MSI MOBO MBA
- Support 3rd Gen AMD Ryzen™ Desktop Processors and AMD Ryzen™ 4000 G-Series Desktop Processors
- Supports DDR4 Memory, up to 4600(OC) MHz
- Turbo M.2: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs
- M.2 Shield Frozr: Strengthened built-in M.2 thermal solution. Keeps M.2 SSDs safe while preventing throttling, making them run faster
- Core Boost: With premium layout and digital power design to support more cores and provide better performance
- DDR4 Boost: Advanced technology to deliver pure data signals for the best performance and stability
- 2oz Thickened Copper PCB: An enhanced PCB design improves heat dissipation and performance reliability
- Audio Boost: Reward your ears with studio grade sound quality
- Dragon Center: A brand new software which integrates all MSI exclusive tools with user friendly user interface
Similar Products
Overview
MSI A520M PRO, AMD, Socket AM4, AMD Ryzen 3000 Series, DDR4-SDRAM, 64 GB, DIMM
Specifications
Internal I/O
- Chassis intrusion connector
- Yes
- USB 2.0 connectors
- 2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors
- 1
- USB 3.2 Gen 2 (3.1 Gen 2) connectors
- 0
- Number of SATA III connectors
- 4
- Number of SATA II connectors
- 0
- Total number of SATA connectors
- 4
- Number of Parallel ATA connectors
- 0
- Front panel audio connector
- Yes
- Front panel connector
- Yes
- ATX Power connector (24-pin)
- Yes
- CPU fan connector
- Yes
- Number of chassis fan connectors
- 1
Features
- Motherboard chipset
- AMD A520
- Audio output channels
- 7.1 channels channels
- Audio chip
- Realtek ALC892
- Power source type
- ATX
- Number of mounting holes
- 6
- Component for
- PC
- Motherboard form factor
- micro ATX
- Motherboard chipset family
- AMD
Expansion slots
- PCI Express x1 (Gen 3.x) slots
- 2
- PCI Express x16 slots
- 1
- Number of M.2 (M) slots
- 1
Logistics data
- Harmonized System (HS) code
- 84733020
Weight & dimensions
- Width
- 244 mm mm
- Depth
- 210 mm mm
- Height
- 65 mm mm
Other features
- Weight
- 698 g g
Processor
- Processor manufacturer
- AMD
- Processor socket
- Socket AM4
- Compatible processor series
- AMD Ryzen 3000 Series
- Maximum number of SMP processors
- 1
Memory
- Supported memory types
- DDR4-SDRAM
- Number of memory slots
- 2
- Maximum internal memory
- 64 GB GB
- Memory slots type
- DIMM
- Memory channels
- Dual-channel
- ECC сompatibility
- ECC & Non-ECC
- Supported memory clock speeds
- 1866,2133,2400,2667,2800,2933,3000,3066,3200,3466,3600,3733,3866,4000,4133,4266,4400,4466 MHz MHz
- Unbuffered memory
- No
Storage controllers
- Supported storage drive interfaces
- PCI Express 3.0, SATA
- Supported storage drive types
- HDD & SSD
- RAID levels
- 0, 1, 10
Graphics
- Maximum resolution
- 4096 x 2160 pixels pixels
Rear panel I/O ports
- USB 2.0 ports quantity
- 2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
- 4
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
- 0
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
- 0
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
- 0
- Ethernet LAN (RJ-45) ports
- 1
- VGA (D-Sub) ports quantity
- 1
- HDMI ports quantity
- 1
- DVI-D ports quantity
- 0
- eSATA ports quantity
- 0
- PS/2 ports quantity
- 1
- DisplayPorts quantity
- 1
- Microphone in
- Yes
Network
- Wi-Fi
- No
- Ethernet LAN
- Yes
- Ethernet interface type
- Gigabit Ethernet
- LAN controller
- Realtek 8111H
