Product Comparison
Technical Specifications
Feature
General
Authentication Method
RADIUS
—
Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2)
RADIUS, TACACS+, Secure Shell v.2 (SSH2), Secure Shell (SSH)
RADIUS, TACACS+
Capacity
Link aggregation ports: 8 IPv4 routes (static): 32 VLANs supported: 256 Access Control Entries (ACEs) per ACL: 480 Packet buffer size: 1.5 MB
—
Packet buffer size: 8 MB IPv4 ACL entries (ingress): 5120 IPv6 ACL entries (ingress): 1280 MAC ACL entries (ingress): 5120 IPv4 ACL entries (egress): 2048 IPv6 ACL entries (egress): 512 MAC ACL entries (egress): 2048
Packet buffer size: 8 MB
Switched virtual interfaces (SVIs): 128 IPv4 host table capacity: 8000 IPv6 host table capacity: 8000 IPv4 routes (Unicast): 2000 IPv6 routes (Unicast): 2000 IGMP groups: 1000 MLD groups: 1000 IPv4 ACL entries (ingress): 1000 IPv6 ACL entries (ingress): 1000 MAC ACL entries (ingress): 1000 IPv4 ACL entries (egress): 512 IPv6 ACL entries (egress): 256 MAC ACL entries (egress): 512
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.2af
—
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az
IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3ad (LACP), IEEE 802.1D, IEEE 802.1w, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1ab (LLDP), IEEE 802.1x
IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at
Device Type
Switch - 28 ports - L3 - Managed
—
Switch - 24 ports - L3 - Managed - stackable
Switch - 48 ports - L3 - Managed - stackable
Switch - 12 ports - L3 - Managed - stackable
Enclosure Type
Rack-mountable 1U
—
Rack-mountable 1U
Front and side to back rack-mountable 1U
Rack-mountable 1U
Encryption Algorithm
SSL
—
SSL, FIPS 140-2
FIPS 140-2, SSL
MD5, SSL, FIPS 140-2
Features
Flow control, DHCP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, IPv6 support, half duplex mode, full duplex mode, STP support, MSTP support, ACL support, QoS, TPM, LLDP support, LACP, Energy Efficient Ethernet, CoS, BPDU Filter, PoE Class 4
—
VRRP support, TPM, UDLD, DWRR, CoS, ToS, BPDU, RPVST+, LLDP, UTM, EQS, Address Resolution Protocol
UTM, UDLD, VRRP support, DWRR, CoS, ToS, EQS, RPVST+, BPDU, Address Resolution Protocol, LLDP, TPM
Layer 2 switching, ARP support, DiffServ support, VRRP support, QoS, TPM, ECMP, UDLD, fanless, DWRR, MIB, CoS, ToS, BPDU, SSM, NTP, security slot (Kensington security lock compatible), RPVST+, DNS support, IGMP support, UDLD, Auto MDIX, web GUI management portal, UTM, EQS
Flash Memory
256 MB
—
—
16 GB
16 GB
Jumbo Frame Support
9216 bytes
—
9220 bytes
9220 bytes
9198 bytes
MAC Address Table Size
16000 entries
—
—
32768 entries
32000 entries
Max Units In A Stack
—
—
8
8
8
Performance
Switching capacity: 128 Gbps Throughput: 95.23 Mpps Latency (1 Gbps): 2.4 µs Latency (10 Gbps): 1.3 µs
—
Switching capacity: 128 Gbps Throughput: 95.2 Mpps Latency (1 Gbps): 2.28 µs Latency (10 Gbps): 1.46 µs Stacking bandwidth: 40 Gbps
Latency (1 Gbps): 2.28 µs, Latency (10 Gbps): 1.46 µs
Switching capacity: 68 Gbps Throughput: 50.5 Mpps Latency (1 Gbps): 3.8 µs Latency (10 Gbps): 2.9 µs Packet buffer size: 12.38 MB Stacking bandwidth: 20 Gbps
PoE Budget
370 W
—
370 W
370 W
139 W
Ports
24 x 10/100/1000 (PoE) + 4 x 1 Gigabit / 10 Gigabit SFP+
—
24 x 10/100/1000 (PoE+) + 4 x 1 Gigabit / 10 Gigabit SFP+ (uplink)
48 x 10/100/1000 (PoE+) + 4 x 1 Gigabit / 10 Gigabit SFP+ (uplink)
12 x 10/100/1000 (PoE+) + 2 x 100/1000 (uplink) + 2 x 1 Gigabit / 10 Gigabit SFP+
Power Over Ethernet (PoE)
PoE
—
PoE+
PoE+
PoE+
Processor
1 x ARM: 800 MHz
—
1 x ARM Cortex-A72: 1.8 GHz
1 x ARM Cortex-A72: 1.8 GHz
1 x ARM: 1.2 GHz
RAM
512 MB SDRAM
—
—
8 GB DDR4 SDRAM
8 GB DDR4 SDRAM
Remote Management Protocol
SNMP 1, RMON, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, RADIUS
—
RMON, CLI, MIB
RMON, CLI, MIB
SNMP, SNMP 3, SNMP 2c, CLI
Routing Protocol
Static IP routing
—
RIP-2, IGMPv2, IGMP, OSPFv2, IGMPv3, OSPFv3, MLDv2, MLD
IGMP, IGMPv2, IGMPv3, RIP-2, OSPFv2, OSPFv3, MLD, MLDv2
OSPF, RIP-2, OSPFv2, OSPFv3, ECMP
Status Indicators
Port status, power, PoE
—
—
—
—
Subtype
Gigabit Ethernet
—
10 Gigabit Ethernet
Gigabit Ethernet
Gigabit Ethernet
Power
Power Consumption Operational
439 Watt
—
—
—
28 Watt
Power Device
Internal power supply
—
Internal power supply
Internal power supply
Internal power supply
Voltage Required
AC 120 V (50/60 Hz)
—
—
—
AC 90-264 V (50/60 Hz)
Miscellaneous
Compliant Standards
CISPR 24, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-3-3, EN 55024:2010, CISPR 35, SSL, EN 55035:2017
—
EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-3-3, Laser Class 1, EN 61000-3-3:2013, EN 60825-1:2014, IEC 62368-1: 2014 Second Edition, EN 62368-1:2014+A11:2017, EN 61000-3-2:2019, IEC 60825-1:2014 Class 1, CISPR 35: 2016, UL 62368-1 Third Edition, EN 62368-1:2020+A11:2020, KS C 9832, EN 63000:2018, IEC 62368-1:2018 Third Edition, EN 55035:2017+A11:2020, CNS 15598-1:2020, CAN/CSA C22.2 No. 62368-1:19 Third Edition, GB 4943.1-2022, KC 62368-1: 2021-08, EN 55032:2015 /A11:2020, Class A, FCC 47 CFR part 15B:2021 Class A, ICES-003 Issue 7: 2020 Class A, VCCI-CISPR 32 Class A, CISPR 32:2016 Class A, AS/NZS CISPR 32:2015 Class A, IEC 63000:2018
EN 62368-1:2014+A11:2017, EN 62368-1:2020+A11:2020, UL 62368-1 Third Edition, CAN/CSA C22.2 No. 62368-1:19 Third Edition, IEC 62368-1: 2014 Second Edition, IEC 62368-1:2018 Third Edition, CNS 15598-1:2020, GB 4943.1-2022, KC 62368-1: 2021-08, EN 55032:2015 /A11:2020, Class A, EN 61000-3-2:2019, EN 61000-3-3:2013, FCC 47 CFR part 15B:2021 Class A, ICES-003 Issue 7: 2020 Class A, VCCI-CISPR 32 Class A, CISPR 32:2016 Class A, AS/NZS CISPR 32:2015 Class A, CNS 15936: 2020 Class A, KS C 9832, EN 60825-1:2014, IEC 60825-1:2014 Class 1, Laser Class 1, CISPR 35: 2016, EN 55035:2017+A11:2020, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11, EN 61000-3-2, EN 61000-3-3, IEC 61000-3-2, IEC 61000-3-3, EN 63000:2018, IEC 63000:2018
EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-3-3, ICES-003 Class A, RoHS, Laser Class 1, WEEE, VCCI Class A, EN 50581:2012, IEC 60950-1:2005 + A1:2009 + A2:2013, DoE Level VI, CISPR 35, EN 60825-1:2014, IEC 62368-1: 2014 Second Edition, EN 61000-3-2:2019, IEC 60825-1:2014 Class 1, UL 62368-1 Third Edition, EN 61000-3-3:2013/A1:2019, IEC 62368-1:2018 Third Edition, EN 55035:2017+A11:2020, EN 62368-1:2014+A11:2017 2nd Ed., EN 62368-1:2020+A11:2020 3rd Ed., BS EN 62368-1:2020 + A11:2020 3rd Ed, CNS 15598-1:2020, CISPR 32 Ed 2.1: 2019 Class A, CISPR 35 Ed 1.0:2016, CSA 22.2 No.62368-1 Third Edition, EN 55032:2015 + A11:2020 Class A, FCC 47 CFR part 15B:2014 Class A
Included Accessories
—
—
—
—
Rack kit (2 post)
Localisation
English / United Kingdom
—
English / United Kingdom
English / United Kingdom
English / United Kingdom
MTBF
71 years
—
—
—
—
Pricing Type
—
—
BTO
BTO
—
Service & Support
Limited warranty - lifetime
—
—
—
—
Environmental Parameters
AC 120 V (50/60 Hz)
0 °C
—
—
—
—
Humidity Range Operating
15 - 95% (40 °C)
—
5 - 95% (non-condensing)
5 - 95% (non-condensing)
5 - 95% RH (non-condensing)
Humidity Range Storage
15 - 95% (60 °C)
—
5 - 95% (non-condensing)
5 - 95% (non-condensing)
5 - 95% RH (non-condensing)
Max Operating Temperature
40 °C
—
45 °C
45 °C
45 °C
Max Storage Temperature
70 °C
—
70 °C
70 °C
70 °C
Min Operating Temperature
—
—
0 °C
0 °C
0 °C
Min Storage Temperature
-40 °C
—
-40 °C
-40 °C
-40 °C
OS Required
—
—
—
—
AOS-CX
Weight & Dimensions
Depth
26.47 cm
—
30.43 cm
30.43 cm
30.5 cm
Height
4.39 cm
—
4.37 cm
4.37 cm
4.39 cm
Weight
3.67 kg
—
4.39 kg
4.87 kg
3.24 kg
Width
44.25 cm
—
44.25 cm
44.25 cm
25.4 cm
Connections & Expansion
Interfaces
24 x 10/100/1000 Base-T RJ-45 PoE - 370 W 4 x 1/10Gbit LAN SFP+
—
24 x 10/100/1000 Base-T RJ-45 PoE+ - 30 W 4 x 100/1000/10G SFP+ uplink 1 x USB-C console 1 x console RJ-45 1 x management 1 x USB Type A host
48 x 10/100/1000 Base-T RJ-45 PoE+ - 30 W, 4 x 100/1000/10G SFP+ uplink, 1 x USB-C console, 1 x console RJ-45, 1 x management, 1 x USB Type A host
12 x 10/100/1000 Base-T RJ-45 PoE Class 4 2 x 1/10Gbit LAN SFP+ 2 x 1000Base-T 1 x console RJ-45 1 x console (USB) Type C 1 x USB Type A host
Manufacturer Warranty
Service & Support
—
—
Limited warranty - lifetime
Limited warranty - lifetime
Limited warranty - lifetime
