D-Link 10GBase-SR SFP+ Transceiver, 80/300m

Name: D-Link 10GBase-SR SFP+ Transceiver, 80/300m
Brand: D-Link
SKU: DEM-431XT
Price: 93.52 GBP
Availability: InStock

Manuf P/N: DEM-431XT

APAXON#: 2232703

EAN: 0790069353130

SFP+ Fiber optic 10000 Mbit/s
Wavelength: 850 nm
Hot-Plug support

Stock20

Price £ 93.52

Price inc. VAT

£ 112.22

Quantity

Notify me when available.

Product Summary

D-Link DEM-431XT network transceiver module Fiber optic 10000 Mbit/s SFP+ 850 nm

Extended Specification

Group 11207

SFP transceiver type

Fiber optic

Maximum data transfer rate

10000 Mbit/s

Interface type

SFP+

Single-mode fiber (SMF) supported

Multi-mode fiber (MMF) supported

Yes

Fiber optic connector

Fiber cable diameters supported (core/cladding)

50/125,62.5/125 µm

SFP transceiver standard

Maximum transfer distance

550 m

Wavelength

850 nm

Tx power (min)

-6.5 dBmW

Tx power (max)

-1 dBmW

Rx power (min)

-11.1 dBmW

Rx power (max)

-1 dBmW

Link budget

10.1 dB

Networking standards

IEEE 802.3ae

Fiber ethernet cabling technology

10GBASE

Duplex system

Full

Group 14500

Product colour

Gold, Metallic

Hot-Plug support

Yes

Mean time between failures (MTBF)

3960000 h

Group 6700

Maximum voltage

3.3 V

Maximum current

300 A

Group 41470

Compliance certificates

RoHS

Safety

UL, TUV, CDRH

Certification

CE, FCC, VCCI, C-Tick, MSA

Group 6686

Operating temperature (T-T)

0 - 70 °C

Storage temperature (T-T)

-40 - 85 °C

Operating relative humidity (H-H)

5 - 85%

Storage relative humidity (H-H)

5 - 95%

Group 6695

Width

14.8 mm

Depth

11.8 mm

Height

56.5 mm

Weight

18 g

Group 32111

Package width

74 mm

Package depth

131 mm

Package height

49 mm

Package weight

64 g

Group 24991

Shipping (inner) case length

36 cm

Shipping (inner) case width

26 cm

Shipping (inner) case height

31 cm

Shipping (inner) case net weight

3.2 kg

Products per shipping (inner) case

50 pc(s)

Pallet gross weight (air)

272 kg

Master (outer) cases per pallet (air)

60 pc(s)

Products per pallet (air)

3000 pc(s)

Pallet gross length

102 cm

Pallet gross width

122 cm

Pallet height (air)

199 cm

Pallet gross weight (sea)

272 kg

Master (outer) cases per pallet (sea)

60 pc(s)

Products per pallet (sea)

3000 pc(s)

Pallet height (sea)

199 cm

Shipping (inner) case gross weight

4.2 kg

Harmonized System (HS) code

85369010

D-Link 10GBase-SR SFP+ Transceiver, 80/300m
