ASUS ExpertBook B5 B5604CMA-QVU715X - 180-degree hinge design - Intel Core Ultra 7 - 155U / up to 4.8 GHz - Win 11 Pro - Intel Graphics - 16 GB RAM - 512 GB SSD NVMe - 16" 1920 x 1200 - Gigabit Ethernet - Wi-Fi 6E, Bluetooth - star black
Manuf P/N: B5604CMA-QVU715X
APAXON#: 10308135
EAN: 4711387559833
ASUS ExpertBook B5 B5604CMA-QVU715X - 180-degree hinge design - Intel Core Ultra 7 - 155U / up to 4.8 GHz - Win 11 Pro - Intel Graphics - 16 GB RAM - 512 GB SSD NVMe - 16" 1920 x 1200 - Gigabit Ethernet - Wi-Fi 6E, Bluetooth - star black
- Work Laptop Clamshell Black
- Intel Core Ultra 7 155U Processor cores: 12
- Touchscreen 40.6 cm (16") WUXGA 1920 x 1200 pixels LED backlight 16:10
- 16 GB DDR5-SDRAM 1 x 16 GB
- 512 GB SSD
- Intel Graphics
- Wi-Fi 6E (802.11ax) Ethernet LAN 10,100,1000 Mbit/s Bluetooth 5.3
- Lithium-Ion (Li-Ion) 63 Wh 65 W
- Windows 11 Pro 64-bit
Stock0
Price £0.00
Quantity
|
Similar Products
Product Summary
ASUS ExpertBook B5 B5604CMA-QVU715X Intel Core Ultra 7 155U Laptop 40.6 cm (16") Touchscreen WUXGA 16 GB DDR5-SDRAM 512 GB SSD Wi-Fi 6E (802.11ax) Windows 11 Pro Black
Extended Specification
Design
Product type
Laptop
Product colour
Black
Form factor
Clamshell
Colour name
Star Black
Housing material
Aluminium, Magnesium
Market positioning
Work
Introduction year
2024
Display
Display diagonal
40.6 cm (16")
Display resolution
1920 x 1200 pixels
Touchscreen
Yes
HD type
WUXGA
LED backlight
Yes
Native aspect ratio
16:10
Anti-glare screen
Yes
Display brightness
300 cd/m²
RGB colour space
NTSC
Colour gamut
45%
Maximum refresh rate
60 Hz
Contrast ratio (typical)
1000:1
Processor
Processor family
Intel Core Ultra 7
Processor manufacturer
Intel
Processor model
155U
Processor generation
Intel® Core™ Ultra (Series 1)
Processor cores
12
Processor threads
14
Processor boost frequency
4.8 GHz
Performance cores
2
Efficient cores
8
Low Power Efficient-cores
2
Performance-core Max Turbo Frequency
4.8 GHz
Efficient-core Max Turbo Frequency
3.8 GHz
Low Power Efficient-core Max Turbo Frequency
2.1 GHz
Performance-core base frequency
1.7 GHz
Efficient-core base frequency
1.2 GHz
Low Power Efficient-core Base Frequency
700 MHz
Processor cache
12 MB
Processor cache type
Smart Cache
Processor base power
15 W
Maximum turbo power
57 W
Neural processor unit (NPU)
Neural processor unit (NPU)
Intel AI Boost
Maximum frequency NPU
1.4 GHz
Sparsity support
Yes
Windows Studio effects support
Yes
AI software frameworks supported by NPU
DirectML, ONNX RT, OpenVINO, Windows ML
Memory
Internal memory
16 GB
Maximum internal memory
64 GB
Internal memory type
DDR5-SDRAM
Memory form factor
SO-DIMM
Memory layout (slots x size)
1 x 16 GB
Memory slots
2x SO-DIMM
Storage
Total storage capacity
512 GB
Storage media
SSD
Optical drive type
No
Total SSDs capacity
512 GB
Number of SSDs installed
1
SSD capacity
512 GB
SSD interface
PCI Express 4.0
NVMe
Yes
SSD form factor
M.2
Graphics
On-board graphics card
Yes
Discrete graphics card
No
Discrete graphics card model
Not available
On-board graphics card model
Intel Graphics
On-board GPU manufacturer
Intel
On-board graphics card family
Intel Graphics
Audio
Audio system
Dolby Atmos
Built-in microphone
Yes
Camera
Front camera
Yes
Front camera resolution
1920 x 1080 pixels
Front camera HD type
Full HD
Privacy camera
Yes
Privacy type
Privacy shutter
Network
Top Wi-Fi standard
Wi-Fi 6E (802.11ax)
Wi-Fi standards
Wi-Fi 6E (802.11ax)
Antenna type
2x2
Ethernet LAN
Yes
Ethernet LAN data rates
10,100,1000 Mbit/s
Bluetooth
Yes
Bluetooth version
5.3
Ports & interfaces
USB 2.0 ports quantity
0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
HDMI ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
Ethernet LAN (RJ-45) ports
1
HDMI version
2.1
Thunderbolt 4 ports quantity
2
Intel® Thunderbolt 4
Yes
Combo headphone/mic port
Yes
USB Type-C DisplayPort Alternate Mode
Yes
Keyboard
Numeric keypad
Yes
Pointing device
Touchpad
Software
Operating system installed
Windows 11 Pro
Operating system architecture
64-bit
Trial software
1-month trial for new Microsoft 365 customers.
Battery
Battery capacity
63 Wh
Battery technology
Lithium-Ion (Li-Ion)
Number of battery cells
3
Power
USB Type-C charging port
Yes
AC adapter power
65 W
AC adapter frequency
50 - 60 Hz
AC adapter input voltage
100 - 240 V
AC adapter output current
3.25 A
AC adapter output voltage
20 V
USB Power Delivery (USB PD)
Yes
Security
Cable lock slot
Yes
Cable lock slot type
Kensington
Fingerprint reader
Yes
Smart card reader
Yes
Trusted Platform Module (TPM)
Yes
Trusted Platform Module (TPM) version
2.0
Password protection
Yes
Password protection type
BIOS, HDD, User
Certificates
Compliance certificates
REACH
Sustainability
Sustainability certificates
ENERGY STAR, EPEAT Gold, Forest Stewardship Council (FSC) Recycled
Weight & dimensions
Weight
1.95 kg
Width
358 mm
Depth
254.3 mm
Height (front)
1.89 cm
Height (rear)
2.29 cm
