | — | — |
| Quantity per pack | 1 pc(s) | 1 pc(s) | — | — | 1 pc(s) |
| Quick start guide | — | Yes | Yes | Yes | Yes |
| Security | |||||
| Access Control List (ACL) | Yes | Yes | — | — | — |
| Auto Wireless Distribution System (WDS) | — | — | Yes | — | — |
| MAC address filtering | Yes | Yes | Yes | — | — |
| Number of SSID supported | 24 | 16 | — | — | — |
| Remote Authentication Dial-In User Service (RADIUS) | Yes | — | — | — | — |
| Security algorithms | SNMP, SNMPv2, SNMPv3, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal | 802.1x RADIUS | WPA, WPA-PSK, WPA2, WPA2-PSK | — | SNMP, SNMPv2, SNMPv3, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise |
| Service Set Identifier (SSID) features | Multiple SSIDs | Multiple SSIDs | Multiple SSIDs | — | — |
| Antenna | |||||
| Antenna direction type | — | Omni-directional | Omni-directional | — | — |
| Antenna features | — | Detachable antenna | — | — | — |
| Antenna gain level (max) | — | 4 dBi | — | — | — |
| Antenna type | Internal | External | External | External | Internal |
| Antennas quantity | — | 2 | 2 | 2 | — |
| Transmitting power (CE) | — | — | — | 2.4 GHz ≤20dBm, 5 GHz ≤30dBm | — |
| Performance | |||||
| Browser supported | — | — | — | Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 | — |
| Compatible operating systems | — | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux | — | — | — |
| Data transfer rate | — | — | — | 867 Mbit/s | — |
| Ethernet LAN data rates | — | — | — | 10,100 Mbit/s | — |
| Linux operating systems supported | — | — | — | Yes | — |
| Mac compatibility | — | — | — | Yes | — |
| Mac operating systems supported | — | — | — | Yes | — |
| Type | — | — | — | Network repeater | — |
| Windows operating systems supported | — | — | — | Yes | — |
| WPS push button | — | — | — | Yes | — |
| Certificates | |||||
| Certification | CE, FCC, RoHS, IC | — | — | — | — |
| Compliance certificates | — | CE, Federal Communications Commission (FCC), RoHS | Federal Communications Commission (FCC), RoHS | CE, RoHS | — |
| Design | |||||
| Certification | — | — | — | CE, RoHS | — |
| International Protection (IP) code | — | IP65 | — | — | — |
| LED indicators | Yes | — | — | Yes | Yes |
| On/off switch | — | — | Yes | — | — |
| Placement | Ceiling, Wall | Pole, Wall | Floor, Table | — | Ceiling, Wall |
| Product colour | White | White | White | White | White |
| Quantity per pack | — | — | — | 1 pc(s) | — |
| Reset button | — | Yes | Yes | Yes | Yes |
| WPS push button | — | — | Yes | — | — |
| Ports & interfaces | |||||
| DC-in jack | — | — | — | — | Yes |
| Ethernet LAN (RJ-45) ports | 1 | 1 | 1 | 1 | 1 |
| USB 2.0 ports quantity | 0 | 0 | 0 | — | 0 |
| Weight & dimensions | |||||
| Depth | 220 mm | 46 mm | 129.5 mm | 35 mm | 220 mm |
| Height | 32.5 mm | 27 mm | 36.2 mm | 124.1 mm | 32.5 mm |
| Width | 220 mm | 215 mm | 181.6 mm | 89 mm | 220 mm |
| Management features | |||||
| Firmware upgradeable | — | — | — | — | Yes |
| Syslog | — | Yes | — | — | Yes |
| Web-based management | Yes | Yes | — | — | Yes |
| Logistics data | |||||
| Harmonized System (HS) code | — | 85176990 | 85176990 | 85176990 | — |
| Protocols | |||||
| Management protocols | — | — | SNMP | — | — |
| Other features | |||||
| Maximum operating distance | — | — | 30 m | — | — |
| Operational conditions | |||||
| Operating relative humidity (H-H) | 10 - 90% | 10 - 90% | 10 - 90% | 10 - 90% | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C | -30 - 70 °C | 0 - 40 °C | 0 - 40 °C | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90% | 5 - 90% | 5 - 90% | 5 - 90% | 5 - 90% |
| Storage temperature (T-T) | -40 - 70 °C | -40 - 70 °C | -40 - 70 °C | -40 - 70 °C | -40 - 70 °C |
| Packaging data | |||||
| Package depth | — | 270 mm | 223 mm | 89 mm | — |
| Package height | — | 100 mm | 70 mm | 156.5 mm | — |
| Package type | — | — | — | Box | — |
| Package weight | — | 640 g | 560 g | 260 g | — |
| Package width | — | 140 mm | 310 mm | 121.5 mm | — |
| Sustainability | |||||
| Sustainability compliance | — | Yes | Yes | — | — |
