Neomounts DS70S-950WH1 - Mounting kit (desk mounting arm) - full-motion - for Monitor - aluminium - white - screen size: 17"-49
Manuf P/N: DS70S-950WH1
APAXON#: 8670065
EAN: 8717371441418
Neomounts DS70S-950WH1 - Mounting kit (desk mounting arm) - full-motion - for Monitor - aluminium - white - screen size: 17"-49
- Maximum weight capacity: 18 kg
- Minimum screen size: 43.2 cm (17") Maximum screen size: 124.5 cm (49")
- Number of displays supported: 1
- Clamp/Grommet Mounting type: Desk
- Maximum VESA mount: 100 x 100 mm
- Gas spring Height adjustment Tilt adjustment
- Cable management Easy to install
- Aluminium White
Stock49
Price £0.00
Quantity
|
Similar Products
Neomounts DS70S-950WH1 - Mounting kit (desk mounting arm) - full-motion - for Monitor - aluminium - white - screen size: 17"-49
Your Choice
English
United Kingdom
1
Personal computer
N/A GB
Stock
49
£0.00
K/NMPLXPROTECT DBL MB BK50 10-49 DC/GKit
Better
English
United Kingdom
1
Personal computer
N/A GB
Stock
0
£0.00
Neomounts TV Desk Stand (legs) - Black - 45-90 inches
Better
English
United Kingdom
1
Personal computer
N/A GB
Stock
1
£0.00
Neomounts DS60-600BL1 - Mounting kit (monitor arm, grommet clamp) - full-motion - for Monitor - steel - black - screen size: 10"-32" - desk-mountable
Better
English
United Kingdom
1
Personal computer
N/A GB
Stock
0
£0.00
K/NMPLXPROTECT DBL MB BK50 10-27 DC/GKit
Better
English
United Kingdom
1
Personal computer
N/A GB
Stock
0
£0.00
Product Summary
Neomounts DS70S-950WH1 Monitor arm 17-49" - gas spring - Topfix - 180°-stop
Extended Specification
Mounting
Number of displays supported
1
Maximum screen size
124.5 cm (49")
Mounting type
Desk
Maximum weight capacity
18 kg
Minimum screen size
43.2 cm (17")
Minimum VESA mount
75 x 75 mm
Maximum VESA mount
100 x 100 mm
Maximum weight capacity (per curved/ultra-wide display)
15 kg
Mounting
Clamp/Grommet
Panel mounting interface
75 x 75,100 x 100 mm
Desk thickness (min)
1 cm
Desk thickness (max)
5.5 cm
Clamp mount desk thickness (max)
5 cm
Grommet mount desk thickness (max)
5.5 cm
Distance to the wall (min)
11.9 cm
Distance to the wall (max)
65.6 cm
Ergonomics
Height adjustment
Yes
Height adjustment type
Gas spring
Height adjustment range
200 - 520 mm
Adjustable depth
Yes
Depth adjustment range
88 - 625 mm
Tilt adjustment
Yes
Tilt angle range
-90 - 90°
Swivelling
Yes
Swivel angle range
-90 - 90°
Rotating
Yes
Angle of rotation
360°
Number of arms
1
Cable management
Yes
Design
Product colour
White
Housing material
Aluminium
Easy to install
Yes
Weight & Dimensions
Width
135 mm
Depth
656 mm
Height
579 mm
Weight
3.72 kg
Packaging data
Package width
333 mm
Package depth
122 mm
Package height
423 mm
Package weight
4.3 kg
Package type
Box
Package net weight
4.3 kg
Other features
Minimum weight
1 kg
Width adjustment range
0 - 1074 mm
Warranty period
10 year(s)
Logistics data
Master (outer) case width
355 mm
Master (outer) case length
290 mm
Master (outer) case height
490 mm
Master (outer) case gross weight
18.1 kg
Products per master (outer) case
4 pc(s)
Country of origin
China
Master (outer) case net weight
15 kg
Harmonized System (HS) code
7326909890
Products per pallet (EU)
80 pc(s)
