Compare TP-Link Access Point/Extenders
Comparing 5 products side-by-side — specifications, pricing and stock. Showing TP-Link products in the Access Point/Extenders category.
| Specification | |||||
|---|---|---|---|---|---|
| Power | |||||
| AC input frequency | — | 50/60 Hz | — | — | — |
| AC input voltage | — | 100 - 240 V | — | — | — |
| DC voltage range | 12 V | — | — | — | — |
| Power consumption (max) | — | 9.5 W | — | — | — |
| Power consumption (typical) | — | — | 3 W | — | 12 W |
| Power over Ethernet (PoE) | Yes | — | — | — | Yes |
| Power over Ethernet (PoE) type supported | Active PoE, Passive PoE | — | — | — | — |
| Network | |||||
| Cabling technology | — | 10/100Base-T(X) | — | — | — |
| Ethernet LAN interface type | — | Fast Ethernet | — | — | — |
| Networking standards | — | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n | — | — | — |
| Security algorithms | — | 64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK | WEP, WPA-PSK, WPA2-PSK | — | — |
| Top Wi-Fi standard | — | Wi-Fi 5 (802.11ac) | — | — | — |
| Wi-Fi | — | Yes | Yes | — | — |
| Wi-Fi band | — | Dual-band (2.4 GHz / 5 GHz) | — | — | — |
| Wi-Fi data rate (max) | — | 867 Mbit/s | — | — | — |
| Wi-Fi standards | — | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) | 802.11b, 802.11g, Wi-Fi 4 (802.11n) | — | — |
| WLAN data transfer rates supported | — | 300 Mbit/s | — | — | — |
| Features | |||||
| 2.4 GHz | Yes | — | — | — | Yes |
| 5 GHz | Yes | — | — | — | Yes |
| 6 GHz | No | — | — | — | No |
| Airtime Fairness (ATF) | Yes | — | — | — | Yes |
| Automatic channel scanning | Yes | — | — | — | — |
| Automatic channel selection | Yes | — | — | — | Yes |
| Band steering | Yes | — | — | — | Yes |
| BeamForming | Yes | — | — | — | Yes |
| Cabling technology | 10/100/1000Base-T(X) | — | — | — | 10/100/1000Base-T(X) |
| Ethernet LAN data rates | 10,100,1000 Mbit/s | — | — | — | 10,100,1000 Mbit/s |
| Fit AP mode features | Mesh networking | — | — | — | — |
| Flow control support | Yes | — | — | — | — |
| Frequency band | 2.4 - 5 GHz | — | — | — | 2.4, 5 GHz |
| Housing material | — | — | — | Plastic | — |
| Maximum data transfer rate | 1201 Mbit/s | — | — | — | 2402 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 574 Mbit/s | — | — | — | 574 Mbit/s |
| Maximum data transfer rate (5 GHz) | 1201 Mbit/s | — | — | — | 2402 Mbit/s |
| MIMO | Yes | — | — | — | — |
| MIMO type | Multi User MIMO | — | — | — | — |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at | — | — | — | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
| Number of users | 1020 user(s) | — | — | — | 100 user(s) |
| Product colour | — | — | — | White | — |
| Quality of Service (QoS) support | Yes | — | — | — | Yes |
| Rate limiting | Yes | — | — | — | Yes |
| Spread spectrum method | OFDMA | — | — | — | — |
| Transmitting power (CE) | 20/23 dBm | — | — | — | 20 - 23 - 26 dBm |
| Transmitting power (FCC) | 23 dBm | — | — | — | 21 - 21 dBm |
| VLAN support | Yes | — | — | — | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | — | — | — | — | Yes |
| Wireless isolation | — | — | — | — | Yes |
| Security | |||||
| Access Control List (ACL) | Yes | — | — | — | Yes |
| IP address filtering | — | — | — | — | Yes |
| MAC address filtering | Yes | — | — | — | Yes |
| Number of SSID supported | — | — | — | — | 16 |
| Remote Authentication Dial-In User Service (RADIUS) | Yes | — | — | — | Yes |
| Security algorithms | SNMP, SNMPv2, SNMPv3, SSH, WEP, WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPA3, WPA3-PSK | — | — | — | HTTPS, SNMP, SNMPv2, SNMPv3, SSH, WPA-Enterprise, WPA2-Enterprise, WPA3-Enterprise |
| Service Set Identifier (SSID) features | — | — | — | — | Multiple SSIDs |
| Antenna | |||||
| Antenna direction type | Omni-directional | — | — | — | — |
| Antenna gain level (max) | — | — | — | — | 5 dBi |
| Antenna type | Internal | External | — | — | Internal |
| Antennas quantity | — | 2 | — | — | 2 |
| Transmitting power (CE) | — | 2.4 GHz ≤20dBm, 5 GHz ≤30dBm | 20 dBm | — | — |
| Performance | |||||
| Antenna gain level (max) | — | — | — | 23 dBi | — |
| Browser supported | — | Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 | — | — | — |
| Built-in processor | — | — | — | Yes | — |
| Compatible operating systems | — | — | — | — | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows 11, Linux |
| Data transfer rate | — | 867 Mbit/s | 300 Mbit/s | — | — |
| Ethernet LAN data rates | — | 10,100 Mbit/s | 10,300 Mbit/s | — | — |
| Flash memory | — | — | — | 8 MB | — |
| Frequency band | — | — | — | 5 GHz | — |
| Internal memory | — | — | — | 64 MB | — |
| Internal memory type | — | — | — | DDR2 | — |
| Linux operating systems supported | — | Yes | — | — | — |
| Mac compatibility | — | Yes | — | — | — |
| Mac operating systems supported | — | Yes | — | — | — |
| Networking standards | — | — | — | IEEE 802.11a, IEEE 802.11n | — |
| Processor frequency | — | — | — | 560 MHz | — |
| Processor model | — | — | — | Atheros MIPS 74Kc | — |
| Type | — | Network repeater | Network repeater | — | — |
| Windows operating systems supported | — | Yes | — | — | — |
| WPS push button | — | Yes | — | — | — |
| Design | |||||
| Cable lock slot | — | — | — | — | No |
| Certification | — | CE, RoHS | — | — | — |
| LED indicators | Yes | Yes | — | — | Yes |
| Placement | Ceiling, Wall | — | — | — | Wall |
| Product colour | White | White | White | — | White |
| Quantity per pack | — | 1 pc(s) | — | — | — |
| Reset button | Yes | Yes | — | — | Yes |
| Certificates | |||||
| Certification | CE, FCC, RoHS | — | — | — | FCC, RoHS |
| Compliance certificates | — | CE, RoHS | RoHS | — | RoHS |
| Group 41455 | |||||
| Certification | — | — | — | CE, FCC | — |
| Compliance certificates | — | — | — | RoHS | — |
| Ports & interfaces | |||||
| DC-in jack | Yes | — | — | — | Yes |
| Ethernet LAN (RJ-45) ports | 1 | 1 | 1 | — | 4 |
| Host interface | — | — | RJ-45 | — | — |
| USB 2.0 ports quantity | 0 | — | — | — | 0 |
| WAN connection | — | — | — | — | Ethernet (RJ-45) |
| Weight & dimensions | |||||
| Depth | 160 mm | 35 mm | 65.8 mm | — | 86 mm |
| Height | 33 mm | 124.1 mm | 110 mm | — | 42.6 mm |
| Width | 160 mm | 89 mm | 75.2 mm | — | 143 mm |
| Management features | |||||
| Firmware upgradeable | Yes | — | — | — | Yes |
| Syslog | Yes | — | — | — | Yes |
| Web-based management | Yes | — | — | — | Yes |
| Logistics data | |||||
| Harmonized System (HS) code | — | 85176990 | 85176990 | 85177100 | — |
| Group 4023 | |||||
| Input voltage | — | — | — | 16 - 27 V | — |
| Packaging content | |||||
| Mounting kit | Yes | — | — | — | Yes |
| Quantity per pack | 1 pc(s) | — | — | — | 1 pc(s) |
| Quick start guide | Yes | Yes | — | — | — |
| Operational conditions | |||||
| Operating relative humidity (H-H) | 10 - 90% | 10 - 90% | 10 - 90% | — | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C | 0 - 40 °C | 0 - 40 °C | — | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 90% | 5 - 90% | 5 - 90% | — | 5 - 90% |
| Storage temperature (T-T) | -40 - 70 °C | -40 - 70 °C | -40 - 70 °C | — | -40 - 70 °C |
| Packaging data | |||||
| Package depth | — | 89 mm | — | — | 184 mm |
| Package height | — | 156.5 mm | — | — | 56 mm |
| Package type | Box | Box | — | — | Box |
| Package weight | — | 260 g | — | — | 400 g |
| Package width | — | 121.5 mm | — | — | 117 mm |
| Group 11371 | |||||
| Quick installation guide | — | — | — | Yes | — |
| Sustainability | |||||
| Sustainability compliance | — | — | Yes | — | — |
