Compare Zyxel Hubs & Switches
Comparing 5 products side-by-side — specifications, pricing and stock. Showing Zyxel products in the Hubs & Switches category.
| Specification | Zyxel Zyxel XMG1915-18EP, 16-port 2.5GbE, 2 SFP+, 8 x PoE++ 180W Smart Switch, hybird mode, standalone or NebulaFlex CloudXMG1915-18EP-GB0101F £342.93 £411.52 inc VAT | Zyxel Zyxel GS1350-6HP - Switch - smart - 5 x 10/100/1000 (PoE+) + 1 x Gigabit SFP (uplink) - desktop - PoE+ (250 W)GS1350-6HP-GB0101F £112.80 £135.36 inc VAT | |||
|---|---|---|---|---|---|
| General | |||||
| Authentication Method | RADIUS | — | — | — | RADIUS, TACACS+ |
| Built-in Devices | — | Led panel | — | — | — |
| Capacity | — | — | — | — | QoS hardware queues per port: 8 |
| Device Type | Switch - 8 ports - smart | Switch - 24 ports - unmanaged | — | — | Switch - 24 ports - smart |
| Enclosure Type | Desktop, wall-mountable | Desktop, rack-mountable, wall-mountable | — | — | — |
| Encryption Algorithm | SSL | — | — | — | SSL |
| Features | Flow control, IGMP snooping, Syslog support, port mirroring, IPv6 support, firmware upgradable, STP support, QoS, fanless, LLDP support, DHCP client, SPQ, CoS, Storm Control, ICMP, rate limit, schedule PoE, Voice VLAN, LLDP-MED, LACP support, Loop Guard, WRR queuing, WFQ, DSCP support, RSTP support, MAC address filtering, DHCP snooping, DLF, MIB support, NebulaFLEX support | Flow control, VLAN support, auto-uplink (auto MDI/MDI-X), fanless, CoS, 525KB packet buffer, EEE | — | — | Flow control, VLAN support, IGMP snooping, Syslog support, port mirroring, DiffServ support, MAC address filtering, Broadcast Storm Control, IPv6 support, IP address filtering, Multicast Storm Control, Unicast Storm Control, firmware upgradable, WFQ, ZyXEL iStacking Technology, STP support, RSTP support, MSTP support, DHCP snooping, QoS, RADIUS support, MLD snooping, DHCP relay, Port Security, SNMP trap, DHCP client, MIB, MVR, GVRP, dual firmware images, SPQ, NDP, port isolation, CoS, IGMP proxy, 802.1x authentication, Duplicated Address Detection, cloud managed, DSCP support, 1.5MB packet buffer, ErrDisable Recovery, IGMP filtering, IGMP throttling, Protocol-based VLANs support, CPU protection, IP source guard, ARP inspection, ICMP, VLAN filtering, Loop Guard, Voice VLAN, Private VLAN, Guest VLAN, WRR, MAC based VLAN, VLAN Tagging, port-based VLAN, Unknown Storm Control, MRSTP, MAC freeze |
| Flash Memory | — | — | — | — | 32 MB |
| MAC Address Table Size | — | — | — | — | 16K entries |
| Performance | Switching capacity: 16 Gbps Forwarding performance: 11.9 Mbps Packet buffer size: 525 KB | Switching capacity: 48 Gbps Forwarding performance: 35.7 Mpps | — | — | Switching capacity: 56 Gbps Forwarding rate: 42 Mpps |
| Ports | — | 24 x 10/100/1000 | — | — | 24 x 10/100/1000 (PoE+) + 4 x combo Gigabit SFP + 4 x 10/100/1000 |
| RAM | — | — | — | — | 256 MB |
| Remote Management Protocol | SNMP 1, SNMP 2c, SNMP 3, RMON 1, RMON 2, RMON 3, RMON 9, SSH-2, ICMP, Syslog | — | — | — | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c |
| Routing Protocol | IGMPv2, IGMP, IGMPv3, RSTP, STP | — | — | — | IGMPv2, IGMP, IGMPv3 |
| Subtype | Gigabit Ethernet | Gigabit Ethernet | — | — | Gigabit Ethernet |
| Power | |||||
| AC input frequency | — | 50 - 60 Hz | — | — | 50 - 60 Hz |
| AC input voltage | 200 - 240 V | 100 - 240 V | — | — | 100 - 240 V |
| DC input voltage | — | — | — | 52 - 57 V | — |
| Power consumption (max) | 72 W | 13 W | — | 72 W | 463.5 W |
| Power source | AC | — | — | — | — |
| Power supply included | — | Yes | — | Yes | — |
| Voltage Required | AC 100-240 V (50/60 Hz) | AC 100-240 V (50/60 Hz) | — | — | AC 120/230 V (50/60 Hz) |
| Network | |||||
| 10G support | No | No | — | No | No |
| Auto MDI/MDI-X | Yes | Yes | — | — | — |
| Broadcast storm control | Yes | — | — | Yes | — |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T | — | — | 10BASE-T, 100BASE-TX, 1000BASE-T | 100BASE-TX, 1000BASE-T |
| Flow control support | Yes | — | — | Yes | Yes |
| Full duplex | Yes | — | — | — | — |
| Networking standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x | IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z | — | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Number of VLANs | 8 | — | — | 256 | — |
| Port mirroring | — | — | — | Yes | — |
| Rate limiting | Yes | — | — | Yes | Yes |
| Spanning tree protocol | — | — | — | Yes | Yes |
| Virtual LAN features | — | — | — | MAC address-based VLAN, Port-based VLAN | IP subnet–based VLAN, MAC address-based VLAN, Port-based VLAN, Private VLAN, Protocol-based VLAN, Voice VLAN |
| VLAN support | Yes | — | — | Yes | Yes |
| Management features | |||||
| ARP inspection | — | — | — | — | Yes |
| Configuring Location Settings (CLI) | — | — | — | Yes | — |
| MIB support | RFC 1213 MIB II, RFC 2819, RFC 1215, RFC 1493 | — | — | RFC 1066, RFC 1213, 1157, RFC 1493, RFC 1643, RFC 1757, RFC 2011, 2012, 2013, RFC 2233, RFC 2358, RFC 2674, RFC 2819, 2925, RFC 3621, RFC 4293, RFC 4292, RFC 4022, RFC 4113 | RFC 1066, RFC 1213, RFC 1157, RFC 1493, RFC 1643, RFC 1757, RFC 2011.2012,2013, RFC 2233, RFC 2358, RFC 2674, RFC 2819,2925, RFC 3621, RFC 4022, RFC 4113, RFC 4292, RFC 4293 |
| Quality of Service (QoS) support | Yes | — | — | — | Yes |
| Switch layer | L2 | — | — | L2 | L2/L3/L4 |
| Switch type | Managed | Unmanaged | — | Managed | Managed |
| System event log | Yes | — | — | Yes | Yes |
| Web-based management | Yes | — | — | Yes | — |
| Security | |||||
| Authentication | — | — | — | — | Guest VLAN, Port-based authentication |
| Authentication type | — | — | — | — | IEEE 802.1x, RADIUS |
| DHCP features | — | — | — | DHCP client, DHCP relay, DHCP snooping | DHCP client, DHCP relay, DHCP snooping, DHCPv6 relay |
| IGMP proxy | — | — | — | Yes | — |
| IGMP snooping | Yes | — | — | Yes | Yes |
| IP-MAC-Port binding | — | — | — | — | Yes |
| Loop protection | — | — | — | Yes | — |
| MAC address filtering | Yes | — | — | Yes | — |
| Password protection | — | — | — | — | Yes |
| Queue scheduling algorithms | — | — | — | SPQ, WFQ, Weighted Round Robin (WRR) | SPQ, WFQ, Weighted Round Robin (WRR) |
| Security algorithms | — | — | — | SNMP, SNMPv3, SSH, SSL/TLS | 802.1x RADIUS, SNMP, SNMPv3 |
| SSH/SSL support | Yes | — | — | — | — |
| Ports & interfaces | |||||
| Basic switching RJ-45 Ethernet ports quantity | 8 | 24 | — | 5 | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) | Gigabit Ethernet (10/100/1000) | — | Gigabit Ethernet (10/100/1000) | Gigabit Ethernet (10/100/1000) |
| Combo SFP ports quantity | — | — | — | — | 4 |
| Fiber optic connector | — | — | — | — | SFP |
| Gigabit Ethernet (copper) ports quantity | 8 | — | — | — | — |
| Installed SFP modules quantity | 0 | 0 | — | 0 | — |
| Installed SFP+ modules quantity | 0 | 0 | — | 0 | — |
| Power connector | AC-in jack | — | — | — | — |
| SFP module slots quantity | — | — | — | 1 | — |
| Packaging content | |||||
| Cables included | AC | AC | — | — | AC |
| Manual | Yes | — | — | — | — |
| Quick start guide | Yes | — | — | — | — |
| Rack mount kit | — | Yes | — | — | Yes |
| User guide | Yes | — | — | — | — |
| Certificates | |||||
| Certification | CE, FCC, C-Tick, Class A, Class B, BSMI CNS13438 | LVD, BSMI, EMC Class A, CE, FCC, RCM, ICES-003, BSMI, RoHS, REACH | — | LVD EN62368-1, BSMI CNS14336-1, RoHS | RoHS |
| Weight & dimensions | |||||
| Depth | 104 mm | 162 mm | — | 84 mm | 270 mm |
| Height | 27 mm | 42 mm | — | 26 mm | 44 mm |
| Weight | 620 g | 1.5 kg | — | 410 g | 3.8 kg |
| Width | 250 mm | 267 mm | — | 193 mm | 441 mm |
| Design | |||||
| Electromagnetic compatibility | LVD EN60950-1, BSMI CNS14336-1 | — | — | CE, FCC, C-Tick, A; BSMI CNS13438 | FCC 15 A, CE A, BSMI EMC |
| LED indicators | Yes | Yes | — | Yes | Yes |
| Product colour | Black | Black | — | Grey | Black |
| Rack mounting | — | Yes | — | No | Yes |
| Wall mountable | — | Yes | — | Yes | — |
| Performance | |||||
| Fanless | — | Yes | — | — | — |
| Firmware upgradeable | — | — | — | Yes | — |
| Flash memory | — | — | — | — | 32 MB |
| Internal memory | — | — | — | — | 256 MB |
| Mean time between failures (MTBF) | 1641000 h | 366919 h | — | 2021885.87 h | 638691 h |
| Noise level | — | — | — | 0 dB | 27.2 dB |
| Optical fiber | |||||
| Fiber ethernet cabling technology | — | — | — | 1000BASE-X | — |
| Data transmission | |||||
| Forwarding rate | 11.9 Mpps | 35.7 Mpps | — | 8.9 Mpps | 42 Mpps |
| Jumbo frames | 9000 | 10000 | — | — | — |
| Jumbo frames support | Yes | — | — | — | — |
| MAC address table | 8000 entries | 8000 entries | — | 8000 entries | 16000 entries |
| Packet buffer memory | 0.525 MB | 0.525 MB | — | 0.525 MB | 1.5 MB |
| Switching capacity | 16 Gbit/s | 48 Gbit/s | — | 12 Gbit/s | 56 Gbit/s |
| Logistics data | |||||
| Harmonized System (HS) code | 85176990 | 85176990 | — | 85176990 | 85176990 |
| Operational conditions | |||||
| Heat dissipation | 245.52 BTU/h | 43.53 BTU/h | — | 245.52 BTU/h | 1580.54 BTU/h |
| Operating relative humidity (H-H) | 10 - 95% | — | — | 5 - 95% | 10 - 95% |
| Operating temperature (T-T) | 0 - 40 °C | 0 - 40 °C | — | -20 - 50 °C | 0 - 50 °C |
| Storage relative humidity (H-H) | 10 - 95% | — | — | 5 - 95% | 10 - 95% |
| Storage temperature (T-T) | -40 - 70 °C | — | — | -40 - 70 °C | -40 - 70 °C |
| Protocols | |||||
| Management protocols | SNMP v1,v2,v3, RMON (1,2,3,9) | — | — | — | — |
| Multicast features | |||||
| Multicast support | Yes | — | — | Yes | Yes |
| Packaging data | |||||
| Package depth | 227 mm | — | — | 255 mm | 355 mm |
| Package height | 64 mm | — | — | 65 mm | 107 mm |
| Package type | — | — | — | — | Box |
| Package weight | 1.4 kg | — | — | 1.08 kg | 4.97 kg |
| Package width | 302 mm | — | — | 242 mm | 616 mm |
| Power over Ethernet (PoE) | |||||
| Power over Ethernet (PoE) | Yes | No | — | Yes | Yes |
| Power over Ethernet (PoE) ports quantity | 8 | — | — | 5 | 24 |
| Total Power over Ethernet (PoE) budget | 60 W | — | — | 60 W | 375 W |
