Compare Asus Motherboards
Comparing 5 products side-by-side — specifications, pricing and stock. Showing Asus products in the Motherboards category.
| Specification | Asus ASUS HYPER M.2 X16 CARD V2 - Interface adapter - M.2 - Expansion Slot to M.2 - M.2 Card - PCIe 3.0 x1690MC06P0-M0EAY0 £29.73 £35.68 inc VAT | ||||
|---|---|---|---|---|---|
| Processor | |||||
| Compatible processor series | AMD Ryzen 3000 Series | Intel Core Ultra (Series 2) | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold | Intel Core Ultra (Series 2) | — |
| Maximum number of SMP processors | 1 | — | — | — | — |
| Processor manufacturer | AMD | Intel | Intel | Intel | — |
| Processor socket | Socket AM4 | LGA 1851 (Socket V1) | LGA 1700 | LGA 1851 (Socket V1) | — |
| Supported processor sockets | Socket AM4 | — | LGA 1700 | — | — |
| Memory | |||||
| ECC сompatibility | — | Non-ECC | Non-ECC | Non-ECC | — |
| Maximum internal memory | 128 GB | 256 GB | 128 GB | 192 GB | — |
| Memory channels | — | — | Dual-channel | Dual-channel | — |
| Memory slots type | DIMM | DIMM | DIMM | DIMM | — |
| Number of memory slots | 4 | 4 | 4 | 4 | — |
| Supported memory clock speed (max) | — | 8600 MHz | 5333 MHz | 8600 MHz | — |
| Supported memory clock speeds | 2133,2400,2666,2800,3000,3200,3466,3600,3866,4000,4133,4400,4600 MHz | — | 2133,2400,2666,2800,2933,3000,3200,3333,3400,3466,3600,3733,4000,4266,4400,4600,4800,5000,5066,5333 MHz | — | — |
| Supported memory types | DDR4-SDRAM | DDR5-SDRAM | DDR4-SDRAM | DDR5-SDRAM | — |
| Unbuffered memory | — | Yes | Yes | Yes | — |
| Graphics | |||||
| Maximum resolution | — | — | 3840 x 2160 pixels | — | — |
| On-board graphics card | No | — | — | No | — |
| Parallel processing technology support | 2-Way CrossFireX | Not supported | Not supported | Not supported | — |
| Network | |||||
| Bluetooth | Yes | Yes | Yes | Yes | — |
| Bluetooth version | 5.0 | 5.4 | 5.2 | 5.4 | — |
| Ethernet interface type | 2.5 Gigabit Ethernet | 2.5 Gigabit Ethernet | 2.5 Gigabit Ethernet | 2.5 Gigabit Ethernet | — |
| Ethernet LAN | Yes | Yes | Yes | Yes | — |
| LAN controller | Intel I225-V | — | — | — | — |
| Top Wi-Fi standard | — | Wi-Fi 7 (802.11be) | Wi-Fi 6 (802.11ax) | Wi-Fi 7 (802.11be) | — |
| Wake-on-LAN ready | Yes | — | Yes | — | — |
| Wi-Fi | No | Yes | Yes | Yes | — |
| Wi-Fi standards | — | — | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be) | — |
| Internal I/O | |||||
| 12V power connector | Yes | Yes | Yes | Yes | — |
| ATX Power connector (24-pin) | — | Yes | Yes | Yes | — |
| Chassis intrusion connector | — | — | — | Yes | — |
| CPU fan connector | Yes | Yes | Yes | Yes | — |
| EPS power connector (8-pin) | Yes | Yes | Yes | Yes | — |
| Front panel audio connector | — | Yes | Yes | Yes | — |
| Number of chassis fan connectors | 3 | 4 | 2 | 4 | — |
| Number of COM connectors | — | — | — | 1 | — |
| Number of CPU fan connectors | — | 1 | — | — | — |
| Number of EATX power connectors | 1 | — | — | — | — |
| Number of Parallel ATA connectors | 0 | — | — | — | — |
| Number of SATA connectors | 0 | — | — | 0 | — |
| Number of SATA II connectors | 0 | — | — | 0 | — |
| Number of SATA III connectors | 6 | 4 | 4 | 4 | — |
| RGB LED pin header | — | — | Yes | Yes | — |
| S/PDIF out connector | — | — | Yes | — | — |
| Thunderbolt headers | 1 | 1 | — | 1 | — |
| TPM connector | — | — | Yes | — | — |
| USB 2.0 connectors | 2 | 1 | 3 | 2 | — |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 | 1 | 3 | 2 | — |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 | 1 | 0 | 1 | — |
| Packaging content | |||||
| Antenna included | — | — | Yes | — | — |
| Cables included | SATA | — | SATA | SATA | — |
| Drivers included | Yes | — | — | — | — |
| Manual | Yes | — | — | — | — |
| Screws included | — | — | Yes | — | — |
| Features | |||||
| Audio chip | — | Realtek ALC1220P | — | Realtek ALC1220P | — |
| Audio output channels | 7.1 channels | 7.1 channels | 7.1 channels | 7.1 channels | — |
| Bandwidth | — | — | — | — | 128 Gbit/s |
| Component for | PC | PC | PC | PC | — |
| Cooling type | Active | — | — | Passive | — |
| Motherboard chipset | AMD B550 | Intel B860 | Intel B760 | Intel Z890 | — |
| Motherboard chipset family | AMD | Intel | Intel | Intel | — |
| Motherboard form factor | ATX | ATX | micro ATX | ATX | — |
| PC health monitoring | CPU, Fan | — | — | — | — |
| Power source type | ATX | — | — | ATX | — |
| Product colour | Black | White | Black | Black | — |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64 | Windows 11 | Windows 10 x64, Windows 11 x64 | Windows 11 | — |
| Other features | |||||
| Back-to-BIOS button | — | — | — | Yes | — |
| mSATA ports quantity | 0 | — | — | 0 | — |
| Quick installation guide | — | — | — | Yes | — |
| Weight | 945 g | 1.4 kg | — | — | — |
| BIOS | |||||
| BIOS memory size | 256000 Mbit | 256 Mbit | 128 Mbit | 256 Mbit | — |
| BIOS type | UEFI AMI | UEFI AMI | UEFI AMI | UEFI AMI | — |
| Clear CMOS button | — | Yes | — | — | — |
| Clear CMOS jumper | — | — | Yes | — | — |
| Weight & dimensions | |||||
| Depth | 244 mm | 244 mm | 244 mm | 244 mm | 13 mm |
| Height | 68 mm | 50 mm | — | — | 96 mm |
| Width | 305 mm | 305 mm | 244 mm | 305 mm | 202 mm |
| Rear panel I/O ports | |||||
| DisplayPort version | 1.2 | — | 1.4 | 1.4 | — |
| DisplayPorts quantity | 1 | 1 | 1 | 1 | — |
| DVI-D ports quantity | 0 | 0 | 0 | 0 | — |
| eSATA ports quantity | 0 | — | — | — | — |
| Ethernet LAN (RJ-45) ports | 1 | 1 | 1 | 1 | — |
| Firewire (IEEE 1394) ports | 0 | — | — | — | — |
| HDMI ports quantity | 1 | 1 | 2 | 1 | — |
| HDMI version | 2.1 | — | 2.1 | 2.1 | — |
| Headphone outputs | 1 | — | 3 | 1 | — |
| Line-in | — | — | — | Yes | — |
| Microphone in | Yes | Yes | — | — | — |
| PS/2 ports quantity | 0 | — | 1 | — | — |
| S/PDIF out port | Yes | Yes | — | Yes | — |
| Thunderbolt ports quantity | — | — | — | 1 | — |
| USB 2.0 ports quantity | 2 | 4 | 4 | 0 | — |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 | 2 | 0 | 3 | — |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 | 0 | 0 | 0 | — |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 | 2 | 2 | 3 | — |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 | 1 | 0 | 1 | — |
| USB connector type | — | — | USB Type-A | — | — |
| USB4 Gen 2x2 ports quantity | — | 1 | — | — | — |
| VGA (D-Sub) ports quantity | 0 | 0 | 0 | 0 | — |
| WiFi-AP antenna jack | — | — | 1 | 2 | — |
| Ports & interfaces | |||||
| Expansion card standard | — | — | — | — | PCIe 3.0 |
| Host interface | — | — | — | — | PCIe |
| Number of M.2 (M) slots | — | — | — | — | 1 |
| Output interface | — | — | — | — | M.2 |
| Logistics data | |||||
| Harmonized System (HS) code | 84733020 | — | — | — | 84733020 |
| Design | |||||
| Internal | — | — | — | — | Yes |
| Packaging data | |||||
| Manual | — | — | — | — | Yes |
| Package depth | — | 273 mm | — | 273 mm | — |
| Package height | — | 70 mm | — | 68 mm | — |
| Package weight | — | 1.68 kg | — | 2.34 kg | — |
| Package width | — | 355 mm | — | 353 mm | — |
| Quantity | — | — | — | — | 1 |
| Storage controllers | |||||
| Number of HDDs supported | 6 | 4 | — | 4 | — |
| Number of storage drives supported | — | 8 | 6 | 8 | — |
| RAID levels | 0, 1, 10 | 0, 1, 5, 10 | 0, 1, 5, 10 | 0, 1, 5, 10 | — |
| RAID support | Yes | Yes | Yes | Yes | — |
| Supported storage drive interfaces | M.2, SATA III | M.2, SATA III | M.2, PCI Express 4.0, SATA III | M.2, SATA III | — |
| Supported storage drive types | HDD & SSD | HDD & SSD | HDD & SSD | HDD & SSD | — |
| Expansion slots | |||||
| Number of M.2 (M) slots | 2 | — | — | 4 | — |
| PCI Express slots version | 3.0, 4.0 | — | — | — | — |
| PCI Express x1 (Gen 3.x) slots | 3 | — | — | — | — |
| PCI Express x16 (Gen 3.x) slots | 1 | — | — | — | — |
| PCI Express x16 (Gen 4.x) slots | 1 | 1 | 3 | 1 | — |
| PCI Express x16 (Gen 5.x) slots | — | — | — | 1 | — |
| PCI Express x4 (Gen 1.x) slots | — | — | — | 2 | — |
| PCI Express x4 (Gen 4.x) slots | — | — | — | 1 | — |
| PCI slots | 7 | — | — | — | — |
