Compare TP-Link Access Point/Extenders
Comparing 5 products side-by-side — specifications, pricing and stock. Showing TP-Link products in the Access Point/Extenders category.
| Specification | |||||
|---|---|---|---|---|---|
| Power | |||||
| AC input frequency | 50/60 Hz | 50/60 Hz | — | — | — |
| AC input voltage | 100 - 240 V | 100 - 240 V | — | — | — |
| Power consumption (max) | 10 W | 9.5 W | — | — | — |
| Power consumption (typical) | — | — | 3 W | — | 12 W |
| Power over Ethernet (PoE) | — | — | — | — | Yes |
| Network | |||||
| Cabling technology | 10/100/1000Base-T(X) | 10/100Base-T(X) | — | — | — |
| Ethernet LAN interface type | Gigabit Ethernet | Fast Ethernet | — | — | — |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n | — | — | — |
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK | 64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK | WEP, WPA-PSK, WPA2-PSK | — | — |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) | Wi-Fi 5 (802.11ac) | — | — | — |
| Wi-Fi | Yes | Yes | Yes | — | — |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) | Dual-band (2.4 GHz / 5 GHz) | — | — | — |
| Wi-Fi data rate (max) | 1200 Mbit/s | 867 Mbit/s | — | — | — |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) | 802.11b, 802.11g, Wi-Fi 4 (802.11n) | — | — |
| WLAN data transfer rates supported | 300 Mbit/s | 300 Mbit/s | — | — | — |
| Features | |||||
| 2.4 GHz | — | — | — | — | Yes |
| 5 GHz | — | — | — | — | Yes |
| 6 GHz | — | — | — | — | No |
| Airtime Fairness (ATF) | — | — | — | — | Yes |
| Automatic channel selection | — | — | — | — | Yes |
| Band steering | — | — | — | — | Yes |
| BeamForming | — | — | — | — | Yes |
| Cabling technology | — | — | — | — | 10/100/1000Base-T(X) |
| Ethernet LAN data rates | — | — | — | — | 10,100,1000 Mbit/s |
| Frequency band | — | — | — | — | 2.4, 5 GHz |
| Housing material | — | — | — | Plastic | — |
| Maximum data transfer rate | — | — | — | — | 2402 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | — | — | — | — | 574 Mbit/s |
| Maximum data transfer rate (5 GHz) | — | — | — | — | 2402 Mbit/s |
| Networking standards | — | — | — | — | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
| Number of users | — | — | — | — | 100 user(s) |
| Product colour | — | — | — | White | — |
| Quality of Service (QoS) support | — | — | — | — | Yes |
| Rate limiting | — | — | — | — | Yes |
| Transmitting power (CE) | — | — | — | — | 20 - 23 - 26 dBm |
| Transmitting power (FCC) | — | — | — | — | 21 - 21 dBm |
| VLAN support | — | — | — | — | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | — | — | — | — | Yes |
| Wireless isolation | — | — | — | — | Yes |
| Security | |||||
| Access Control List (ACL) | — | — | — | — | Yes |
| IP address filtering | — | — | — | — | Yes |
| MAC address filtering | — | — | — | — | Yes |
| Number of SSID supported | — | — | — | — | 16 |
| Remote Authentication Dial-In User Service (RADIUS) | — | — | — | — | Yes |
| Security algorithms | — | — | — | — | HTTPS, SNMP, SNMPv2, SNMPv3, SSH, WPA-Enterprise, WPA2-Enterprise, WPA3-Enterprise |
| Service Set Identifier (SSID) features | — | — | — | — | Multiple SSIDs |
| Performance | |||||
| Antenna gain level (max) | — | — | — | 23 dBi | — |
| Browser supported | Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 | Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 | — | — | — |
| Built-in processor | — | — | — | Yes | — |
| Compatible operating systems | — | — | — | — | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows 11, Linux |
| Data transfer rate | 1200 Mbit/s | 867 Mbit/s | 300 Mbit/s | — | — |
| Ethernet LAN data rates | 10,100,1000 Mbit/s | 10,100 Mbit/s | 10,300 Mbit/s | — | — |
| Flash memory | — | — | — | 8 MB | — |
| Frequency band | — | — | — | 5 GHz | — |
| Internal memory | — | — | — | 64 MB | — |
| Internal memory type | — | — | — | DDR2 | — |
| Linux operating systems supported | Yes | Yes | — | — | — |
| Mac compatibility | Yes | Yes | — | — | — |
| Mac operating systems supported | Yes | Yes | — | — | — |
| Networking standards | — | — | — | IEEE 802.11a, IEEE 802.11n | — |
| Plug and Play | Yes | — | — | — | — |
| Processor frequency | — | — | — | 560 MHz | — |
| Processor model | — | — | — | Atheros MIPS 74Kc | — |
| Type | Network transmitter & receiver | Network repeater | Network repeater | — | — |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 2000, Windows 2000 Professional, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 98SE, Windows Vista, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows Vista x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 | Yes | — | — | — |
| WPS push button | Yes | Yes | — | — | — |
| Antenna | |||||
| Antenna gain level (max) | — | — | — | — | 5 dBi |
| Antenna type | External | External | — | — | Internal |
| Antennas quantity | 2 | 2 | — | — | 2 |
| Transmitting power (CE) | 2.4 GHz ≤20dBm, 5 GHz ≤30dBm | 2.4 GHz ≤20dBm, 5 GHz ≤30dBm | 20 dBm | — | — |
| Design | |||||
| Cable lock slot | — | — | — | — | No |
| Certification | — | CE, RoHS | — | — | — |
| LED indicators | Power, WAN, WLAN | Yes | — | — | Yes |
| Placement | — | — | — | — | Wall |
| Product colour | White | White | White | — | White |
| Quantity per pack | 1 pc(s) | 1 pc(s) | — | — | — |
| Reset button | Yes | Yes | — | — | Yes |
| Group 41455 | |||||
| Certification | — | — | — | CE, FCC | — |
| Compliance certificates | — | — | — | RoHS | — |
| Certificates | |||||
| Certification | — | — | — | — | FCC, RoHS |
| Compliance certificates | RoHS | CE, RoHS | RoHS | — | RoHS |
| Ports & interfaces | |||||
| DC-in jack | — | — | — | — | Yes |
| Ethernet LAN (RJ-45) ports | 1 | 1 | 1 | — | 4 |
| Host interface | — | — | RJ-45 | — | — |
| USB 2.0 ports quantity | — | — | — | — | 0 |
| WAN connection | — | — | — | — | Ethernet (RJ-45) |
| Weight & dimensions | |||||
| Depth | 46 mm | 35 mm | 65.8 mm | — | 86 mm |
| Height | 124.8 mm | 124.1 mm | 110 mm | — | 42.6 mm |
| Width | 74 mm | 89 mm | 75.2 mm | — | 143 mm |
| Management features | |||||
| Firmware upgradeable | — | — | — | — | Yes |
| Syslog | — | — | — | — | Yes |
| Web-based management | — | — | — | — | Yes |
| Logistics data | |||||
| Harmonized System (HS) code | 85176990 | 85176990 | 85176990 | 85177100 | — |
| Group 4023 | |||||
| Input voltage | — | — | — | 16 - 27 V | — |
| Packaging content | |||||
| Mounting kit | — | — | — | — | Yes |
| Quantity per pack | — | — | — | — | 1 pc(s) |
| Quick start guide | Yes | Yes | — | — | — |
| Operational conditions | |||||
| Operating relative humidity (H-H) | 10 - 90% | 10 - 90% | 10 - 90% | — | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C | 0 - 40 °C | 0 - 40 °C | — | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90% | 5 - 90% | 5 - 90% | — | 5 - 90% |
| Storage temperature (T-T) | -40 - 70 °C | -40 - 70 °C | -40 - 70 °C | — | -40 - 70 °C |
| Packaging data | |||||
| Package depth | 125 mm | 89 mm | — | — | 184 mm |
| Package height | 97 mm | 156.5 mm | — | — | 56 mm |
| Package type | Box | Box | — | — | Box |
| Package weight | 400 g | 260 g | — | — | 400 g |
| Package width | 202 mm | 121.5 mm | — | — | 117 mm |
| Group 11371 | |||||
| Quick installation guide | — | — | — | Yes | — |
| Sustainability | |||||
| Sustainability compliance | — | — | Yes | — | — |
