Compare APC UPS
Comparing 5 products side-by-side — specifications, pricing and stock. Showing APC products in the UPS category.
| Specification | APC Freight charge of 1% to be added for APC kit, Please add SKU 2550388 at 1% of total order value to your PO when placing orderSRT6KRMXLI-6W £5203.30 £6243.96 inc VAT | ||||
|---|---|---|---|---|---|
| General | |||||
| Device Type | UPS - rack-mountable | — | — | — | — |
| Battery | |||||
| Automatic battery test | Yes | — | — | Yes | — |
| Battery capacity | 108 VAh | — | — | 902 VAh | — |
| Battery life (max) | 5 year(s) | — | — | 5 year(s) | — |
| Battery recharge time | 5 h | — | 4 h | 1.5 h | — |
| Battery technology | Sealed Lead Acid (VRLA) | — | Sealed Lead Acid (VRLA) | Sealed Lead Acid (VRLA) | — |
| Battery voltage | — | — | 48 V | — | — |
| Cold start | — | — | — | Yes | — |
| Hot-swap battery | Yes | — | — | Yes | — |
| Typical backup time at full load | 5.9 min | — | — | 2.5 min | — |
| Typical backup time at half load | 19.4 min | — | — | 8.7 min | — |
| Ports & interfaces | |||||
| AC outlet types | C13 coupler | IEC 60320 | C13 coupler | C13 coupler, C19 coupler | — |
| AC outlets quantity | 4 AC outlet(s) | — | — | 10 AC outlet(s) | 8 AC outlet(s) |
| Emergency Power Off (EPO) connector | — | — | — | — | Yes |
| Ethernet LAN (RJ-45) ports | 0 | — | — | — | — |
| Number of output IEC jumpers | 2 | — | — | 2 | — |
| Power plug | C14 coupler | — | C19 coupler | Hardwire | — |
| RS-232 ports | — | — | 1 | — | — |
| Serial interface | Yes | — | — | Yes | Yes |
| Serial interface type | RS-232 | — | — | — | RJ-45 |
| Serial ports quantity | 1 | — | — | — | — |
| SmartConnect port | — | No | — | No | — |
| SmartSlot | — | Yes | — | Yes | Yes |
| USB 2.0 ports quantity | — | — | — | — | 1 |
| USB port | — | — | Yes | Yes | Yes |
| Features | |||||
| Audible alarm modes | Low battery alarm, Overload alarm | — | Alarm when on battery, Low battery alarm, Overload alarm | — | — |
| Audible alarm(s) | Yes | — | — | Yes | — |
| Auto-restart | Yes | — | — | Yes | — |
| Automatic Voltage Regulation (AVR) | Yes | — | — | — | — |
| Crest factor | — | — | 3:1 | 3:1 | — |
| Efficiency | — | — | 88% | 94.4% | — |
| Emergency Power Off (EPO) | — | — | — | Yes | — |
| Heat dissipation | — | — | — | — | 317 BTU/h |
| Hold time (max) | 8 ms | — | — | — | — |
| Hold time (min) | 4 ms | — | — | — | — |
| Input frequency | 50/60 Hz | — | 50/60 Hz | 40 - 70 Hz | 40/70 Hz |
| Input operation voltage (max) | 302 V | — | 285 V | 275 V | 230 V |
| Input operation voltage (min) | 151 V | — | 110 V | 100 V | 50 V |
| Noise level | 38 dB | — | 50 dB | 55 dB | 50 dB |
| Number of output phases | — | — | — | 1 | — |
| Output frequency | — | — | 50/60 Hz | — | 50/60 Hz |
| Output frequency regulation | — | — | — | 50/60 Hz | — |
| Output operation voltage (max) | — | — | 240 V | 240 V | 230 V |
| Output operation voltage (min) | — | — | 220 V | 220 V | — |
| Output power | 280 W | — | 1800 W | 6000 W | 1980 W |
| Output power capacity | 0.45 kVA | — | 2 kVA | 6 kVA | 2.2 kVA |
| Power source type | — | — | AC | — | — |
| Surge energy rating | 320 J | — | — | 480 J | 432 J |
| Surge protection | Yes | — | Yes | Yes | — |
| Surge protection features | Digital Subscriber Line (DSL), Fax, Modem, Network | — | — | — | — |
| UPS topology | Line-Interactive | — | Double-conversion (Online) | Double-conversion (Online) | Line-Interactive |
| Waveform | Sine | — | Sine | Sine | Sine |
| Packaging data | |||||
| Bracket | — | — | — | Yes | — |
| Package depth | 589 mm | — | 235 mm | 960 mm | 594 mm |
| Package height | 164 mm | — | 355 mm | 370 mm | 246 mm |
| Package type | — | — | — | — | Box |
| Package weight | 11.7 kg | — | 18.9 kg | 67 kg | 29.6 kg |
| Package width | 476 mm | — | 525 mm | 610 mm | 749 mm |
| Software CD | Yes | — | — | Yes | — |
| Temperature sensor | — | — | — | Yes | — |
| Warranty card | — | — | — | Yes | — |
| Design | |||||
| Cable length | — | — | 1.5 m | — | 1.8 m |
| Display type | — | — | LCD | LCD | — |
| Form factor | Rackmount/Tower | — | — | Rackmount | Rackmount |
| International Protection (IP) code | — | — | IP20 | IP20 | IP20 |
| LED indicators | Battery replacement | — | — | Status | — |
| Product colour | Grey | — | Black | Black | Black |
| Rack capacity | 1U | — | — | 4U | 2U |
| Packaging content | |||||
| Cables included | RS-232 | — | — | USB cable | — |
| Management card included | — | No | — | Yes | — |
| Manual | Yes | — | — | — | — |
| Quick installation guide | — | — | — | Yes | — |
| Rack mount kit | Yes | — | — | Yes | — |
| Certificates | |||||
| Certification | C-tick, CE, GOST, VDE, PEP, EOLI | — | — | REACH, CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, IRAM, RCM, VDE | CE, EAC |
| Compliance certificates | RoHS | — | — | RoHS | — |
| Weight & dimensions | |||||
| Depth | 383 mm | — | 400 mm | 719 mm | 508 mm |
| Height | 44 mm | — | 238 mm | 174 mm | 432 mm |
| Weight | 10.2 kg | — | 17 kg | 60 kg | 22 kg |
| Width | 432 mm | — | 145 mm | 432 mm | 85 mm |
| Compatibility Information | |||||
| Designed For | P/N: ACCS1000, ACCS1001, ACCS1002, ACCS1003, ACCS1004, ACCS1005, ACCS1006, ACCS1007, ACDC1015, ACDC1016, ACDC1017, ACDC1019, ACDC1020, ACDC1021, ACDC2513, ACF001, ACF002, ACF003, ACF101BLK, ACF102BLK, ACF201BLK, ACF400, ACF600, AP5017, AP5602, AP5606, AP5607, AP5616, AP92200, AP9290, AR100, AR100HD, AR106SH6, AR109SH6, AR112SH6, AR202, AR203A, AR204A, AR2101, AR2102BLK, AR2144BLK, AR2145BLK, AR2200, AR2280, AR2400, AR2400FP1, AR2401, AR2407, AR2480, AR2487, AR2487G, AR2500, AR2507, AR2580, AR2587, AR2900, AR2901, AR3000, AR3003, AR3003SP, AR3006, AR3006SP, AR3100, AR3100G, AR3100SP, AR3100SP1, AR3100SP2, AR3100TAA, AR3100W, AR3100X609, AR3100X610, AR3100X617, AR3101, AR3103, AR3103SP, AR3104SP1, AR3105, AR3105SP, AR3105W, AR3106, AR3106SP, AR3107, AR3107G, AR3107SP, AR3107X609, AR3107X610, AR3107X617, AR3130, AR3140, AR3140G, AR3140W, AR3150, AR3150SP, AR3150SP1, AR3150SP2, AR3150W, AR3150X609, AR3150X610, AR3150X617, AR3155, AR3155SP, AR3155W, AR3157, AR3157SP, AR3157X609, AR3157X610, AR3157X617, AR3200, AR3300, AR3300G, AR3300SP, AR3300W, AR3300X609, AR3300X610, AR3300X617, AR3305, AR3305SP, AR3305W, AR3307, AR3307SP, AR3307W, AR3307X609, AR3307X610, AR3307X617, AR3340, AR3340G, AR3340W, AR3347, AR3350, AR3350SP, AR3350W, AR3350X609, AR3350X610, AR3350X617, AR3355, AR3355SP, AR3355W, AR3357, AR3357SP, AR3357X609, AR3357X610, AR3357X617, AR3357X674, AR3810, AR3812, AR3814, AR4018, AR4018A, AR4018I, AR4018IA, AR4018IX429, AR4018IX431, AR4018IX432, AR4018SP, AR4018SPX429, AR4018SPX431, AR4018SPX432, AR4018X429, AR4018X431, AR4018X432, AR4024, AR4024A, AR4024I, AR4024IA, AR4024IX429, AR4024IX431, AR4024IX432, AR4024SP, AR4024SPX429, AR4024SPX431, AR4024SPX432, AR4024X429, AR4024X431, AR4024X432, AR4038, AR4038A, AR4038I, AR4038IA, AR4038IX429, AR4038IX431, AR4038IX432, AR4038X429, AR4038X431, AR4038X432, AR7007, AR7050, AR7057, AR8135BLK, NBWL0356A | — | — | — | — |
| Logistics data | |||||
| Harmonized System (HS) code | 85078000 | — | — | 85078000 | — |
| Products per pallet | 24 pc(s) | — | — | 6 pc(s) | — |
| Total carbon footprint (kg of CO2e) | 484.92 | 1030.49 | — | 13539.46 | 3558.01 |
| Warranty period | — | — | — | — | 5 year(s) |
| Power Device | |||||
| Input Voltage | AC 230 V | — | — | — | — |
| Input Voltage Range | AC 160 - 286 V | — | — | — | — |
| Power Capacity | 280 Watt / 450 VA | — | — | — | — |
| Other features | |||||
| Nominal output voltage | 230 V | — | — | — | — |
| Packaging content | — | — | — | Web/SNMP Management Card | — |
| Operational conditions | |||||
| Non-operating altitude | 0 - 15000 m | — | — | 0 - 15000 m | 0 - 15240 m |
| Operating altitude | 0 - 3000 m | — | — | 0 - 3000 m | 0 - 3048 m |
| Operating relative humidity (H-H) | 0 - 95% | — | — | 0 - 95% | 0 - 95% |
| Operating temperature (T-T) | 0 - 40 °C | — | — | 0 - 40 °C | 0 - 40 °C |
| Storage relative humidity (H-H) | 0 - 95% | — | — | 0 - 95% | 0 - 95% |
| Storage temperature (T-T) | -15 - 45 °C | — | — | -15 - 45 °C | -20 - 50 °C |
| Sustainability | |||||
| Sustainability certificates | — | Green Premium | — | ENERGY STAR | — |
