Allied Telesis CentreCOM AT-GS910/8 - Switch - unmanaged - 8 x 10/100/1000 - desktop

Manuf P/N: AT-GS910/8-30

APAXON#: 8986812

EAN: 767035207414

Unmanaged Web-based management
Basic switching RJ-45 Ethernet ports quantity: 8 Console port: RJ-45
10BASE-T, 100BASE-T, 1000BASE-T
MAC address table: 4000 entries Switching capacity: 16 Gbit/s
1U Rack mounting

Stock0

Price £64.61

Quantity

Notify me when available.

Product Summary

Allied Telesis AT-GS910/8-30 network switch Unmanaged Gigabit Ethernet (10/100/1000) 1U Grey

Extended Specification

Group 1143

Storage temperature (T-T)

-25 - 70 °C

Operating relative humidity (H-H)

5 - 90%

Storage relative humidity (H-H)

5 - 95%

Operating temperature (T-T)

0 - 50 °C

Group 1144

Width

210 mm

Depth

121 mm

Height

38 mm

Weight

780 g

Group 2483

Included power plug types

Group 41469

Certification

EAC certification, EN55024, ICES Class A, VCCI Class A, FCC Class A, RCM, CE, EN55022, CISPR 55022

Group 2944

Switch type

Unmanaged

Web-based management

Yes

Group 763

Basic switching RJ-45 Ethernet ports quantity

Basic switching RJ-45 Ethernet ports type

Gigabit Ethernet (10/100/1000)

Installed SFP modules quantity

Installed SFP+ modules quantity

Gigabit Ethernet (copper) ports quantity

Console port

RJ-45

Group 1141

Networking standards

IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x

10G support

Copper ethernet cabling technology

10BASE-T, 100BASE-T, 1000BASE-T

Full duplex

Yes

Flow control support

Yes

Broadcast storm control

Yes

Auto-negotiation

Yes

Group 2484

MAC address table

4000 entries

Switching capacity

16 Gbit/s

Throughput

11.9 Mpps

Jumbo frames support

Yes

Jumbo frames

9216

Packet forwarding rate (1 Gbps)

1488000 pps

Packet forwarding rate (100 Mbps)

148800 pps

Packet forwarding rate (10 Mbps)

14880 pps

Group 2482

Loop protection

Yes

BPDU filtering/protection

Yes

Group 10881

Rack mounting

Yes

Form factor

Product colour

Grey

Housing material

Metal

LED indicators

Yes

Wall mountable

Yes

Safety

UL60950-1, 2nd Edition, CSA C22.2 No.60950-1-07, 2nd Edition, IEC60950-1(UL-EU, UL-CB)

Group 10882

Buffer size

128 KB

Group 1142

AC input voltage

100 - 240 V

AC input frequency

50 - 60 Hz

Input current

0.2 A

Power consumption (max)

4.5 W

Group 9999

Power over Ethernet (PoE)

Allied Telesis CentreCOM AT-GS910/8 - Switch - unmanaged - 8 x 10/100/1000 - desktop
