APC Smart-UPS 1500VA LCD RM
APC Smart-UPS 1500VA LCD RM
UPS (rack-mountable)
AC 220/230/240 V
1000 Watt
1500 VA
RS-232, USB
output connectors: 4
2U
black
with APC SmartConnect
for P/N: AR106V, AR106VI, AR112SH6, AR3006, AR3006SP, AR3103, AR3103SP, AR3106, AR3106SP
Weight: 34.40 KG
UPS (rack-mountable)
AC 220/230/240 V
1000 Watt
1500 VA
RS-232, USB
output connectors: 4
2U
black
with APC SmartConnect
for P/N: AR106V, AR106VI, AR112SH6, AR3006, AR3006SP, AR3103, AR3103SP, AR3106, AR3106SP
Weight: 34.40 KG
- Intuitive LCD interface
- Predictive replace battery date
- Energy meter
- Pure sine wave output on battery
- Single switched outlet group
- High online efficiency
- SmartSlot
- Cold-start capable
- Temperature-compensated battery charging
Similar Products
Overview
Intuitive LCD interface provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys. Predictive replace battery date dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning.
Specifications
Features
- Auto-restart
- Yes
- Output power capacity
- 1.5 kVA kVA
- Output power
- 1000 W W
- Input operation voltage (min)
- 151 V V
- Input operation voltage (max)
- 302 V V
- Input frequency
- 50/60 Hz Hz
- Output operation voltage (min)
- 220 V V
- Output operation voltage (max)
- 240 V V
- Output frequency
- 50/60 Hz Hz
- Surge energy rating
- 459 J J
- Response time
- 10 ms ms
- Noise level
- 46 dB dB
- UPS topology
- Line-Interactive
- Output power capacity
- 1.5 kVA
- Output power
- 1000 W
- Waveform
- Sine
- Input operation voltage (min)
- 151 V
- Input operation voltage (max)
- 302 V
- Input frequency
- 50/60 Hz
- Output operation voltage (min)
- 220 V
- Output operation voltage (max)
- 240 V
- Output frequency
- 50/60 Hz
- Surge energy rating
- 459 J
- Response time
- 10 ms
- Noise level
- 46 dB
- Audible alarm(s)
- Yes
- Audible alarm modes
- Alarm when on battery, Low battery alarm
Ports & interfaces
- AC outlet types
- C13 coupler, IEC Jumpers
- Power plug
- C14 coupler
- AC outlets quantity
- 4 AC outlet(s)
- USB port
- Yes
- Serial interface
- Yes
- Serial interface type
- RJ-45
- SmartSlot
- Yes
- AC outlets quantity
- 4 AC outlet(s) AC outlet(s)
Battery
- Battery technology
- Sealed Lead Acid (VRLA)
- Number of batteries supported
- 1
- Battery life (max)
- 6 year(s)
- Battery recharge time
- 3 h
- Hot-swap battery
- Yes
- Automatic battery test
- Yes
- Cold start
- Yes
- Battery life (max)
- 6 year(s) year(s)
- Battery recharge time
- 3 h h
Design
- Form factor
- Rackmount
- Product colour
- Black
- Rack capacity
- 2U
- Display type
- LCD
- LED indicators
- Yes
Operational conditions
- Operating temperature (T-T)
- 0 - 40 °C
- Storage temperature (T-T)
- -15 - 45 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Storage relative humidity (H-H)
- 0 - 95%
- Operating altitude
- 0 - 3000 m
- Non-operating altitude
- 0 - 15000 m
- Operating temperature (T-T)
- 0 - 40 °C °C
- Storage temperature (T-T)
- -15 - 45 °C °C
- Operating relative humidity (H-H)
- 0 - 95% %
- Storage relative humidity (H-H)
- 0 - 95% %
- Operating altitude
- 0 - 3000 m m
- Non-operating altitude
- 0 - 15000 m m
Certificates
- Certification
- CE, EAC, EN / IEC 62040-1, EN / IEC 62040-2, Energy Star 1.0 (EU), RCM, TÜV, VDE
Packaging content
- Rack mount kit
- Yes
- Cables included
- RS-232, USB cable
- Manual
- Yes
Sustainability
- Sustainability certificates
- ENERGY STAR, Green Premium
Weight & dimensions
- Width
- 432 mm
- Depth
- 477 mm
- Height
- 86 mm
- Weight
- 26.1 kg
- Width
- 432 mm mm
- Depth
- 477 mm mm
- Height
- 86 mm mm
- Weight
- 26.1 kg kg
Packaging data
- Resource CD
- Yes
- Package width
- 594 mm
- Package depth
- 603 mm
- Package height
- 251 mm
- Package weight
- 31.9 kg
- Package width
- 594 mm mm
- Package depth
- 603 mm mm
- Package height
- 251 mm mm
- Package weight
- 31.9 kg kg
Logistics data
- Products per pallet
- 8 pc(s)
- Harmonized System (HS) code
- 85078000
- Total carbon footprint (kg of CO2e)
- 1416.6
- Products per pallet
- 8 pc(s) pc(s)
Other features
- Output voltage
- 230 V
- Output voltage
- 230 V V
General
- Device Type
- UPS - rack-mountable
Power Device
- Input Voltage
- AC 220/230/240 V
- Power Capacity
- 1000 Watt / 1500 VA
- Input Voltage Range
- AC 160 - 286 V
Miscellaneous
- Designed For
- P/N: ACCS1000, ACCS1001, ACCS1002, ACCS1003, ACCS1004, ACCS1005, ACCS1006, ACCS1007, ACDC1015, ACDC1016, ACDC1017, ACDC1019, ACDC1020, ACDC1021, ACDC2513, ACF001, ACF002, ACF003, ACF101BLK, ACF102BLK, ACF201BLK, ACF400, ACF600, AP5017, AP5602, AP5606, AP5607, AP5616, AP92200, AP9290, AR100, AR100HD, AR106V, AR106VI, AR112SH6, AR202, AR203A, AR204A, AR2101, AR2102BLK, AR2144BLK, AR2145BLK, AR2200, AR2280, AR2400, AR2400FP1, AR2401, AR2407, AR2480, AR2487, AR2487G, AR2500, AR2507, AR2580, AR2587, AR2900, AR2901, AR3000, AR3003SP, AR3006, AR3006SP, AR3100, AR3100G, AR3100SP, AR3100SP1, AR3100SP2, AR3100TAA, AR3100W, AR3100X609, AR3100X610, AR3100X617, AR3101, AR3103, AR3103SP, AR3104, AR3104SP1, AR3105, AR3105SP, AR3105W, AR3106, AR3106SP, AR3107, AR3107G, AR3107SP, AR3107X609, AR3107X610, AR3107X617, AR3130, AR3140, AR3140G, AR3140W, AR3150, AR3150SP, AR3150SP1, AR3150SP2, AR3150W, AR3150X609, AR3150X610, AR3150X617, AR3155, AR3155SP, AR3155W, AR3157, AR3157SP, AR3157X609, AR3157X610, AR3157X617, AR3200, AR3300, AR3300G, AR3300SP, AR3300W, AR3300X609, AR3300X610, AR3300X617, AR3305, AR3305SP, AR3305W, AR3307, AR3307SP, AR3307W, AR3307X609, AR3307X610, AR3307X617, AR3340, AR3340G, AR3340W, AR3347, AR3350, AR3350SP, AR3350W, AR3350X609, AR3350X610, AR3350X617, AR3355, AR3355SP, AR3355W, AR3357, AR3357SP, AR3357X609, AR3357X610, AR3357X617, AR3357X674, AR4018, AR4018A, AR4018I, AR4018IA, AR4018IX429, AR4018IX431, AR4018IX432, AR4018SP, AR4018SPX429, AR4018SPX431, AR4018SPX432, AR4018X429, AR4018X431, AR4018X432, AR4024, AR4024A, AR4024I, AR4024IA, AR4024IX429, AR4024IX431, AR4024IX432, AR4024SP, AR4024SPX429, AR4024SPX431, AR4024SPX432, AR4024X429, AR4024X431, AR4024X432, AR4038, AR4038A, AR4038I, AR4038IA, AR4038IX429, AR4038IX431, AR4038IX432, AR4038X429, AR4038X432, AR7007, AR7050, AR7057, NBWL0356
