This product is out of stock
We can email you when it's back in stock, confirm expected lead times, or recommend in-stock alternatives that meet the same requirements.
D-Link 10GBase-SR SFP+ Transceiver, 80/300m
- SFP+ Fiber optic 10000 Mbit/s
- Wavelength: 850 nm
- Hot-Plug support
Similar Products
Overview
D-Link DEM-431XT network transceiver module Fiber optic 10000 Mbit/s SFP+ 850 nm
Specifications
Performance
- SFP transceiver type
- Fiber optic
- Maximum data transfer rate
- 10000 Mbit/s
- Interface type
- SFP+
- Single-mode fiber (SMF) supported
- No
- Multi-mode fiber (MMF) supported
- Yes
- Fiber optic connector
- LC
- Fiber cable diameters supported (core/cladding)
- 50/125,62.5/125 µm
- SFP transceiver standard
- SR
- Maximum transfer distance
- 550 m
- Wavelength
- 850 nm
- Tx power (min)
- -6.5 dBmW
- Tx power (max)
- -1 dBmW
- Rx power (min)
- -11.1 dBmW
- Rx power (max)
- -1 dBmW
- Link budget
- 10.1 dB
- Networking standards
- IEEE 802.3ae
- Fiber ethernet cabling technology
- 10GBASE
- Duplex system
- Full
Features
- Product colour
- Gold, Metallic
- Hot-Plug support
- Yes
- Mean time between failures (MTBF)
- 3960000 h
Power
- Maximum voltage
- 3.3 V
- Maximum current
- 300 A
Certificates
- Compliance certificates
- RoHS
- Safety
- UL, TUV, CDRH
- Certification
- CE, FCC, VCCI, C-Tick, MSA
Operational conditions
- Operating temperature (T-T)
- 0 - 70 °C
- Storage temperature (T-T)
- -40 - 85 °C
- Operating relative humidity (H-H)
- 5 - 85%
- Storage relative humidity (H-H)
- 5 - 95%
Weight & dimensions
- Width
- 14.8 mm
- Depth
- 11.8 mm
- Height
- 56.5 mm
- Weight
- 18 g
Packaging data
- Package width
- 74 mm
- Package depth
- 131 mm
- Package height
- 49 mm
- Package weight
- 64 g
Logistics data
- Shipping (inner) case length
- 36 cm
- Shipping (inner) case width
- 26 cm
- Shipping (inner) case height
- 31 cm
- Shipping (inner) case net weight
- 3.2 kg
- Products per shipping (inner) case
- 50 pc(s)
- Pallet gross weight (air)
- 272 kg
- Master (outer) cases per pallet (air)
- 60 pc(s)
- Products per pallet (air)
- 3000 pc(s)
- Pallet gross length
- 102 cm
- Pallet gross width
- 122 cm
- Pallet height (air)
- 199 cm
- Pallet gross weight (sea)
- 272 kg
- Master (outer) cases per pallet (sea)
- 60 pc(s)
- Products per pallet (sea)
- 3000 pc(s)
- Pallet height (sea)
- 199 cm
- Shipping (inner) case gross weight
- 4.2 kg
- Harmonized System (HS) code
- 85369010
