Compare TP-Link Routers
Comparing 5 products side-by-side — specifications, pricing and stock. Showing TP-Link products in the Routers category.
| Specification | TP-Link TP-Link Omada ER7412-M2 V1 - Router 12-port switch - 1GbE, 2.5GbE - WAN ports: 12 - rack-mountableER7412-M2 £212.97 £255.56 inc VAT | TP-Link TP-Link Omada ER706W-4G V1 - Wireless router - WWAN 5-port switch - 1GbE - WAN ports: 6 - Wi-Fi 6 - Dual Band - 4G - wall-mountableER706W-4G £194.71 £233.65 inc VAT | |||
|---|---|---|---|---|---|
| Power | |||||
| AC input frequency | 50 - 60 Hz | 50/60 Hz | — | — | — |
| AC input voltage | 100 - 240 V | 100 - 240 V | — | — | — |
| Battery capacity | — | — | — | 2000 mAh | — |
| Output current | — | — | — | 1 A | 1 A |
| Output voltage | — | — | — | 5 V | 12 V |
| Power consumption (max) | — | 18.5 W | — | — | — |
| Power source type | — | — | AC | Battery | — |
| Network | |||||
| Cabling technology | 10/100/1000Base-T(X) | — | — | — | 10/100/1000Base-T(X) |
| Dynamic DNS (DDNS) | — | — | Yes | — | — |
| Ethernet interface type | Gigabit Ethernet | 2.5 Gigabit Ethernet, Gigabit Ethernet | — | — | Gigabit Ethernet |
| Ethernet LAN | — | — | Yes | — | — |
| Ethernet LAN data rates | 10,100,1000 Mbit/s | 10,100,1000,2500 Mbit/s | — | — | 10,100,1000 Mbit/s |
| Ethernet LAN interface type | — | — | Gigabit Ethernet | — | — |
| Networking standards | IEEE 802.1Q | IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z | — | — | IEEE 802.3, IEEE 802.3ab, IEEE 802.3q, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Port forwarding | Yes | — | — | — | Yes |
| Static route | Yes | Yes | — | — | Yes |
| VLAN support | Yes | Yes | — | — | Yes |
| VPN Passthrough | — | — | Yes | — | — |
| Mobile network | |||||
| 3G bands supported | — | — | — | 850,900,2100 MHz | — |
| 3G standards | — | — | HSDPA, HSUPA, WCDMA | HSPA, HSPA+, UMTS | — |
| 4G bands supported | — | — | 800,850,900,1800,2100,2300,2500,2600 MHz | 800,850,900,1800,2100,2300,2500,2600 MHz | — |
| 4G standard | — | — | LTE-TDD & LTE-FDD | LTE-FDD | — |
| Data network | — | — | — | 3G, 4G, LTE | — |
| Mobile network generation | — | — | 4G | — | — |
| SIM card type | — | — | NanoSIM | MicroSIM | — |
| UMTS bands supported | — | — | — | 850,900,2100 MHz | — |
| WAN connection | |||||
| 3G/4G USB modem compatibility | No | Yes | No | — | No |
| DSL WAN | No | No | No | — | No |
| Ethernet WAN | Yes | Yes | Yes | — | Yes |
| SFP WAN | Yes | Yes | — | — | Yes |
| SIM card slot | No | No | Yes | — | No |
| Packaging content | |||||
| AC adapter included | Yes | — | — | — | — |
| Cables included | — | AC, LAN (RJ-45) | — | Micro-USB | — |
| Manual | Yes | — | — | — | — |
| Quick start guide | — | Yes | — | — | — |
| Security | |||||
| Access Control List (ACL) | Yes | Yes | Yes | — | — |
| ARP attack prevention | — | Yes | — | — | — |
| DoS attack prevention | — | Yes | — | — | — |
| ICMP attack prevention | — | Yes | — | — | — |
| NAT functionality | One-to-One NAT; Multi-Net NAT; Virtual Server; Port Triggering; NAT-DMZ; FTP/H.323/SIP/IPSec/PPTP ALG; UPnP; | — | • One-to-One NAT • Multi-Net NAT • Virtual Server • Port Triggering† • NAT-DMZ • FTP/H.323/SIP/IPSec/PPTP ALG • UPnP | — | — |
| Network address translation (NAT) | — | Yes | Yes | — | — |
| Security algorithms | — | 128-bit AES, 192-bit AES, 256-bit AES, DES, MD5, SHA-1, SHA-2, SHA-384, SHA-512 | — | SSID, WPA-PSK, WPA2-PSK | SNMP, SNMPv2, SNMPv3 |
| URL filtering | Yes | Yes | Yes | — | — |
| VPN tunnels quantity | — | 80 | — | — | 50 |
| Antenna | |||||
| Antenna design | — | — | External | — | — |
| Antennas quantity | — | — | 5 | — | — |
| Management features | |||||
| Bandwidth control | — | — | Yes | — | — |
| MIMO | — | — | Yes | — | — |
| MU-MIMO technology | — | — | Yes | — | — |
| Reset button | Yes | Yes | Yes | — | Yes |
| Universal Plug and Play (UPnP) | Yes | Yes | — | — | Yes |
| Web-based management | — | Yes | — | — | Yes |
| Features | |||||
| Built-in processor | Yes | — | — | — | — |
| Certification | CE, FCC, RoHS | — | — | — | — |
| Flash memory | 256 MB | 128 MB | 128 MB | — | 128 MB |
| Internal memory | 4096 MB | 1024 MB | 512 MB | — | 512 MB |
| Internal memory type | DDR4 | DDR4 | DDR4 | — | DDR4 |
| Linux operating systems supported | — | Yes | — | — | — |
| Mac operating systems supported | — | Yes | — | — | — |
| Windows operating systems supported | — | Windows 10, Windows 11, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP | — | — | — |
| Certificates | |||||
| Certification | — | — | — | CE, RoHS | — |
| Compliance certificates | — | CE, Federal Communications Commission (FCC) | — | CE, RoHS | — |
| Ports & interfaces | |||||
| Combo SFP ports quantity | 2 | — | — | — | — |
| DC-in jack | Yes | — | — | — | Yes |
| Ethernet LAN (RJ-45) ports | 8 | 7 | 5 | — | 5 |
| Number of console ports | — | 1 | — | — | — |
| SFP module slots quantity | — | 2 | — | — | 1 |
| USB port | — | — | No | Yes | — |
| USB port type | — | — | — | Micro-USB | — |
| USB ports quantity | 2 | 1 | — | — | 1 |
| USB version | — | — | — | — | 3.2 Gen 1 (3.1 Gen 1) |
| WAN/Ethernet LAN ports quantity | — | 2 | — | — | — |
| Weight & dimensions | |||||
| Depth | 220 mm | 180 mm | 131 mm | 56.7 mm | 131 mm |
| Height | 44 mm | 44 mm | 35 mm | 19.8 mm | 35 mm |
| Width | 440 mm | 294 mm | 226 mm | 94 mm | 226 mm |
| Design | |||||
| Device type | — | — | — | Cellular network router | — |
| LED indicators | Yes | — | LAN, LTE, Status, System, WAN | Power, WLAN | Yes |
| Product colour | Black | Black | Black | Black | Black |
| Product type | — | — | Desktop/pole router | — | — |
| Rack mounting | — | Yes | — | — | — |
| Reset button | — | — | — | Yes | — |
| Protocols | |||||
| DHCP client | Yes | — | — | — | Yes |
| DHCP server | Yes | Yes | Yes | — | Yes |
| DMZ support | — | Yes | — | — | — |
| Ethernet LAN features | |||||
| DHCP client | — | — | — | Yes | — |
| DHCP server | — | — | — | Yes | — |
| Ethernet LAN | — | — | — | No | — |
| Networking standards | — | — | — | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n | — |
| Performance | |||||
| Mac operating systems supported | — | — | — | Yes | — |
| Mobile operating systems supported | — | — | — | Android, Windows Phone, iOS | — |
| Web-based management | — | — | — | Yes | — |
| Windows operating systems supported | — | — | — | Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP | — |
| Operational conditions | |||||
| Operating relative humidity (H-H) | 10 - 90% | 10 - 90% | 10 - 90% | 10 - 90% | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C | 0 - 45 °C | 0 - 40 °C | 0 - 35 °C | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90% | 5 - 90% | 5 - 90% | 5 - 90% | 5 - 90% |
| Storage temperature (T-T) | -40 - 70 °C | -40 - 70 °C | -40 - 70 °C | -20 - 60 °C | -40 - 70 °C |
| Packaging data | |||||
| Package depth | 528 mm | — | — | 95 mm | — |
| Package height | 100 mm | — | — | 50 mm | — |
| Package weight | 3.68 kg | — | — | 150 g | — |
| Package width | 336 mm | — | — | 135 mm | — |
| Sustainability | |||||
| Sustainability compliance | — | — | — | Yes | — |
| Wireless LAN features | |||||
| Top Wi-Fi standard | — | — | Wi-Fi 6 (802.11ax) | — | — |
| Wi-Fi | — | — | — | Yes | — |
| Wi-Fi band | — | — | Dual-band (2.4 GHz / 5 GHz) | — | — |
| Wi-Fi standards | — | — | — | 802.11b, 802.11g, Wi-Fi 4 (802.11n) | — |
| WLAN data transfer rate (max) | — | — | 2402 Mbit/s | — | — |
| WLAN data transfer rates supported | — | — | — | 300 Mbit/s | — |
