Currently Unavailable

This product is out of stock

We can email you when it's back in stock, confirm expected lead times, or recommend in-stock alternatives that meet the same requirements.

INDUSTRIAL 8 PORT GBE + 2 SFP MANAGE

Manuf P/N: IES101G2SFPW

StarTech.com Industrial 8 Port Gigabit Ethernet Switch w/2 MSA SFP Slots - Hardened GbE L2 Managed Network Switch - Rugged RJ45 LAN Layer 2 Switch Din Rail Wall Mount IP-30/-40C to 75C. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex, Networking standards: IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE.... Wall mountable
  • FLAT DESIGN: Industrial 8 Port Gigabit Ethernet Switch with 2 MSA Open SFP Slots .Compact housing allows for front access, easy installation & troubleshooting; DIN rail or wall mountable
  • FULL LAYER 2 MANAGEMENT CAPABILITIES: Through built in web-based GUI/Telnet/SSH; Switch can be managed to configure features like Ports/VLAN/Link Aggregation/SNMP/QoS/Spanning Tree among others
  • TECH SPECS: 8 + 2 port Gigabit switch / 8 x RJ45 / 2 x Open SFP slot (MSA Compliant) / 12-48VDC power input / 10/100/1000 Mbps auto / Redundant power inputs w/terminal block kit or using incl AC adapter
  • ROBUST DESIGN: Steel housing with IP-30/vibration/shock/free fall ratings and 6kV ESD; Operating temperature range of -40C to 75C w/ MTBF of 500,000+ hrs using MIL-HDBK-217F @ 25C; RJ45 dust caps incl
  • STARTECH.COM ADVANTAGE: IT professionals choice for over 30 years; This L2 Gigabit network switch is backed for 2-years by StarTech.com, including 24/5 North America based multi-lingual tech support

Similar Products

Compare All

StarTech.com Industrial 8 Port Gigabit Ethernet Switch w/2 MSA SFP Slots - Hardened GbE L2 Managed Network Switch - Rugged RJ45 LAN Layer 2 Switch Din Rail Wall Mount IP-30/-40C to 75C, Managed, L2, Gigabit Ethernet (10/100/1000), Full duplex, Wall mountable

Ports & interfaces

Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
SFP module slots quantity
2
Basic switching RJ-45 Ethernet ports quantity
8
Installed SFP modules quantity
0
Installed SFP+ modules quantity
0

Network

Networking standards
IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Flow control support
Yes
Full duplex
Yes
Virtual LAN features
Tagged VLAN
10G support
No
Spanning tree protocol
Yes
Copper ethernet cabling technology
10BASE-T, 100BASE-FX, 100BASE-TX, 1000BASE-SX, 1000BASE-T
Auto MDI/MDI-X
Yes

Management features

Switch layer
L2
Switch type
Managed

Data transmission

Store-and-forward
Yes
Jumbo frames support
Yes
Jumbo frames
9000

Design

International Protection (IP) code
IP30
Wall mountable
Yes
Product colour
Black
Housing material
Steel
LED indicators
Activity, Link

Performance

Maximum data transfer rate
2000 Mbit/s Mbit/s
Mean time between failures (MTBF)
100000 h h
Maximum cable length
100 m m
Buffer size
512 KB KB

Power

Output voltage
12 V V
Output current
1.5 A A
AC input voltage
100 - 240 V V
Power supply included
Yes
Power plug type
Type M

Operational conditions

Operating temperature (T-T)
-40 - 75 °C °C
Storage temperature (T-T)
-40 - 90 °C °C

Packaging data

AC adapter included
Yes
Washers included
Yes
DIN rail included
Yes
Package depth
303 mm mm
Package height
91 mm mm
Pinlock included
Yes
Terminal block included
Yes
Screws included
Yes
Dust cap included
Yes
Package width
173 mm mm
Package weight
1.11 kg kg

Weight & dimensions

Width
139 mm mm
Weight
626 g g
Height
30 mm mm
Depth
178 mm mm

Security

Access Control List (ACL)
Yes

Other features

Terminal block port
Yes

Packaging content

Quick start guide
Yes

Certificates

Certification
RoHS, CE, FCC

Logistics data

Master (outer) case width
342 mm mm
Master (outer) case height
474 mm mm
Products per master (outer) case
10 pc(s) pc(s)
Master (outer) case length
369 mm mm
