Dell 20" Monitor E2020H
Manuf P/N: DELL-E2020H
APAXON#: 5631620
EAN: 5397184200674
Dell E2020H
LED monitor
20" (19.5" viewable)
1600 x 900 @ 60 Hz
TN
250 cd/m²
1000:1
5 ms
VGA, DisplayPort
black
with 3 years Advanced Exchange Service
Weight: 4.08 KG
LED monitor
20" (19.5" viewable)
1600 x 900 @ 60 Hz
TN
250 cd/m²
1000:1
5 ms
VGA, DisplayPort
black
with 3 years Advanced Exchange Service
Weight: 4.08 KG
- Maximize your workspace
- Enhanced views
- Versatile connections
- Adapts to your needs
- Productive at every level
Stock341
Price £79.72
Quantity
|
Similar Products
Product Summary
An affordable 19.5" monitor made for your daily workflow. Featuring an elegant design, 1600x900 resolution and Dell Display Manager.
Extended Specification
Display
Display diagonal
49.5 cm (19.5") cm
Display resolution
1600 x 900 pixels pixels
Response time
5 ms ms
Maximum refresh rate
60 Hz Hz
Display brightness (typical)
250 cd/m² cd/m²
Viewing angle, horizontal
170° °
Viewing angle, vertical
160° °
Pixel pitch
0.27 x 0.27 mm mm
Pixel density
94 ppi ppi
Horizontal scan range
30 - 83 kHz kHz
Vertical scan range
50 - 76 Hz Hz
Viewable size, horizontal
43.3 cm cm
Viewable size, vertical
23.8 cm cm
Viewable size diagonal
49.5 cm cm
NTSC coverage (typical)
72% %
Display diagonal
49.5 cm (19.5")
Display resolution
1600 x 900 pixels
Native aspect ratio
16:9
Display technology
LCD
Touchscreen
No
HD type
HD+
Panel type
TN
Response time
5 ms
Screen shape
Flat
Contrast ratio (typical)
1000:1
Maximum refresh rate
60 Hz
Display number of colours
16.78 million colours
Backlight type
LED
Display brightness (typical)
250 cd/m²
Supported graphics resolutions
640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1600 x 900
Viewing angle, horizontal
170°
Viewing angle, vertical
160°
Pixel pitch
0.27 x 0.27 mm
Pixel density
94 ppi
Horizontal scan range
30 - 83 kHz
Vertical scan range
50 - 76 Hz
Viewable size, horizontal
43.3 cm
Viewable size, vertical
23.8 cm
Viewable size diagonal
49.5 cm
Sync-on-green (SOG)
Yes
High Dynamic Range (HDR) supported
No
DDC/CI
Yes
NTSC coverage (typical)
72%
Dell ComfortView technology
Yes
3D
No
Ergonomics
Panel mounting interface
100 x 100 mm mm
Tilt angle range
-5 - 21° °
VESA mounting
Yes
Cable lock slot
Yes
Height adjustment
No
Panel mounting interface
100 x 100 mm
Pivot
No
Swivelling
No
Tilt adjustment
Yes
Tilt angle range
-5 - 21°
On Screen Display (OSD)
Yes
Plug and Play
Yes
LED indicators
Power
Power
Energy consumption (SDR) per 1000 hours
10 kWh kWh
Power consumption (typical)
9.9 W W
Power consumption (standby)
0.2 W W
Power consumption (max)
14 W W
Power consumption (off)
0.2 W W
Power consumption (PowerSave)
9.37 W W
AC input voltage
100 - 240 V V
AC input frequency
50 - 60 Hz Hz
Input current
0.7 A A
Energy efficiency class (SDR)
D
Energy efficiency class (HDR)
Not available
Energy consumption (SDR) per 1000 hours
10 kWh
Power consumption (typical)
9.9 W
Power consumption (standby)
0.2 W
Power consumption (max)
14 W
Power consumption (off)
0.2 W
Power consumption (PowerSave)
9.37 W
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Input current
0.7 A
Power supply type
Internal
Energy efficiency scale
A to G
European Product Registry for Energy Labelling (EPREL) code
344010
Operational conditions
Operating temperature (T-T)
0 - 40 °C °C
Storage temperature (T-T)
-20 - 60 °C °C
Operating relative humidity (H-H)
10 - 80% %
Storage relative humidity (H-H)
5 - 90% %
Operating altitude
0 - 5000 m m
Non-operating altitude
0 - 12192 m m
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-20 - 60 °C
Operating relative humidity (H-H)
10 - 80%
Storage relative humidity (H-H)
5 - 90%
Operating altitude
0 - 5000 m
Non-operating altitude
0 - 12192 m
Weight & dimensions
Width (with stand)
471.5 mm mm
Depth (with stand)
171 mm mm
Height (with stand)
369 mm mm
Weight (with stand)
2.63 kg kg
Width (without stand)
471.5 mm mm
Depth (without stand)
50.1 mm mm
Height (without stand)
275.4 mm mm
Weight (without stand)
2.2 kg kg
Bezel width (side)
1.83 cm cm
Bezel width (top)
1.83 cm cm
Bezel width (bottom)
1.83 cm cm
Width (with stand)
471.5 mm
Depth (with stand)
171 mm
Height (with stand)
369 mm
Weight (with stand)
2.63 kg
Width (without stand)
471.5 mm
Depth (without stand)
50.1 mm
Height (without stand)
275.4 mm
Weight (without stand)
2.2 kg
Bezel width (side)
1.83 cm
Bezel width (top)
1.83 cm
Bezel width (bottom)
1.83 cm
Packaging data
Package width
118.1 mm mm
Package depth
581.9 mm mm
Package height
343.9 mm mm
Package weight
3.94 kg kg
Package width
118.1 mm
Package depth
581.9 mm
Package height
343.9 mm
Package weight
3.94 kg
Performance
NVIDIA G-SYNC
No
AMD FreeSync
No
Flicker-free technology
Yes
Multimedia
Built-in speaker(s)
No
Built-in camera
No
Design
Market positioning
Home
Product colour
Black
Front bezel colour
Black
Feet colour
Black
Ports & interfaces
Built-in USB hub
No
HDMI
No
Headphone out
No
VGA (D-Sub) ports quantity
1
DVI port
No
HDMI ports quantity
0
DisplayPorts quantity
1
DisplayPort version
1.2
Audio input
No
HDCP
Yes
AC (power) in
Yes
Network
Wi-Fi
No
Packaging content
Stand included
Yes
Cables included
AC, DisplayPort
Manual
Yes
Sustainability
Sustainability certificates
ENERGY STAR
Doesn't contain
PVC
Carbon footprint
Total carbon footprint (kg of CO2e)
401
Total carbon emissions, standard deviation (kg of CO2e)
100
Carbon emissions, manufacturing (kg of CO2e)
305.83
Carbon emissions, logistics (kg of CO2e)
18.9
Carbon emissions, energy usage (kg of CO2e)
75
Carbon emissions, end-of-life (kg of CO2e)
1.08
Total carbon emissions, w/o use phase (kg of CO2e)
326
PAIA version
1.2.6, 2020
Other features
On/off switch
Yes
TV tuner integrated
No
Compliance certificates
RoHS
Ethernet LAN (RJ-45) ports
0
Certification
TCO
Brand-specific features
Dell Display Manager (DDM) compatibility
Yes
Logistics data
Harmonized System (HS) code
85285210

Disclaimers
- Actual configuration might differ from illustration
Product Carbon Footprint (PCF):
1. Dell generally uses the PAIA (Product Attribute to Impact Algorithm)(http://msl.mit.edu/projects/paia/main.html) tool for product carbon footprint calculations.
2. Docking station related PCFs are extracted from corresponding LCAs and as such do not follow the PAIA methodology used for calculating other PCFs in this report.
3. PAIA method is developed by the Massachusetts Institute of Technology’s Materials Systems Laboratory and partners.
4. All estimates of carbon footprint are uncertain. Dell Technologies reports the 5th and 95th percentile of the carbon footprint estimate to reflect this uncertainty wherever possible. (https://www.dell.com/en-us/dt/corporate/social-impact/advancing-sustainability/climate-action/product-carbon-footprints.htm#tab0=0)
5. Please note the emission estimate in this report is calculated using the mean value along with the standard deviation for that product model.
6. Use of default inputs (i.e. not primary data) and assumptions on location of use and other fields can introduce a standard deviation which must be taken into account while completing the calculations.
7. Please note, PAIA uses the ecoinvent Database (https://ecoinvent.org/the-ecoinvent-database/)whenever primary data is not made available for calculations.
8. For client and commercial end user computing products, minimum configurations were assumed for calculations. For Server and Storage products, typical configurations or ENERGY STAR (https://www.energystar.gov/products) configurations were used for calculations.
9. Use Phase emissions were calculated based on the location of use as "Europe" i.e. the Use Phase emissions are not specific to a single country / location.
10. The report does provide an option for a total emissions number for manufacturing, transport and end of life while leaving the use phase emissions out, in case the customer uses their own calculation methodology for use phase emissions.
11. The lifetime usage assumption at the product family level is as follows: Desktop, Notebook - 4 years, Display - 5 years and Servers - 4 years.
12. For detailed assumptions please refer to the product datasheets in the Dell Technologies reports (https://www.dell.com/en-us/dt/corporate/social-impact/advancing-sustainability/climate-action/product-carbon-footprints.htm#tab0=0).
13. The results from the PAIA tool are liable to change over time as the methodology is improved and datasets are updated. The PAIA version used to calculate emissions has been indicated with each record in the report.
14. Metrics used: The units for global warming potential are in kgCO2-equivalent or MT (metric ton) CO2-equivalent (CO2e).
15. Beginning in June 2024, the data dashboard now incorporates PCF values computed using the Dell PCF calculator. It’s important to note that the default location utilized for these calculations shown on the data dashboard is Europe. To access PCF values calculated for the USA and China locales, please refer to the Product PCF PDF document on Dell.com.
