ATEN VS0801H - Video/audio switch - 8 x HDMI - desktop
Manuf P/N: VS0801H
APAXON#: 11494294
EAN: 4710423776326
ATEN VS0801H - Video/audio switch - 8 x HDMI - desktop
- Video port type: HDMI
- 1920 x 1080 pixels
- Black, Silver
Stock0
Price £0.00
Quantity
|
Similar Products
Product Summary
ATEN VS0801H video switch HDMI
Extended Specification
Group 5415
Video port type
HDMI
HDMI ports quantity
9
HDMI version
1.4
HDMI in
8
Number of HDMI outputs
1
RS-232 ports
1
Video in
8 x HDMI Type A Female (Black)
Video out
1 x HDMI Type A Female (Black)
DC-in jack
Yes
Group 28464
Material
Metal
Product colour
Black, Silver
Plug and Play
Yes
HDCP
Yes
Maximum refresh rate
60 Hz
Maximum operating distance
15 m
Rack mounting
Yes
Supported graphics resolutions
640 x 480 (VGA), 800 x 480 (WVGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Supported video modes
480p, 720p, 1080i, 1080p
Bandwidth
6.75 Gbit/s
Bandwidth
225 MHz
Maximum resolution
1920 x 1080 pixels
3D
Yes
HD type
Full HD
Dolby technologies
DTS-HD Master Audio, Dolby TrueHD
Input impedance
100 Ω
Output impedance
100 Ω
Group 6565
Power consumption (typical)
3.71 W
Group 5416
Width
437 mm
Depth
159.8 mm
Height
44 mm
Weight
1.75 kg
Depth (imperial)
16 cm (6.29")
Height (imperial)
4.39 cm (1.73")
Width (imperial)
43.7 cm (17.2")
Group 5413
Remote control included
Yes
User guide
Yes
AC adapter included
Yes
Group 22057
Operating temperature (T-T)
0 - 50 °C
Storage temperature (T-T)
-20 - 60 °C
Operating relative humidity (H-H)
0 - 80%
Group 5414
Compliance certificates
RoHS
Group 17513
Harmonized System (HS) code
85176990
