Compare Lenovo Portable Docking stations
Comparing 4 products side-by-side — specifications, pricing and stock. Showing Lenovo products in the Portable Docking stations category.
| Specification | ||||
|---|---|---|---|---|
| General | ||||
| Depth | — | 8 cm | — | — |
| Docking Interface | USB-C | USB-C | USB-C | Thunderbolt 4 |
| Enclosure Colour | — | Black | — | — |
| Height | — | 3.075 cm | — | — |
| Localisation | — | United Kingdom, Hong Kong, Singapore, Sri Lanka | — | — |
| Optical Storage | — | None | None | None |
| Product Type | Mini-dock | Docking station | Docking station | Docking station |
| Video Interfaces | VGA, HDMI | HDMI, 2 x DP | 2 x HDMI, 2 x DP | 2 x DP, HDMI, 2 x Thunderbolt |
| Weight | — | 340 g | — | — |
| Width | — | 17.1 cm | — | — |
| Power | ||||
| Output current | — | — | — | 15 A |
| Output voltage | — | — | — | 20 V |
| Power consumption (max) | — | — | — | 230 W |
| Power Device | — | Power adapter | — | — |
| Power Provided | — | 90 Watt | — | — |
| Power source type | AC | — | — | AC |
| Power supply | 65 W | — | — | 300 W |
| Network | ||||
| 10G support | — | — | No | — |
| Data Link Protocol | Gigabit Ethernet | Gigabit Ethernet | — | — |
| Ethernet LAN | Yes | — | Yes | Yes |
| Ethernet LAN (RJ-45) ports | 1 | — | 1 | 1 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s | — | 10,100,1000 Mbit/s | 10,100,1000 Mbit/s |
| Wake-on-LAN ready | — | — | Yes | — |
| Miscellaneous | ||||
| Compliant Standards | — | FCC, ICES, KCC, RCM, BSMI, VCCI, CB, EAC, TUV Mark, Kvalitet, LoA, SII, Ukraine EMC DoC, NOM, DisplayPort 1.4 | — | — |
| Features | — | Security lock slot (cable lock sold separately) | — | — |
| Security Slot Type | — | Kensington NanoSaver security slot / Kensington MicroSaver security slot | — | — |
| Packaging content | ||||
| AC adapter included | Yes | — | Yes | Yes |
| Cables included | — | — | AC, USB Type-A to USB Type-C | AC |
| Manual | — | — | — | Yes |
| User guide | — | — | Yes | — |
| Warranty card | — | — | — | Yes |
| Performance | ||||
| Brand compatibility | — | — | Lenovo | — |
| Cable lock slot | — | — | — | Yes |
| Cable lock slot type | — | — | — | Kensington |
| Card reader integrated | No | — | No | No |
| Certification | — | — | — | cULus, FCC, ICES, NOM |
| Data transfer rate | — | — | 10 Gbit/s | 40 Gbit/s |
| HD type | — | — | — | 8K Ultra HD |
| LED indicators | — | — | — | Yes |
| Maximum digital resolution | — | — | — | 7680 x 4320 pixels |
| Maximum refresh rate | — | — | — | 30 Hz |
| Number of displays supported | — | — | — | 4 |
| Optical drive included | — | — | No | — |
| Product colour | Black | — | Black | Black, Red |
| VESA mounting | — | — | — | Yes |
| Audio | ||||
| Built-in speaker(s) | — | — | — | No |
| Ports & interfaces | ||||
| Combo headphone/mic port | Yes | — | Yes | Yes |
| Connectivity technology | Wired | — | Wired | Wired |
| DC-in jack | — | — | — | Yes |
| DisplayPort version | — | — | — | 1.4 |
| DisplayPorts quantity | — | — | 2 | 2 |
| HDMI ports quantity | 1 | — | 2 | 1 |
| HDMI version | 2.0 | — | — | 2.1 |
| Headphone connectivity | 3.5 mm | — | 3.5 mm | — |
| Headphone outputs | 0 | — | 1 | 0 |
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-C | — | USB 3.2 Gen 1 (3.1 Gen 1) Type-C | Thunderbolt 4 |
| Microphone in | No | — | — | No |
| Thunderbolt 4 ports quantity | — | — | — | 1 |
| USB 2.0 ports quantity | 1 | — | 2 | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 | — | — | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 2 | — | — | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | — | — | 3 | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | — | — | 1 | — |
| USB Power Delivery (USB PD) | — | — | — | Yes |
| USB Power Delivery up to | — | — | — | 230 W |
| Weight & dimensions | ||||
| Depth | 53 mm | — | 80 mm | 80 mm |
| Height | 17 mm | — | 30 mm | 30 mm |
| Weight | 156 g | — | 480 g | 450 g |
| Width | 180 mm | — | 210 mm | 220 mm |
| Logistics data | ||||
| Harmonized System (HS) code | 84733020 | — | 84733020 | 84733020 |
| Connections & Expansion | ||||
| Interfaces | — | USB 3.2 Gen 2 with Always-on charging 2 x USB 3.2 Gen 2 1 x USB-C - 24 pin USB-C 1 x network - 10Base-T/100Base-TX/1000Base-T - RJ-45 2 x audio / video - DisplayPort - 20 pin DisplayPort 1 x audio / video - HDMI - 19 pin HDMI Type A 1 x audio - headphones/microphone - mini-phone 3.5 mm 4-pole 2 x USB 2.0 - 4 pin USB Type A | — | — |
| Environmental Parameters | ||||
| Max Operating Temperature | — | 35 °C | — | — |
| Min Operating Temperature | — | 0 °C | — | — |
| Video | ||||
| Max Resolution Details | — | 3840 x 2160 - 60 Hz (Dual Display) 3840 x 2160 - 30 Hz (Triple Display) | — | — |
| Operational conditions | ||||
| Operating relative humidity (H-H) | 20 - 95% | — | — | 5 - 95% |
| Operating temperature (T-T) | -5 - 40 °C | — | — | 0 - 40 °C |
| System requirements | ||||
| OS Required | — | Microsoft Windows 7 / 10 | — | — |
| Packaging data | ||||
| Package depth | 210 mm | — | — | 195 mm |
| Package height | 65 mm | — | — | 85 mm |
| Package weight | 565 g | — | — | 1.9 kg |
| Package width | 215 mm | — | — | 270 mm |
| Quantity per pack | 1 pc(s) | — | — | 1 pc(s) |
| Manufacturer Warranty | ||||
| Service & Support | — | Limited warranty - 3 years | — | — |
| Dimensions & Weight (Shipping) | ||||
| Shipping Depth | — | 15.8 cm | — | — |
| Shipping Height | — | 7.5 cm | — | — |
| Shipping Weight | — | 955 g | — | — |
| Shipping Width | — | 21 cm | — | — |
| Software | ||||
| Windows operating systems supported | Windows 10 | — | — | Windows 10 |
